Input and output connectors
CAMERA Triax (1)
CCU-700A: King type
CCU-700AP: Fischer type
COAX BNC type (1)
RCP/CNU REMOTE
8-pin multiconnector (1)
AUX REMOTE 8-pin multiconnector (1)
INTERCOM/TALLY/PGM
19-pin multiconnector (1)
TALLY: 24 V DC, TTL level,
or contact selectable
MIC REMOTE D-sub 15-pin (1)
INTERCOM REMOTE
D-sub 25-pin (1)
INTERCOM (front panel)
XLR 5-pin (1)
Supplied accessories
AC power cord (1)
Plug holder for the AC power cord (1)
4-pin connector (1)
19-pin connector (1)
Number plate (1 set)
Operation Manual (1)
Maintenance Manual (1)
Optional accessories
Triax cable
BKP-7931/7931P sub-encoder board
BKP-7900 expansion board
BKP-7311 SDI output board
BKP-7312 SDI input board
Recommended equipment
BVP-700/750/500/550-series Color Video Camera
RCP-700-series Remote Control Panel
MSU-700 Master Setup Unit
VCS-700 Video Selector
CNU-700 Camera Command Network Unit
CCA-5-3 (3m or 3.8 feet) and CCA-5-10 (10m or
32.8 feet) connecting cables
Design and specifications are subject to change
without notice.
9
