HooToo Dual Band AC1200 Router
ONLINE GUIDE
Model: HT-ND001
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-ND001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hootoo HT-ND001

  • Page 1 HooToo Dual Band AC1200 Router ONLINE GUIDE Model: HT-ND001...
  • Page 2: Table Of Contents

    Table of Contents Product Overview ......................4 Introduction ....................... 4 Package Contents ....................5 Product Diagram ..................... 6 LED Indicator ......................7 Physical Interface..................... 8 Connecting ........................8 Preparation ........................ 8 Hardware Connection ................... 9 PC TCP/IP Settings ....................10 For Windows ......................
  • Page 3 4.6.1 DHCP Server ....................41 4.6.2 DHCP List & Binding ................... 42 Virtual Server ......................43 4.7.1 Port Range ....................43 4.7.2 DMZ Settings ....................44 4.7.3 UPnP Settings ....................45 Security Settings ...................... 45 4.8.1 Client Filter ....................45 4.8.2 URL Filter ......................
  • Page 4: Product Overview

    1 Product Overview Thank you for choosing the HooToo HT-ND001 Dual Band AC1200 Router. Please read this manual carefully and keep it for future reference. Introduction The HT-ND001 Router supports both 2.4GHz and 5GHz wireless bands for up to 1200Mbps of total available bandwidth, as well as DHCP, PPPoE, and static IP Internet modes.
  • Page 5: Package Contents

    Package Contents HooToo Dual Band 1 x Ethernet Cable AC1200 Router (Model HT-ND001) 1 x Power Adapter 1 x User Guide...
  • Page 6: Product Diagram

    Product Diagram...
  • Page 7: Led Indicator

    LED Indicator The LED indicator displays information about the device status. Name Status What It Means Blinking The router is booting or upgrading. System LED Solid The router has booted. Power is off or the router is not booted. 2.4GHz wireless is on with data being Blinking transferred.
  • Page 8: Physical Interface

    Physical Interface Item Description Connect to a power socket via power adapter (output Supply Hub 12V, 1.5A). WAN Port Connect to the Internet. LAN Port Ports (1, 2, 3, 4) to connect a PC/Laptop. Press the button to connect to another router via WPS. WPS/RST Press and hold the button for 10 seconds for a device Button...
  • Page 9: Hardware Connection

    DHCP, PPPoE, or Static IP Internet Connection Type: 1. Ethernet Cable from the incoming Internet side (provided by your Internet service provider - ISP) 2. ISP Information: Your Internet service provider (ISP) should have provided you with all of the information needed to connect to the Internet.
  • Page 10: Pc Tcp/Ip Settings

    2.3 PC TCP/IP Settings Prior to logging onto the router, please make sure your computer is set "Obtain an IP address automatically" and "Obtain DNS server address automatically": 2.4 For Windows 1. Click Start and then select Control Panel. 2. Click Network and Internet.
  • Page 11 3. Click Network and Sharing Center. 4. Click Change adapter settings. 5. Click Local Area Connection and select Properties.
  • Page 12 6. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties. 7. Select Obtain an IP address automatically and click OK. 8. Click OK on the Local Area Connection Properties window to save your settings.
  • Page 13: For Mac Os

    2.5 For Mac OS 1. Enter the System Preferences page and select Network. 2. Select IPv4 as shown below: 3. Click Apply on the Network window to save your settings.
  • Page 14: Logging Into The Router

    3. Logging into the Router Log in To access the Router’s Web-based Utility, launch a web browser (such as Internet Explorer or Firefox) and enter http://10.10.10.252 into your browser address bar. Press “Enter”. The system will automatically display the login page. Please enter the correct password (default password is admin) and click the Login button or press “Enter”.
  • Page 15 Four sections categorized as below: Name Introductions Primary The navigation bar is organized in multiple tabs. Navigation Once a function menu has been selected from the navigation bar, the results will be displayed in Secondary the Configuration area. Navigation Configuration To configure and view settings.
  • Page 16: Commonly Used Webpage Elements

