Summary of Contents for Philips BGY280
- Page 1 DISCRETE SEMICONDUCTORS DATA SHEET M3D454 BGY280 UHF amplifier module Preliminary specification 2000 Nov 15...
- Page 2 880 to 915 MHz and 1710 to 1785 MHz. DESCRIPTION The BGY280 is a power amplifier module in a SOT559A leadless package with a plastic cap. The dimensions are 13.75 x 11 x 1.7 mm. The module consists of two separated line-ups.
- Page 3 Philips Semiconductors UHF amplifier module CHARACTERISTICS = 50 Ω; P = 0 dBm; V D1,2 f = 880 to 915 MHz (GSM900); f = 1710 to 1785 MHz (GSM1800); unless otherwise specified. SYMBOL PARAMETER leakage current peak control current load power GSM 900...
- Page 4 Philips Semiconductors UHF amplifier module SYMBOL PARAMETER conversion control bandwidth stability ruggedness (dBm) = 50 Ω ; V = 3.6 V; P = 0 dBm; = 25 ° C; δ = 2 : 8; t = 575 µ s. Fig.2 Load power as a function of control voltage;...
- Page 5 Philips Semiconductors UHF amplifier module (dBc) = 50 Ω ; V = 3.6 V; P = 0 dBm; = 25 ° C; δ = 2 : 8; t = 575 µ s. Fig.4 Second harmonic as a function of load power;...
- Page 6 Philips Semiconductors UHF amplifier module output 900MHz 1800MHz = 50 Ω ; V = 3.6 V; P = 0 dBm; T ∆ f = 100 kHz; input amplitude modulation = 5.4%; δ = 2 : 8; t Fig.8 Output amplitude modulation as a function of load power;...
- Page 7 Philips Semiconductors UHF amplifier module RF input RF input List of components (See Fig 10 and 11) COMPONENT DESCRIPTION multilayer ceramic chip capacitor electrolytic capacitor stripline; note 1 R1, R metal film resistor Note 1. The striplines are on a double copper-clad printed-circuit board with PTFE fibreglass dielectric (ε...
- Page 8 Philips Semiconductors Preliminary specification UHF amplifier module BGY280 Fig.12 PCB testcircuit 2000 Nov 15...
- Page 9 Philips Semiconductors UHF amplifier module PACKAGE OUTLINE SOT559A Leadless surface mounted package; plastic cap; 16 terminations L 1 (4×) L (12×) (4×) (4×) (2×) b 7 (4×) b 8 (4×) b 3 (4×) pin 1 index DIMENSIONS (mm are the original dimensions) UNIT 5.275...
- Page 10 This data sheet contains preliminary data, and supplementary data will be published at a later date. Philips Semiconductors reserves the right to make changes at any time without notice in order to improve design and supply the best possible product.
- Page 11 Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH, Tel. +41 1 488 2741 Fax. +41 1 488 3263 Taiwan: Philips Semiconductors, 5F, No. 96, Chien Kuo N. Rd., Sec. 1, TAIPEI, Taiwan Tel. +886 2 2134 2451, Fax. +886 2 2134 2874 Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd., 60/14 MOO 11, Bangna Trad Road KM.
