- Page 1 DISCRETE SEMICONDUCTORS DATA SHEET BGY580 CATV amplifier module Product specification Supersedes data of 1997 Apr 15 File under Discrete Semiconductors, SC16 1998 Feb 25...
- Page 2 TiPtAu metallized crystals. DESCRIPTION Hybrid amplifier module for CATV systems operating over a frequency range of 40 to 550 MHz at a voltage supply of 24 V (DC). The BGY580 is intended for use as a pre-amplifier. QUICK REFERENCE DATA SYMBOL PARAMETER...
- Page 3 Philips Semiconductors CATV amplifier module CHARACTERISTICS Bandwidth 40 to 550 MHz; T = 30 C; Z SYMBOL PARAMETER power gain slope cable equivalent flatness of frequency response input return losses output return losses composite triple beat cross modulation composite second order distortion...
-
Page 4: Package Outline
Philips Semiconductors CATV amplifier module PACKAGE OUTLINE Rectangular single-ended package; aluminium flange; 2 vertical mounting holes; 2 x 6-32 UNC and 2 extra horizontal mounting holes; 7 gold-plated in-line leads DIMENSIONS (mm are the original dimensions) UNIT max. max. max. -
Page 5: Life Support Applications
Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale. - Page 6 Philips Semiconductors Product specification CATV amplifier module BGY580 NOTES 1998 Feb 25...
