1. General description

2. Features

3. Applications

TDA8559T
Low-voltage stereo headphone amplifier
Rev. 03 — 15 May 2006
The TDA8559T is a stereo amplifier that operates over a wide supply voltage range from
1.9 V to 30 V and consumes a very low quiescent current. This makes it suitable for
battery fed applications (2
can be used with or without a capacitor connected in series with the load. It can be
applied as a headphone amplifier, but also as a mono amplifier with a small speaker
(25 ), or as a line driver in mains applications.
I
Operating voltage from 1.9 V to 30 V
I
Very low quiescent current
I
Low distortion
I
Few external components
I
Differential inputs
I
Usable as a mono amplifier in Bridge-Tied Load (BTL) or stereo Single-Ended (SE)
I
Single-ended mode without loudspeaker capacitor
I
Mute and Standby mode
I
Short-circuit proof to ground, to supply voltage (< 10 V) and across load
I
No switch on or switch off clicks
I
ESD protected on all pins
I
Portable telephones
I
MP3 players
I
Portable audio
I
Mains fed equipment
1.5 V cells). Because of an internal voltage buffer, this device
Product data sheets

Advertisement

Table of Contents
loading

Related Manuals for Philips TDA8559T

Summary of Contents for Philips TDA8559T

  • Page 1: General Description

    Rev. 03 — 15 May 2006 1. General description The TDA8559T is a stereo amplifier that operates over a wide supply voltage range from 1.9 V to 30 V and consumes a very low quiescent current. This makes it suitable for battery fed applications (2 can be used with or without a capacitor connected in series with the load.

  • Page 2: Quick Reference Data

    = 1 kHz = 20 mW; = 10 kHz 1 dB = 70 mW; 0.05 = 1 kHz = 70 mW; = 10 kHz © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Unit 0.15 Version SOT109-1 2 of 36...

  • Page 3: Block Diagram

    LOGIC MODE 100 k SVRR TDA8559T 9,10 n.c. Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 50 k OUT1 OUT2 50 k BUFFER BUFFER mgd115 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 3 of 36...

  • Page 4: Table Of Contents

    (0.5V ground output 1 high supply voltage low supply voltage Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier OUT1 TDA8559T BUFFER OUT2 n.c. n.c. 001aae802 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 4 of 36...

  • Page 5: Standby

    Philips Semiconductors 8. Functional description The TDA8559T contains two amplifiers with differential inputs, a 0.5V high supply voltage stabilizer. Each amplifier consists of a voltage-to-current converter (V/I), an output amplifier and a common dynamic quiescent current controller. The gain of each amplifier is internally fixed at 26 dB (= 20 ).

  • Page 6: Dynamic Quiescent Controller

    These currents control the quiescent current. 8.5 Stabilizer The TDA8559T has a voltage supply range from 1.9 V to 30 V. This range is divided over two supply voltage pins. Pin 16 is 1.9 V to 18 V (breakdown voltage of the process); this pin is preferred for supply voltages less than 18 V.

  • Page 7: Internal Circuitry

    Product data sheets Internal circuits Equivalent circuit 2, 3, 5 and 6 Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 10 k mgd110 mgd106 mgd107 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 7 of 36...
  • Page 8 Philips Semiconductors Table 4. Symbol MUTE MODE TDA8559_3 Product data sheets Internal circuits …continued Equivalent circuit Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier mgd112 mgd113 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 8 of 36...
  • Page 9 Internal circuits …continued Equivalent circuit 11 and 14 15 and 16 Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier buffer output mgd108 buffer output mgd109 mgd111 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 9 of 36...

  • Page 10: Limiting Values

    = 20 mW; f = 10 kHz 1 dB = 5 k Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 1.19 +150 2.75 0.075 0.15 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Unit Unit Unit 10 of 36...

  • Page 11: Mute

    Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 0.05 = 5 k . output. = 0 k ). Figure 4). For applications with supply Figure 5 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Unit Figure 6 11 of 36...

  • Page 12: Mode

    = 3 V, f = 1 kHz, R = 32 , Gain = 26 dB, (Figure 4) and input and the input configuration illustrated in © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Figure 6; input 12 of 36...

  • Page 13: Input Configurations

    100 nF pin 3 pin 6 100 nF pin 5 mgd126 At V 6 V, combined negative inputs. 620 k 47 k 220 nF mgl135 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Figure 4 Figure 6 13 of 36...

  • Page 14: Standby/Mute

    The capacitor Cr is not required; see 13.10 Application 5: Line driver application The TDA8559T delivers a virtual rail-to-rail output voltage and is also usable in a low voltage environment, as a line driver. In this application the input needs a DC path to ground, input configurations illustrated in...

  • Page 15: Out2

    Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier Figure 6 should be used. This 50 k OUT1 220 F OUT2 220 F 50 k BUFFER BUFFER mgd116 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 100 F 15 of 36...

  • Page 16: Buffer

    LOGIC MODE 100 k SVRR TDA8559T Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 100 F 50 k OUT1 OUT2 50 k BUFFER BUFFER mgd117 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 16 of 36...
  • Page 17 LOGIC MODE 100 k SVRR TDA8559T Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 100 F 50 k OUT1 OUT2 50 k BUFFER BUFFER mgd118 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 17 of 36...

