Dynorbital X51 Safety, Operation And Maintenance Manual

Dynorbital
Random Orbital Sander Series
Safety, Operation and Maintenance – Save This Document and Educate All Personnel
Model Pad Type
X51
Vinyl-Face
X51H
Hook-Face
X51V
X52 Vinyl-Face
X52H
Hook-Face
X52V
X61 Vinyl-Face
X61H
Hook-Face
X61V
X62
Vinyl-Face
X62H
Hook-Face
X62V
SANDER / POLISHER
Find The Most Current Offering of Support Documents and Accessories at www.Dynabrade.com
Read and understand this tool manual before operating your air tool. Follow all safety rules for the protection of operating personnel as
well as adjacent areas. Always operate, inspect and maintain this tool in accordance with the American National Standards Institute (ANSI).
Safety Requirements for abrading materials with coated abrasive systems – ANSI B7.7, Compressed Air and Gas Institute (CAGI) Safety
Code for Portable Air Tools – B186.1, Code of Federal Regulation – CFR 29 Part 1910, International Organization for Standardization (ISO)
Hand Held Non-Electric Power Tools – Safety Requirements and applicable State and Local Regulations.
Read and understand tool manual before work starts
to reduce risk of injury to operator, visitors, and tool.
Ear protection to be worn when exposure to sound,
exceeds the limits of applicable Federal, State or
local statues, ordinances and/or regulations.
Respiratory protection to be used when exposed to
contaminants that exceed the applicable threshold
limit values required by law.
Some dust created by sanding, grinding, drilling, and other construction activities contain chemicals known to cause cancer, birth defects
or other reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated lumber
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
Carefully Read and Understand the General
and Sander/Polisher sections found in Tool
Safety and Operating Guidelines (PN00001676)
Before Handling or Using Tool.
Tool Intent: Dynorbital ®
including wood, metal, plastic, fiberglass, solid surfaces, composites, rubber, glass and stone.
DO NOT USE Tool for Anything Other Than Its Intended Applications.
Training: Proper care, maintenance, and storage of your air tool will maximize tools performance and reduce chance for accident.
Employer's Responsibility: Provide operators with safety instructions and training for safe use of tools and accessories.
Report to Your Supervisor any Condition of the Tool, Accessories or Operation you Consider Unsafe.
Extreme
®
Pad Dia. Orbit Dia.
Non-Vacuum
3/16"
(5 mm)
Central Vacuum
5"
(127 mm)
Non-Vacuum
3/32"
(2.5 mm)
Central Vacuum
Non-Vacuum
3/16"
(5 mm)
Central Vacuum
6"
(152 mm)
Non-Vacuum
3/32"
(2.5 mm)
Central Vacuum

SAFETY and OPERATING INSTRUCTIONS

Extreme Random Orbital Sanders are used for sanding and finishing a variety of materials
Vacuum
WARNING
Eye protection must be worn at all times, eye
protection to conform to ANSI Z87.1.
Practice safety requirements. Work alert, have proper
attire, and do not operate tools under the influence
of alcohol or drugs.
Air line hazard, pressurized supply lines and flexible
hoses can cause serious injury. Do not use damaged,
frayed or deteriorated air hoses and fittings.
Carefully Read all instructions before operating or servicing
any Dynabrade ® Abrasive Power Tool. Products offered by
Dynabrade are not to be modified, converted or otherwise
altered from the original design.
PD17.01
February, 2017
X51
