Summary of Contents for T-Mobile Sonic 2.0
- Page 3 GETTING TO KNOW YOUR MOBILE HOTSPOT Memory card slot LCD Screen Back key Right key Left key Charging& USB port Function key Power key Enter or select an item. Press and hold to turn on/off.
- Page 4 Reset point Trigger this point to reset your device. ’s 4G LTE network is not available everywhere. Please see coverage details at .com. Device and screen images are simulated. Capable device is required to achieve 4G LTE speed. INDICATORS Indicates that your Mobile HotSpot is on ’s 2G network. Indicates that your Mobile HotSpot is on ’s 3G network.
- Page 5 Battery power level. The indicator will flash when the battery is almost exhausted. The indicator will show as filling when the Mobile HotSpot is charging. SET UP YOUR SONIC 2.0 MOBILE HOTSPOT Remove back cover and battery. Install SIM card.
- Page 6 USB cable. CONNECT & GO Connect your Wi-Fi device to your Sonic 2.0 Mobile HotSpot Power on your Mobile HotSpot. On your computer or other Wi-Fi enabled device, search for available Wi-Fi Networks and select the default Network for your Mobile HotSpot.
- Page 7 Note: By activating service, you acknowledge that you have read, understand, and agree to be bound by each of ’s Terms and Conditions and your Service Agreement. Managing Your Sonic 2.0 Hotspot Access WebConnect You can access WebConnect using a browser or by starting the WebConnect Companion, if you have it installed on your computer.
- Page 8 To access WebConnect using the WebConnect Companion application, do the following: Connect to your hotspot device via Wi-Fi using the network connection software on your computer. Provide the Wi-Fi network password, if requested. Start the WebConnect Companion application. The WebConnect Companion’s icon appears in your system tray (Windows) or Menu bar (Mac).
- Page 9 Click Configuration in the navigation area to access the Configuration screen. Select the Hotspot Settings tab on the Configuration screen. Change the name that appears in the Network Name (SSID) field in the Wi-Fi Settings area. Select or deselect the Broadcast network name checkbox to enable or disable broadcasting the hotspot’s Network Name (SSID).
-
Page 10: Additional Information
ADDITIONAL INFORMATION Wi-Fi: Devices using wireless connections may be vulnerable to unauthorized attempts to access data and software stored on the device. Plan data allotment applies to use by connected devices sharing Wi-Fi. Use of connected devices subject to terms and conditions. Messaging/Data: You will be charged for all messages and data sent by or to you through the network, regardless of whether or not data is received. -
Page 11: Additional Help
ADDITIONAL HELP Mobile HotSpot URL: http://mobile.hotspot/ or IP address: 192.168.0.1. From the HotSpot Admin page, click User Manual.
