NOTE: This one-page document is intended only as a quick reference for installation – please read
the SP Controls Application Note for a complete description of this projector driver prior to installation.
I. Driver Features
1. Input Selection Mapping
Selection 1:
VIDEO
Selection 2:
S-VIDEO
Selection 3:
RGB
Selection 4:
NETWORK
2. Hidden Function Mapping (Default Configuration)
Using the ON button as a shift key, press the following buttons to access the specified projector features.
Selection 1:
AV MUTE
Selection 2:
ENTER
Selection 3:
ADJUST LEFT
Selection 4:
ADJUST RIGHT
Off:
MENU
Volume Up:
ADJUST UP
Volume Down:
ADJUST DOWN
3. Other Driver Features
Power Status Feedback Method
Control Wiring:
II. Wiring Specifications
NOTE: The Panasonic PT-LB10VU projector serial port is a female 8-pin mini-DIN. This document
provides instructions for terminating the RS-232 control cable directly onto an 8-pin mini-DIN connector. If
you wish to terminate the control cable on a standard DB9 connector, an adaptor cable may be
separately ordered from Panasonic (Panasonic part no. ET-ADSER).
1. RS-232:
Wire the Panel RS-232 port to a male 8-pin mini-DIN as follows:
RX to
5
TX to
3
GND to
4
Connect this male DB9 to the projector port labeled SERIAL.
2. Infrared Emitter:
Wire the Panel IR/Serial port to a female 1/8" Mini as follows:
IR/SER to
tip
GND to
ring
Connect to the included IR Emitter and attach the emitter bud to any projector IR window.
03/28/05
RS-232 Power Polling
RS-232 and IR-Emitter
SP Controls reserves the right to modify specifications without notice at any time.
Quick Start Reference Sheet
Panasonic PT-LB10VU
Revision A