    3.3 Commonly Used Webpage Elements Common Introductions Elements To release the WAN IP address information. Release To obtain the WAN IP address information again. Renew To save the current configuration page. Save To cancel the current configuration page. Cancel To add settings to the list To delete the selected rules.
  • Page 17: Router

    WISP: In this mode, the AP will behave as client. The router function will also be added between the wireless WAN side and the Ethernet LAN side. Therefore, the WISP subscriber can share the WISP connection without the need for an extra router. 4.1.1 Router In Router mode, a wired connection can be made to an ADSL or Cable Modem via the WAN port to share the Internet to local wireless and wired...
  • Page 18: Wisp

    will automatically assign these values to you (includes the DNS server). PPPoE: Inquire with your ISP to make sure you can use PPPoE. Enter your username and password provided by your ISP. 3. In this setting, you can set the wireless name and wireless password for your local network.
  • Page 19 2. Click Open Scan to search Wi-Fi signal. Select your Wi-Fi and enter the password, then click NEXT. Set the pass phrase (password) for the Wi-Fi, then click the “NEXT” button...
  • Page 20: System Status

    4. You are configuring the device to work in WISP mode. If you have confirmed the settings, please click the “Save” button to reboot the device and activate the configurations. System Status This section includes the following: System Status, WAN Status, LAN Status, and Wireless Status.
  • Page 21: Wan Status

    Connected Number of DHCP clients. Clients System Version Router System Version. It indicates how long the router has been working Running Time since startup. Running time is reset when the device is powered off. Current system time on this device. The device System Time automatically synchronizes the system time with the Internet server time.
  • Page 22 Parameter Description Connection It displays the connection status. It displays Status “Connected” when connected to the Internet. IP address obtained from ISP. It connects to wide WAN IP area network. Subnet Mask Obtained from ISP. Generally 255.255.255.0. Gateway Obtained from ISP. Refers to the next router address.
  • Page 23: Lan Status

    4.2.3 LAN Status The Router LAN IP address (not your PC IP address). The IP Address default value is 10.10.10.252; you can change it when necessary. The Router LAN subnet mask. The default value is IP Mask 255.255.255.0. DHCP Server It displays DHCP Server on/off.
  • Page 24: Network Settings

    Working Mode It displays router wireless working mode. Wireless It displays wireless status (enabled/disabled). SSID Name Wireless name, you can set up it in. Security Mode Selected encryption way. BSSID MAC address of the device wireless interface Network Settings This section includes: LAN Settings, WAN Settings, WAN Speed, DNS Settings, MAC Clone, DHCP Server, DHCP Client List.
  • Page 25: Wan Settings

    Note: Default IP address and subnet mask are, respectively, 10.10.10.252 and 255.255.255.0. Make sure to keep track of any changes you apply to this page. If you change the Router LAN IP address, it is necessary to connect to the new IP address and log in again. Also, you have to set the default gateway addresses of all LAN PCs to this new IP address.
  • Page 26 PPPoE Configuration: Internet Connection Type: PPPoE. Username: ISP login name. Password: ISP login password. Click Save to save your settings. Note: MTU: The MTU (maximum transmission unit) is the largest data packet a network device transmits. The normal MTU value for most Ethernet networks is 1500 bytes, or 1492 bytes for PPPoE connections.
  • Page 27 Dynamic IP Dynamic IP Configuration: Connection Type: Dynamic IP. Click Save to save your settings. Note: An incorrect MTU value may cause Internet communication problems. For example, you may be unable to access certain websites, frames within websites, secure login pages, or FTP or POP servers. It is recommended to use the default MTU value.
  • Page 28: Mtu Application

    Application 1500 Typical for connections that do not use PPPoE or VPN. 1492 Used in PPPoE environments. Maximum size to use for pinging. (Larger packets are 1472 fragmented.) 1468 Used in some DHCP environments. 1436 Used in PPTP environments or with VPN. L2TP L2TP Configuration: 1.
  • Page 29: Mac Address Clone

