Adding Text to an Image

To type text:
1. Obtain an image, press Freeze
2. Press the TEXT key
3. Place green text cursor where you would like text
displayed
4. Enter text
Removing Text from an Image
 Pressing TEXT, then ESCAPE will remove text on a frozen image
 Pressing DELETE TEXT on keyboard will allow all text to be deleted
 Pressing DELETE LINE on Keyboard will delete text in the same line
Selecting Multiple Gestations
To Indicate Multiple Gestations:
1. Press CALIPER key
2. Roll TRACKBALL to top of Measurement menu to higlight SINGLE
3. Press SET
4. Select Single or Multiple from prompt box
5. Use TRACKBALL to select OK
6. Press SET
G20 Quick Reference
To Use Pre Programmed Text
1. Press TEXT
2. Press MENU
3. Use TRACKBALL to select the desired text from menu
list
4. Press SET
Page 3
