v. 12.july.2016
A C O U S T I C A C 1 0 1 H
O W N E R 's M A N UA L

Advertisement

loading
Need help?

Need help?

Do you have a question about the ACOUSTIC AC 101 H and is the answer not in the manual?

Questions and answers

Related Manuals for Mark Acoustic ACOUSTIC AC 101 H

Summary of Contents for Mark Acoustic ACOUSTIC AC 101 H

  • Page 1 v. 12.july.2016 A C O U S T I C A C 1 0 1 H O W N E R ’s M A N UA L...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS PRÉCAUTIONS D’EMPLOI 1) Read these instructions; 1) Lire ces instructions; 2) Keep these instructions; 2) Conserver ces instructions; 3) Heed all warnings; 3) Suivre tous les conseils d’utilisations; 4) Follow all instructions; 4) Suivre toutes les instructions; 5) Do not use this apparatus near water;...
  • Page 3 A Word from Marco De Virgiliis Thank you for choosing the Acoustic AC 101 H combo. The full-range sound reproduction of the AC 101 H, powering even the lowest frequencies with stunning definition, makes it appropriate for a wide range of acoustic instruments such acoustic guitar, acoustic bass, double bass, harp, cello, accordion, etc.

  • Page 4: Front Panel

    FRONT PANEL 1) INPUT CH1 Connect your acoustic instrument to this input using a standard ¼” shielded instrument cable. 2) CH1 GAIN This controls how much signal is passed through the CH1 preamp stage of the unit, which includes equalization and the effects loop. 3) CH1 CLIP LED If playing through the amp causes the blue CLIP light to turn on at all, you should turn down the GAIN control to set the optimal gain level for your instrument’s signal.
  • Page 5 14) CH2 LOW This knob controls the amount of low frequencies in your sound, boosts or cuts the level of the frequencies around 60 Hz (± 16 dB). 15) CH2 HIGH This knob controls the level of mid frequencies, boosts or cuts the level of the frequencies around 5 kHz (± 16 dB). 16) VPF The VPF (Variable Preshape Filter) knob boosts lows and highs, and cuts mids around 380 Hz.

  • Page 6: Rear Panel

    REAR PANEL 23) AC POWER SOCKET Make sure the unit is grounded; all three terminals of the AC power plug must be connected to avoid any injury to the user or damage to the unit. WARNING: The DV AC 101 is manufactured to be used in the country where they have been sold, and it is factory preset to that country’s voltage. So make sure you’re sending the correct voltage to your amp before you connect it to AC power.
  • Page 7 13 14 19 20 PULL FOR GAIN HIGH EFFECT MIX PHANTOM CLIP CLIP MIX INPUT 31) LINE OUT The balanced XLR output allows you to connect your amplifier directly to a mixing console (either in live situations or in a recording INPUT GAIN HIGH...

  • Page 8: Technical Specs

    TECHNICAL SPECS Channels: Input CH1 unbalanced impedance: 500 Kohm, max. voltage: 10 Vpp Input CH2 unbalanced impedance: 1 Mohm, max. voltage: 10 Vpp balanced impedance: 1 Mohm, max. voltage: 20 Vpp Return impedance: 10 Kohm, max. voltage: 20 Vpp Controls: Gain CH1 –45 dB to +28 dB range Gain CH2...
  • Page 9 Outputs Send unbalanced, max. voltage 25 Vpp Line Out balanced XLR, max. voltage 20 Vpp Speaker Out speakon / 1/4” combo jack, 1/4” jack Speaker Outputs: One ¼” Jack mono out (minimum load 4 ohm) One Neutrik Speakon/¼” Jack Combo out (minimum load 4 ohm) Power Output: 250W RMS @ 4 ohm, 150W RMS @ 8 ohm Other Features:...
  • Page 10 Product specifications are subject to change without notice Italy - 66020 San Giovanni Teatino (Ch) - Via Po, 52 - Tel. +39 085 446 3755 - Fax +39 085 440 7764 - www.markbass.it - info@markbass.it...