    PPTP PPTP Configuration: 1. Connection Type: PPTP. PPTP Server/Username/Password: ISP information. Click Save to save your settings. Note: For the WAN IP address, Subnet Mask, Default Gateway, you can choose to either obtain automatically or manually enter the information provided by your ISP.
  • Page 30: Wlan Settings

    Restore Default MAC Router WAN MAC factory reset. Click this button to copy your PC MAC address onto the router. Also, you can manually enter the Clone MAC MAC address that you want to use. It is necessary to use a computer whose MAC address is allowed by your ISP.
  • Page 31: Security Settings

    Network Mode: Select a correct mode according to your wireless clients. SSID: This is the public name of your wireless network. BSSID: This is the MAC address of the device wireless interface. SSID Broadcast: This option allows you to have your network names (SSIDs) publicly broadcast/hidden.
  • Page 32: Advanced Settings

    Backup: Configure security mode, cipher type and security key (12345678). Click Save to save your settings. Security Mode: 1. Disable: If you want to allow all wireless clients to join your wireless network. WPA-Personal: WPA personal, support AES and TKIP cipher types. WPA2-Personal: WPA2 personal, support AES, TKIP and TKIP+AES cipher types.
  • Page 33: Wps Settings

    WMM (Wi-Fi Multimedia): Improved wireless multimedia data transmission (video or on-line demand). APSD: Power saver mode. Disabled as default. 4.4.4 WPS Settings To choose PIN or PBC for improved WiFi protection. 4.4.5 Access Control The Wireless Access Control is based on the MAC address of the wireless adapter to determine whether it communicates with the Router or not.
  • Page 34: Connection Status

    Select "Off" to disable this function. Select "Allow" or "Block" to enable this function. 4.4.6 Connection Status Here you can see a list of the wireless devices connected to the router. MAC Address: Shows the connecting PC's MAC address. Bandwidth: The width of channel frequency Note: The bandwidth refers to the channel bandwidth instead of wireless connection rate.
  • Page 35: Usb Settings

    4.5 USB Settings 4.5.1 Device Sharing Follow the steps below to connect a USB device to the router. 1. First, please make sure your USB device is FAT 32, then connect it to the router. 2. Power on the router, enter the IP address 10.10.10.252 to access the router web page.
  • Page 36 The reasons for this issue are as below: 1. The USB device is not formatted and incompatible with the router. Please format the USB device and restore to default FAT32 2. You are using a defective USB device; please use a fully functional USB device.
  • Page 37 For Windows: 1. Click on the Start menu on the left corner of your desktop, enter \\10.10.10.252 in the Search programs and files column. Note: In case your router IP address has been altered, i.e. 192.168.10.1, please enter the modified IP address following its exact format: \\192.168.10.1 2.
  • Page 38 For MacBook: 1. Click Finder, select Connect to Server; you will be directed to below page, enter smb://10.10.10.252. In case your IP address has been altered, please use the new IP address. When done, click Connect. 2. Enter the preset User Account (user name and password) on USB Settings page, click Connect to enter the directory of the USB drive.
  • Page 39: Media Server

    Please Note: 1. The user name and password should be consistent with the preset info on the User Accounts page. 2. Once the share function is activated, all the data on the USB device will be synched to the public folder of the router. Please be careful with data security.
  • Page 40: Print Server

    4.5.3 Print Server You can configure the print server for the network on this page. Print Server: Indicates the current Enable/Disable status of the Print Server. Printer Name: Name of printer connected to the router 4.5.4 User Account You can specify the user name and password for Storage Sharing and FTP Server users on this page.
  • Page 41: Dhcp Server

    4.6 DHCP Server 4.6.1 DHCP Server Here you can change the DHCP IP address pool and lease time. DHCP Server Configuration: 1. DHCP Server: Enable/disable the DHCP server. 2. Start IP/End IP: Specify Start/End IP addresses of the IP address pool. These addresses should be part of the same IP address subnet as the router LAN IP address.
  • Page 42: Dhcp List & Binding

