- Page 1 DISCRETE SEMICONDUCTORS DATA SHEET BGD602 CATV amplifier module Product specification File under Discrete Semiconductors, SC16 Philips Semiconductors February 1994...
- Page 2 Philips Semiconductors CATV amplifier module FEATURES Excellent linearity Extremely low noise Silicon nitride passivation Rugged construction Gold metallization ensures excellent reliability. DESCRIPTION Hybrid high dynamic range amplifier module designed for applications in CATV systems with a bandwidth of 40 to 600 MHz operating with a voltage supply of 24 V (DC).
- Page 3 Philips Semiconductors CATV amplifier module CHARACTERISTICS Bandwidth 40 to 600 MHz; V = 24 V; T SYMBOL power gain slope cable equivalent flatness of frequency response input return losses output return losses phase response composite triple beat cross modulation composite second order distortion...
- Page 4 Philips Semiconductors CATV amplifier module CHARACTERISTICS Bandwidth 40 to 550 MHz; V = 24 V; T SYMBOL power gain slope cable equivalent flatness of frequency response input return losses output return losses phase response composite triple beat cross modulation composite second order distortion...
- Page 5 Philips Semiconductors CATV amplifier module CHARACTERISTICS Bandwidth 40 to 450 MHz; V = 24 V; T SYMBOL power gain slope cable equivalent flatness of frequency response input return losses output return losses phase response composite triple beat cross modulation composite second order distortion...
-
Page 6: Life Support Applications
Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale.
