- Page 1 Toll Free Help Line Ligne d'assistance en service libre Linea de ayuda telefónica sin cargo 800-531-0039 Mini Hi-Fi Systems avec Changeur de 3 CD 3139 116 19371 pg 01-24/C30/21&/30-En 3/3/00, 4:23 PM...
- Page 2 Modelo: FW-C30/21 Alimentación: 110–127/220–240 V; ~50–60 Hz Consumo: 70 W Importador: Philips Mexicana, S.A. de C.V. Domicilio: Norte 45, #669, Col. Industrial Vallejo Localidad y Telefono: C.P. 02300 México D.F., Tel. 728 42 00 Exportador: Philips Hong Kong País de Origen: China Nº...
- Page 3 English ...4 Français ...25 Español ...47 ...69 Warranty ...89 Australia/New Zealand/Mexico CLASS 1 LASER PRODUCT 3139 116 19351 pg 01-24/C30/21&/30-En 3/3/00, 4:23 PM...
- Page 4 3139 116 19351 pg 01-24/C30/21&/30-En 3/3/00, 4:23 PM...
-
Page 5: Table Of Contents
CONTENTS GENERAL INFORMATION General Information ... 5 PLEASE NOTE THAT THE VOLTAGE SELECTOR Safety Information ... 5 LOCATED AT THE REAR OF Preparation ... 6 - 7 THIS SYSTEM IS PRESET AT 220V FROM THE FACTORY. Controls ... 8 - 9 FOR COUNTRIES THAT Operating The System ... -
Page 6: Preparation
PREPARATION Rear Connections pg 01-24/C30/21&/30-En FM AERIAL AM ANTENNA – – VOLTAGE VOLTAGE SELECTOR SELECTOR 220V- 110V- 240V 127V 220V- 110V- 240V 127V MAINS SUBWOOFER AUX IN AUDIO OUT 3/3/00, 4:23 PM STANDBY ON CUT OFF FREQUENCY HIGH POWER SUBWOOFER 60Hz 150Hz 3139 116 19351... -
Page 7: Preparation
A AM Loop Antenna Connection 12 mm Connect the supplied loop antenna to the AM ANTENNA terminal. Place the AM loop antenna far away from the system and adjust its position for the best reception. D Connecting other B FM Wire Antenna equipment to your system Connection You can connect the audio left and right... -
Page 8: Controls
CONTROLS DISC 1 DISC CHANGE C H A N G E R MINI HIFI SYSTEM STANDBY-ON CD1 • 2 • 3 CONTROL OPTIMAL TUNING JAZZ SEARCH PROGRAM ROCK MICROPHONE - LEVEL TECHNO ™ TAPE 1 PLAY/REC ¡ FULL AUTO STOP pg 01-24/C30/21&/30-En DISC 2 DISC 3... - Page 9 ! SOURCE – to select the following: Controls on the system and CD / (CD 1•2•3) remote control – to select CD mode. When CD playback is stopped, press to select disc tray 1, 1 STANDBY ON 2 or 3. –...
-
Page 10: Operating The System
OPERATING THE SYSTEM MINI HIFI SYSTEM STANDBY-ON C D 1 • 2 • 3 BAND TAPE 1 • 2 CONTROL TUNER TAPE OPTIMAL TUNING PRESET JAZZ SEARCH STOP• CLEAR PLAY• PAUSE PREV PROGRAM CLOCK•TIMER ROCK MICROPHONE - LEVEL TECHNO SOUND NAVIGATION - JOG Important: To stop the demonstration mode Before you operate the system,... -
Page 11: Operating The System
DIM 3 - half brightness with Spectrum DIM mode Analyzer Off and all LEDs on the You can select the desired brightness for system will be switched off. the display. • Press DIM to select DIM 1, DIM 2, DIM 3 or DIM OFF display mode. - Page 12 DISC 1 DISC 2 DISC 3 DISC CHANGE C H A N G E R MINI HIFI SYSTEM STANDBY-ON CD1 • 2 • 3 BAND TAPE 1 • 2 CONTROL TUNER TAPE OPTIMAL TUNING PRESET JAZZ SEARCH STOP• CLEAR PLAY• PAUSE PREV PROGRAM CLOCK •...
