Philips Semiconductors
Low voltage mono/stereo power amplifier

RATINGS

Limiting values in accordance with the Absolute Maximum System (IEC 134)
Supply voltage
Peak output current
Total power dissipation
Storage temperature range
Crystal temperature
A.C. and d.c. short-circuit duration
at V = 3,0 V (during mishandling)
P

THERMAL RESISTANCE

From junction to ambient
June 1989
Fig.1 Power derating curve.
3
Product specification
TDA7050
V max.
P
I max. 150 mA
OM
see derating curve Fig.1
T 55 to + 150 C
stg
T max. 100 C
c
t max.
sc
R =
thj-a
6 V
5 s
110 K/W
