Summary of Contents for Toslon XBOAT 730
- Page 2 Preface As Yachting Electronic Co., Ltd is continuously improving this product, we retain the right to make changes to the product at any time which may not be reflected in this version of the manual. Please contact your dealer if you require any further assistance. It is the owner’s sole responsibility to install and use the instrument and transducers in a manner that will not cause accidents, personal injury or property damage.
- Page 3 Warranty 1) Warranty Period Yachting electronic warrants that its products, when properly installed and used will be free from defects in material and workmanship for the period of 24 months from the date of first purchase. For Distributors only, the Warranty Period shall run for an additional three (3) months to that stated for first retail customers.
-
Page 4: Table Of Contents
Contents Check the Content Boat instruction What’s the Speciality High reliability - DSS technology - Heavy load hooper system Easy to Maintain CCU box ESC box Intelligent Smart front light Smart tail light Smart power switch Water switch Battery Fix the battery Connection Battery charging Low battery alarm... -
Page 5: Check The Content
Check the content Bait boat Accessories Remote Remote Li-ion Battery and charger(optional) 1) Charge cable 2) Boat antenna (long) 3) Boat antenna (short) 4) Cable for Pb battery Note: the boat antenna (short) is only for backup using. With which the RC distance may only reach 100-150m Nylon bag Nylon... -
Page 6: Boat Instruction
Boat Instruction 1) Right light 9) Battery charging port 9) Battery charging port 17) Right hopper plate 17) Right hoppe 2) Right hopper 10) Screw for additional device 18) Left weeds protection plate 3) Handle 11) Antenna (for fishfinder) 19) Water switch 4) Clapboard 12) Left hopper 20) Right weeds protection plate... -
Page 7: What's The Speciality
What’s the speciality? TOSLON Xboat730 was well designed with innovative technology, including intelligent llight system, water switch, DSS waterproof, etc. These technology are all used to make the boat high reliability, easy to maintain and intelligent. High Reliability 1) DSS technology... -
Page 8: Easy To Maintain
Easy to Maintain All control system were designed into 2 boxes. No complex and disorganized wiring with PCB. ESC Box CCU Box 1) CCU box The CCU (Central Control Unit) box control Hoppers / Hook Release / Battery Monitor / Front light / Tail light / additional two channel OC output. - Page 9 Intelligent 1) Smart Front light (Unique !) Running-light composed by 2x30pcs hight brightness LED (Could be switch off by remote) Brightness of Spot light (2*1.5W) is controllable by the remote 2) Smart tail light (Unique !) The tail light was composed by 18pcs led wihch give out striking light at day or night.
-
Page 10: Battery
Battery Fix the Battery As shown in right figure, there are 2 battery support being fixed in the housing, which are used to hold the battery. Battery Support 1) for lead-acid battery Directly put the lead-acid battery into the battery support. 2) for Li-ion battery The Li-ion battery were packed into two seperate plastic box. -
Page 11: Battery Charging
Battery Charging Together with the boat accessories, there is an charge cable which is used to connect the battery charger to the boat. Note: this charger is recommend for PB battery charging only! For Li-ion battery, please use separate balance charger! Battery charger Charge cable Low Battery Alarm... -
Page 12: Operation
Operation Remote Following is an short instruction of the remote. For detailed function, please refere to the instruction manual of remote which is in the CD together with the bait boat manual. 1) Switch D (SwD) 6) Up/Down (rotate) 9) Switch A (SwA) 2) Knob B (VrB) Enter (press) 10) Right stick... -
Page 13: Running Instruction
Running instruction The right hand joystick is used to run the boat: go forward, reverse, turn left, spot turn left, turn right, spot turn left, etc... Go forward Go reverse Turn left Turn right Spot turn left Spot turn right Turn back left Turn back right... -
Page 14: Load And Dump The Bait
Load and dump the bait The left hand joystick is used to load and dump the bait. Release the left hopper Note: after the left hopper was released, the left part of tail light will twinkle Release the right hopper Note: after the right hopper was released, the right part of tail light will twinkle... -
Page 15: Load And Release The Hook
Load and release the hook The left hand joystick is used to load and release the hook. Hook holder Load the hook Most of the time, it is very easy to load the hook. Just insert your hook or line (through the pin) to the hook holder will be ok. Some times, if the hook is too bigger to be easily inserted in the hook holder, you may need the following steps: a) Push and hold the left hand joystick down, the pin will withdraw. -
Page 16: Turn On/Off The Light
Turn on/off the light For TOSLON Xboat 730, there are Spot light, daylight and tail light. All lights are remote controllable. Spot light Tail light Daylight Turn on/off the Spot light The knob B is used to turn on/off the spot light. -
Page 17: Trim The Motor
Trim the motor Lt is probable that the boat will not drive absolutely straight as a result of the rotation of water. Due to he pumps, differing loads, winds and water conditions, the motor trim knot of the remote control has little effect on either motor. So, continued correction by using the motor trim knot is therefore necessary for straight line running. -
Page 18: Specification
Specifications 2.4 GHz 6-channel remote control Radio R/C Range 500m to 1000m, depending upon environmental conditions Dimenslons 70cm*44cm*27cm Total weight 7.0kg (without batteries & bait) Hull Spec. Special handle design with rubber protection Special weeds protection Up to 5kg bait capacity / Volume total 5 Liter ( 2.5 liters per hopper ) Bait &...