- Page 13 ™ The CD carousel tray will rotate until Searching for a particular the inner tray is rotated out and is passage during playback ready for changing. • Press and hold à or á until the 3 Press OPEN•CLOSE to close the CD desired passage is located.
-
Page 14: Aux
Shuffle Repeat (only on remote control) In shuffle mode, the system plays all the You can play the current track, a disc or all available discs and their tracks in random available discs repeatedly. order. Shuffle may be used also when 1 Press REPEAT on the remote control to tracks are programmed. -
Page 15: Tuner
MINI HIFI SYSTEM STANDBY-ON CD1 • 2 • 3 BAND TAPE 1 • 2 CONTROL TUNER TAPE OPTIMAL TUNING PRESET JAZZ SEARCH STOP• CLEAR PLAY• PAUSE PREV NEXT PROGRAM CLOCK•TIMER ROCK MICROPHONE - LEVEL TECHNO SOUND NAVIGATION - JOG Note: •... -
Page 16: Tuner
TUNER Notes: Changing the MW tuning grid – When 40 radio stations are stored and (not available for version /30) you attempt to store another radio The frequency step can be changed if station, the display will show necessary. In North and South America, the "... -
Page 17: Tape
MINI HIFI SYSTEM STANDBY-ON C D 1 • 2 • 3 BAND TAPE 1 • 2 CONTROL TUNER TAPE OPTIMAL TUNING PRESET JAZZ SEARCH STOP• CLEAR PLAY• PAUSE PREV NEXT PROGRAM CLOCK•TIMER ROCK MICROPHONE - LEVEL TECHNO SOUND NAVIGATION - JOG TAPE 1 FULL AUTO STOP pg 01-24/C30/21&/30-En... -
Page 18: Karaoke
TAPE Notes: – During rewinding or fast forwarding of a tape, it is also possible to listen to another source (e.g. CD, TUNER or AUX). – Before playing a tape, check and tighten slack tape with a pencil. Slack tape may get jammed or may burst in the mechanism. -
Page 19: Recording
MINI HIFI SYSTEM STANDBY-ON C D 1 • 2 • 3 BAND TAPE 1 • 2 CONTROL TUNER TAPE OPTIMAL TUNING PRESET JAZZ SEARCH STOP• CLEAR PLAY• PAUSE PREV NEXT PROGRAM CLOCK•TIMER ROCK MICROPHONE - LEVEL TECHNO SOUND NAVIGATION - JOG TAPE 1 FULL AUTO STOP pg 01-24/C30/21&/30-En... -
Page 20: Clock
RECORDING 5 Press STOP•OPEN on tape deck 1 and tape deck 2 to stop dubbing. Notes: – At the end of side A, flip the tapes to side B and repeat the procedure. – Dubbing of tapes is only possible from tape deck 2 to tape deck 1. -
Page 21: Timer
TIMER 5 Press CLOCK•TIMER again to store the ™ The TIMER setting. ™ The selected source is lit while other ™ The clock starts. available sources are flashing. 2 Press CD or TUNER to select the • To exit without storing the setting, press desired source. -
Page 22: Specifications
SPECIFICATIONS Specifications AMPLIFIER Output power PMPO ... 1000 W ... 2 x 35 W Signal-to-noise ratio ... 67 dBA (IEC) Frequency response ... 50 – 15,000 Hz, ± 3dB Input sensitivity AUX In ... 700 mV Microphone (not available for version /30) ... 3.5 mV Output Speakers ... -
Page 23: Maintenance
• After prolonged use, dirt or dust may accumulate at the CD lens. To ensure good playback quality, clean the CD lens with Philips CD Lens Cleaner or any commercially available cleaner. Follow the instructions supplied with cleaner. pg 01-24/C30/21&/30-En TROUBLESHOOTING “DISC NOT FINALIZED”... -
Page 24: Troubleshooting
TROUBLESHOOTING Tape Deck Operation General “RECORDING ACTIVE” is displayed. System does not react when any • A recording is in progress. button is pressed. ™ Stop the recording or wait until it is • Electrostatic discharge. finished. ™ Press STANDBY ON to switch the system off.