    4.6.2 DHCP List & Binding Here you can view the DHCP dynamic client list: host name, IP address, MAC address, and lease time information. Note: 1. You can know whether there are unauthorized connections by viewing the client list. 2. You can specify a reserved IP address for a PC in the LAN. That PC will always receive the same IP address each time it accesses the DHCP server.
  • Page 43: Virtual Server

    4.7 Virtual Server 4.7.1 Port Range Port range allows you to share resources on your PC with your friends who are not in your LAN. By default, the router's firewall blocks inbound traffic from the Internet to your computer except for the replies to the outbound traffic.
  • Page 44: Dmz Settings

    Note: Make sure your WAN IP address (Internet IP address) is a public IP address. Private IP addresses are not routed on the Internet. Make sure you enter the correct service port numbers. To ensure that your server computer always has the same IP address, assign a static IP address to your PC.
  • Page 45: Upnp Settings

    4.7.3 UPnP Settings UPnP (Universal Plug and Play) feature allows a network device to discover and connect to other devices on the network. At the current date, it is only supported by Windows XP and Windows 7 or later. Note: The UPnP feature is enabled by default.
  • Page 46 You can set the access restriction parameters (e.g. a fixed IP range, times, and days) and set the client filter by following the steps below. 1. Power on the router and enter the router gateway 10.10.10.252 (password: admin) in the browser to log onto the router’s web page. 2.
  • Page 47 4. On the menu, click Security Settings and select Client Filter to access its page. Tick the Enable box to turn on the Client Filter function. 5.Follow Step 4 to configure the parameters. When all are done, click Save. Parameter configuration details are as below: 1)...
  • Page 48: Url Filter

    7) Type: Protocol type, including TCP, UDP, and Both. In normal cases, TCP is selected. 8) Time: Set the timeframe of the access restriction as needed. 9) Day: Tick to select a specific day, every day, or none (Options: Everyday, SUN, MON, TUE, WED, THU, FRI, SAT). 6.When above settings are configured, restart the DUT.
  • Page 49 3. Click System Tools on the menu, select Time Settings, sync the System Time with the Customized Time. 4. On the menu, click Security Settings, select URL Filter to enter its page. Tick “Enable” to activate the URL Filter function.
  • Page 50: Mac Filter

    5.Configure each parameter in Step 4. After the configuration is done, click “Save”. Parameter configuration details are as below: 1) Policy Number: Items to be configured, selectable from 1 to 10. 2) Access Policy: Tick to enable Access Policy; un-tick to disable. 3)...
  • Page 51 You can set the access restriction parameters (e.g. the fixed IP range, times, and days), you can set the filter through the steps below. 1. Log on the router web page via the gateway 10.10.10.252 (password: admin) after the router is normally powered on. 2.
  • Page 52 4. Click Security Settings to access the MAC Filter page. Tick “Enable” to turn on MAC Filter function. 5.Configure each parameter in Step 4. When done, click Save.
  • Page 53: Threat Prevention

    Parameter configuration details are as below: 1) Policy Number: Items to be configured, selectable from 1 to 10. 2) Access Policy: Tick to enable Access Policy; un-tick to disable. 3) Policy Name: Create a name for the policy. 4) MAC Address: The MAC address for wired and wireless internet connection.
  • Page 54 Set Steps: ① Click “Security Settings”. ② Select “Remote WEB”. Enter the Port. Click “Save” to confirm. ③ Enable: Check to enable the Remote Web Management feature. Port: The management port to grant external access. The default setting is 8080. This can be changed. Note: For better security, configure a port number (between 1025 to 65535) as remote web management interface.
  • Page 55: Wan Ping

    Set Steps: Management “Enable”. ① Enter the Port: 6060. ② Click “Save” to save your settings. ③ “http:// 172.16.87.160:6060” In the PC 210.16.87.154 Type into your browser’s address or location field and you can access the router at your home remotely. 4.8.6 WAN Ping The ping test is to check the status of your internet connection.
  • Page 56: Routing Settings

