Page 1
User guide MAS85 MINI HI-FI SYSTEM S M A R T . V E R Y S M A R T . Thank you for choosing Magnavox Need help fast? Read your Quick Use Guide and/or Owner's manual first for quick tips that make using your magnavox product more enjoyable.
Page 2
CAUTION Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation. ATTENTION Une utilisation des commandes ou des réglages ou l’exécution de procédures différentes à celles énoncées ici peuvent mener à une exposition dangereuse aux radiations ou autre opération dangereuse.
Page 4
Return your Product Registration Card today to get the very most from your purchase. Registering your model with Magnavox makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once to ensure: *Proof of Purchase Returning the enclosed card...
Page 5
Visit our World Wide Web Site at http://www.usasupport.magnavox.com Congratulations on your purchase, and welcome to the “family!” Dear Magnavox product owner: Thank you for your confidence in Magnavox. You’ve selected one of the best-built, best-backed products available today. We’ll do every- thing in our power to keep you happy with your purchase for many years to come.
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer´s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that...
Page 7
Index English ------------------------------------------------ 6 Español --------------------------------------------- 25 Español --------------------------------------------- 43...
Contents General Information Supplied accessories ... 9 Environmental information ... 9 Maintenance ... 9 Safety information ... 9 Controls Controls on the system ... 10 Remote control ... 11 Installation Rear connections ... 12 Speakers connection FM antenna Using AC power ... 13 Inserting batteries into the remote control .
Cleaning the disc lens ● After prolonged use, dirt or dust may accumulate at the disc lens. To ensure good playback quality, clean the disc lens with Philips CD Lens Cleaner or any commercially available cleaner. Follow the instructions supplied with cleaner.
Controls (illustrations on page 3) Controls on the system 1 Disc trays 2 PROGRAM indicator 3 REPEAT indicator 4 TUNING rotary – tunes to radio stations 5 OPEN/CLOSE – press to open/close the disc tray 6 DBB – turns the bass enhancement on/off 7 4 / ¢...
Remote control 1 POWER ON – switches the system on or to standby mode 2 DIGITS 0 - +10 – CD: selects a track number 3 REPEAT – selects repeat modes 4 ÉÅ – starts or pauses CD playback 5 DISC DISC 1/DISC 2/DISC 3 –...
Installation Speaker (right) Rear connections Warning: Never make or change connections with the power supply switched on. Speakers connection Use the supplied speakers only. Using other speakers can damage the set or the sound quality will be negatively affected. ● Connect the speaker wires to the SPEAKERS terminals, right speaker to “R”...
Using AC power Make sure all connections have been made before switching on the power supply. Connect the power cable supplied to AC ~ and to the wall socket. This switches on the power supply. When the system is switched to standby, it is still consuming some power.
Basic Functions Switching on/to standby and selecting functions Press POWER to switch on (or .POWER ON on the remote control). ➜ The POWER indicator lights up ➜ The system switches to the last source selected. To select your function, push FUNCTION to TUNER, TAPE or CD.
Discs for playback This system can playback all digital audio CD, finalized digital audio CD-Recordable (CDR) discs and finalized digital audio CD-Rewritable (CDRW)discs. IMPORTANT! – This system is designed for regular discs. Therefore, do not use any accessories such as disc stabilizer rings or disc treatment sheets, etc., which may jam the changer mechanism.
CD Operation Finding a passage within a track During playback, press and hold 4 or ¢. ➜ The CD plays at a high speed. When you recognize the passage you want, release 4 or ¢. ➜ Normal playback resumes. Changing discs ●...
Tuning to radio stations Press POWER to on, then push FUNCTION to TUNER. Adjust BAND to select your desired waveband, AM or FM ST. Turn TUNING to tune to a station. - FM ST. lights up for stereo FM reception. To improve radio reception: ●...
Tape Recording General information on recording ● For recording, use only tape of IEC type I (normal tape). ● The recording level is set automatically, regardless of the position of the Volume, DBB and so forth. ● The tape is secured at both ends with leader tape.
Page 19
AMPLIFIER Output power ... 4 W total power ... 2 x 2 W RMS Signal-to-noise ratio ... ≥ 67 dBA (IEC) Frequency response ... 50 – 15000 Hz Impedance loudspeakers ... 8 Ω Impedance headphones ... 32 Ω -1000 Ω (1) (8Ω, 60 Hz –...
Page 20
Do not open the system as there is a risk of electric shock. If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to remedy a problem by following these hints, consult your dealer or Philips for help. Problem “no” is displayed.
Page 21
MAGNAVOX LIMITED WARRANTY Six (6) Months Free Product Exchange MAGNAVOX warrants this product against defect in material or workmanship, subject to any conditions set forth as follows: PROOF OF PURCHASE: You must have proof of the date of purchase to exchange the product.
