CLUB SERIES 45 DEGREE
BACK EXTENSION
End of Life
ASSEMBLY INSTRUCTIONS
Part # 7320201
1
Revision: 11/18/02
Rev. C

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS45X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Life Fitness CS45X

  • Page 1 CLUB SERIES 45 DEGREE BACK EXTENSION End of Life ASSEMBLY INSTRUCTIONS Part # 7320201 Revision: 11/18/02 Rev. C...
  • Page 2: Parts List

    PARTS LIST DESCRIPTION PART # PART # DESCRIPTION FRAME ACU04-0001 ACUP05-0007 5/16 X 1/2” SHOULDER BOLT HIP PAD ADJUST ACU04-0002 DA1C03806216NU 3/8 X 62mm BOLT SUPPORT FRONT DA1C03809316NU ACU04-0003F 3/8 X 93mm BOLT ACU02-0002 FOOT PLATE DB2E03807200U 3/8” LOW HEIGHT LOCK NUT HIP PAD ACUP07-0001 DC120010510B...
  • Page 3 11 3/8 X 62mm BOLT 9 3/8 X 77mm BOLT 12 3/8 X 93mm BOLT 8 3/8 X 66mm FLAT HEAD BOLT 10 5/16 X 1/2” SHOULDER HEAD BOLT 3/8” RH WASHER RH CAP (WHITE/PLATINUM) 3/8” SAE 3/8” LOW WASHER HEIGHT LOCK...
  • Page 4 FIGURE 1 3/8 X 93mm 12 STEP 1: • SECURELY assemble the FRONT and REAR SUPPORTS (3 & 7) to the FRAME (1) using eight RH CAPS (16), four 3/8 X 93mm BOLTS (12), eight 3/8” SAE WASHERS (14), eight 3/8” RH WASHERS (15) and four 3/8” LOW HEIGHT LOCK NUTS (13) as shown in FIGURE 1.
  • Page 5 FIGURE 2 3/8 X 66mm FLAT HEAD 8 SPRING PIN 11 3/8 X 62mm STEP 2: • SECURELY assemble the HIP PAD ADJUST (2) to the PAD ADJUST (6) using four RH CAPS (16), two 3/8 X 62mm BOLTS (11), four 3/8”...
  • Page 6 FIGURE 3 10 5/16 X 1/2” SHOULDER BOLT STEP 3: • SECURELY assemble one 5/16 X 1/2” SHOULDER BOLT (10) to the PAD ADJUST (6) as shown in FIGURE 3.
  • Page 7 FIGURE 4 3” 9 3/8 X 77mm SERIAL # LOCATION STEP 4: • SECURELY assemble the two HIP PADS (5) to the HIP PAD ADJUST (2) using four RH CAPS (16), four 3/8 X 77mm BOLTS (9), four 3/ 8” SAE WASHERS (14) and four 3/8” RH WASHERS (15) as shown in FIGURE 4. (Note the the direction of the hole pattern on pad.)
  • Page 8: Warranty Information

    CAUTION-PLEASE READ There is a risk assumed by individuals who use this type of equipment. To minimize risk, please follow these rules: 1. Inspect equipment daily. Tighten all loose connections and replace worn parts immediately. Failure to do so may result in serious injury. 2.