    Routing Settings Destination IP: The IP address of the final destination. "0.0.0.0" indicates any network segment. Subnet Mask: The subnet mask for the specified destination. Gateway: The next router on the same LAN segment as the router to reach. Metric: The number of routers between your network and the destination. Interface: The interface between your router and the final destination.
  • Page 57: System Tools

    Interface: To limit the uploading/downloading bandwidth in WAN port. Bandwidth Range: To specify the uploading/downloading Min/Max traffic speed (KB/s) - that cannot exceed WAN speed. 4.11 System Tools 4.11.1 Time Settings In order to select the time zone for your location. If you turn off the router, time zone settings reset to default.
  • Page 58: Backup/Restore

    4.11.3 Backup/Restore You can save the device settings onto your local hard drive to import them to your device at a later time in case a factory reset should be needed. Backup: Click this button to back up the router's configuration.Restore: Click this button to restore the router's configuration.
  • Page 59 Backup Configuration Procedures: 1. Click Backup 2. Click OK on the appearing window. Click Save on the File Download window. 4. Select a local hard drive to save the file and click Save.
  • Page 60 To Restore Configurations: Click Browse. Select the configuration file previously saved onto your local hard drive and click Open. Click the Restore button to reset your device to previous settings. Note: The default configuration file name is "RouterCfm.cfg". Include the file name suffix ".cfg"...
  • Page 61: Factory Reset

    Click the "Upgrade" button to browse for the latest firmware version. After the upgrade, the router will reboot automatically. 1. Get ready for firmware upgrade (Download the new firmware from the HooToo website or its support page and save it on your PC).
  • Page 62 2. After the router is powered, enter the router gateway 10.10.10.252 (password: admin) to log onto the router web page. 3. On the web menu, click System Tools to access the Firmware Upgrade page. Click the “browse” button to locate and select the downloaded firmware.
  • Page 63: Reboot

    4.11.6 Reboot Reboot the router to activate new settings or to change the current settings in cause of setting failure/software freeze. 4.11.7 Change Password The default password is "admin". We recommend you change it in order to increase security. Old Password: The first time you use the router, enter admin. If you already changed it and unfortunately forgot it, restore the router to factory defaults.
  • Page 64: System Log

    4.11.8 System Log The section is to view the system log. Click the "Refresh" button to update the log. Click the "Clear" button to clear all information. The log will clear automatically once reached 150 records. 5 FAQs 1. Q: I cannot access the device management interface. What should I do? ...
  • Page 65: Factory Default Settings

    3. Q: My computer shows an IP address conflict error after connecting to the device. What should I do?  Make sure there are no other DHCP servers on your LAN/no DHCP servers are disabled.  Make sure the device LAN IP address is not used by other devices on your LAN.
  • Page 66 device's MAC address) 802.11 Mode 11b/g/n mixed Mode SSID Broadcast Enabled Channel 2437MHz(Channel 6) Channel Bandwidth 20/40 Extension Channel 2437MHz(Channel 10) Wireless Security Disabled Wireless Access Disabled Control Country America Wireless Enabled HT_XXXXXX (where XXXXXX is the SSID last six characters in the device's MAC address) 802.11 Mode 11a/an/ac mode...
  • Page 67 Warranty HooToo products are covered by a 12 month limited warranty from the date of its original purchase. If any problems occur, please contact our support team. We can only provide after sales service for products that are sold by HooToo or HooToo authorized retailers and distributors.
  • Page 68 Tech Support: 408-627-7503 (Monday-Friday: 9:00 – 17:00 PST) Address: 46724 Lakeview Blvd, Fremont, CA 94538 EUROPE E-mail: support.uk@hootoo.com (UK) support.de@ hootoo.com (DE) support.fr@ hootoo.com (FR) support.es@ hootoo.com (ES) support.it@ hootoo.com (IT) EU Importer: ZBT International Trading GmbH, Lederstr 21a, 22525 Hamburg, Deutschland ASIA PACIFIC E-mail: support.jp@hootoo.com (JP)