  • Page 18: Out1

    50 k MUTE INPUT LOGIC MODE 100 k SVRR TDA8559T Rev. 03 — 15 May 2006 TDA8559T 100 F 50 k OUT1 OUT2 50 k BUFFER BUFFER mgd119 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 18 of 36...
  • Page 19 = 1.9 V to 6 V. Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 50 k OUT1 OUT2 50 k BUFFER BUFFER © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 100 F 10 F 10 F mgd120 19 of 36...
  • Page 20 Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 50 k OUT1 INPUT LOGIC OUT2 50 k BUFFER BUFFER © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 100 F 10 F 10 F mgd121 20 of 36...
  • Page 21 Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier 50 k OUT1 10 F OUT2 10 F 50 k BUFFER BUFFER © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 100 F POWER AMPLIFIER mgd122 21 of 36...

  • Page 22: Printed-Circuit Board Layout

    100 nF TDA8559T 100 F D&A AUDIO POWER QC - NIJMEGEN 001aae801 Figure 8 for a maximum supply as a function of V (stereo headphone) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Buf. Figure 8 mda090 22 of 36...
  • Page 23 = 5 V, THD = 50 mW. = 3 V, THD = 20 mW. headphone) = 3 V. = 12 V. as a function of V (stereo headphone) mute © Koninklijke Philips Electronics N.V. 2006. All rights reserved. mda092 f (Hz) mda094 mute 23 of 36...
  • Page 24 = 3 V, V = 20 mV. mda098 = 32 , THD = 10 %. = 32 , THD = 0.5 %. as a function of V (stereo headphone) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 24 of 36...
  • Page 25 = 25 . = 5 V, R = 25 . (BTL mono) = 3 V, R = 0 , V = 0.2 V (RMS). © Koninklijke Philips Electronics N.V. 2006. All rights reserved. mda130 mda132 f (Hz) 25 of 36...

  • Page 26: Response Curves For High Input Mode

    Low-voltage stereo headphone amplifier = 25 . = 32 function of supply voltage (BTL mono) = 25 . = 32 . function of supply voltage (SE) (stereo headphone) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. mda134 mda120 26 of 36...
  • Page 27 = 32 . = 100 mW. = 50 mW. headphone) = 10 V, R = 0 , V = 0.2 V (RMS). headphone) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. mda122 f (Hz) mda124 f (Hz) 27 of 36...
  • Page 28 Low-voltage stereo headphone amplifier = 12 V, V = 1 V. driver) = 12 V, R = 0 , V = 0.2 V (RMS). driver) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. mda126 f (Hz) mda128 f (Hz) 28 of 36...

  • Page 29: Test Information

    = 1 k . = 1 k . as a function of V (stereo line driver) Rev. 03 — 15 May 2006 TDA8559T Low-voltage stereo headphone amplifier mda129 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 29 of 36...

  • Page 30: Package Outline

    Low-voltage stereo headphone amplifier (A ) detail X 5 mm 1.05 0.25 0.25 0.039 0.028 0.041 0.01 0.01 0.016 0.020 EUROPEAN PROJECTION © Koninklijke Philips Electronics N.V. 2006. All rights reserved. SOT109-1 0.028 0.004 0.012 ISSUE DATE 99-12-27 03-02-19 30 of 36...

  • Page 31: Soldering

    260 C + 0 C 260 C + 0 C 250 C + 0 C 245 C + 0 C 245 C + 0 C 245 C + 0 C © Koninklijke Philips Electronics N.V. 2006. All rights reserved. > 2000 31 of 36...

  • Page 32: Manual Soldering

    CWQCCN..L For more detailed information on the BGA packages refer to the (LF)BGA Application Note (AN01026); order a copy from your Philips Semiconductors sales office. All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the maximum temperature (with respect to time) and body size of the package, there is a risk that internal or external package cracks may occur due to vaporization of the moisture in them (the so called popcorn effect).
  • Page 33 Hot bar soldering or manual soldering is suitable for PMFP packages. TDA8559_3 Product data sheets Low-voltage stereo headphone amplifier 10 C measured in the atmosphere of the reflow oven. The package Rev. 03 — 15 May 2006 TDA8559T © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 33 of 36...

  • Page 34: Revision History

    Product data sheets Low-voltage stereo headphone amplifier Data sheet status Change notice Product data sheet Product specification Preliminary specification Rev. 03 — 15 May 2006 TDA8559T Supersedes TDA8559_2 TDA8559_1 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. 34 of 36...

  • Page 35: Legal Information

    For detailed and full information see the relevant full data sheet, which is available on request via the local Philips Semiconductors sales office. In case of any inconsistency or conflict with the short data sheet, the full data sheet shall prevail.

  • Page 36: Contents

    Please be aware that important notices concerning this document and the product(s) described herein, have been included in section ‘Legal information’. © Koninklijke Philips Electronics N.V. 2006. For more information, please visit: http://www.semiconductors.philips.com. For sales office addresses, email to: sales.addresses@www.semiconductors.philips.com. TDA8559T All rights reserved. Date of release: 15 May 2006...
