Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC.
Battery Installation and ESC Arming ..............7 * See the Flight Modes section for information concerning the availability of Acro Center of Gravity (CG) ..................8 mode in the RTF version of the X-VERT. Control Horn and Servo Arm Settings ..............8 Control Centering ....................8 Specifi...
Prefl ight 1. Remove and inspect contents. 9. Make sure linkages move freely. 2. Read this instruction manual thoroughly. 10. Perform the Control Direction Test with the transmitter. 3. Charge the fl ight battery. 11. Perform the stability system control direction test with the aircraft. 4.
Throttle (Up/Down) * The RTF version of the X-VERT is shipped with only Multirotor and Stability fl ight modes active. Flight mode switch positions 1 and 2 both access Stability Mode, indicated by the red LED on the fl ight control board. To access Acro Mode in the RTF version, see the Flight Modes section.
BNF Transmitter Setup The X-VERT™ aircraft requires a transmitter with a minimum of 6 channels Computerized Transmitter Setup with one 3-position switch and one momentary switch available. (DXe*, DX6e, DX6, DX7 (Gen2), DX8 (Gen2), DX9, DX18 and DX20) Flight Modes are controlled by channel 5 (GEAR).
Transmitter and Receiver Binding The transmitter included with the RTF version of this aircraft is pre-bound to the Binding Procedure receiver at the factory. If for any reason it becomes necessary to re-bind the transmitter to the receiver, follow the binding procedure in the table. 1.
Center of Gravity (CG) The CG location is within 126-136mm (measured forward from the trailing edge of the wing). CAUTION: Failure to confi rm the correct center of gravity may cause a loss of control and a crash. Crash damage is not covered under warranty. 126-136mm from the trailing edge Control Horn and Servo Arm Settings...
fl y the aircraft. Contact Horizon Product Support. Flight Modes Multirotor Mode (switch position 0) Accessing Acro Mode in the RTF X-VERT Vertical mode allows the aircraft to take off and land vertically. CAUTION: Acro mode is intended only for experienced pilots who have The fl...
Understanding the Primary Flight Controls The X-VERT aircraft is capable of both vertical, multirotor-style fl ight and forward, airplane-style fl ight. It is important to understand how the primary fl ight controls function and how the aircraft reacts in both fl ight modes. Take a few minutes to familiarize yourself with the controls prior to attempting your fi rst fl ight.
Page 11
Stability and Acro Forward Flight Modes Throttle Left side view Left side view Faster Slower Throttle up Throttle down Elevator Left side view Left side view Pitch down Pitch up Elevator down Elevator up Aileron Rear view Rear view Aileron right Roll right Aileron left Roll left...
Fly the aircraft and trim it for level fl ight per the In Flight Trimming section. ready for fl ight. The X-VERT fl ies in a very similar manner in forward fl ight to any other fi xed- Prior to arming, lower the throttle to the lowest setting. The aircraft will not arm wing aircraft.
After landing disconnect and remove the Li-Po battery from the aircraft to prevent How the LVC function is indicated is dependent on which fl ight mode is active. trickle discharge. Charge your Li-Po battery to about half capacity before storage. While in vertical mode, the motor power will decrease.
FPV System Installation (Optional) If you are operating this product in North America, you are required to have an Amateur Radio (HAM) license. Visit www.arrl.org for more information. Consult local laws and ordinances before operating FPV equipment. In some areas, FPV operation may be limited or prohibited. You are responsible for operating this product in a legal and responsible manner.
Page 15
Operating the FPV Mount Channel Selection: The FPV camera mount does not require any programming or additional channels 1. Channel 1 is indicated by the red LED glowing solid. in the transmitter. All functions are controlled by the fl ight control board on the 2.
Troubleshooting Guide Problem Possible Cause Solution Aircraft will not arm Throttle cut switch in the disarm position (position 1) Set the throttle cut switch to the arm position (position 0) Throttle not at idle and/or throttle trim too high Reset controls with throttle stick and throttle trim at lowest setting Aircraft will not re- Throttle servo travel is lower than 100% Make sure throttle servo travel is 100% or greater...
AMA National Model Aircraft Safety Code Effective January 1, 2014 A. GENERAL B. RADIO CONTROL A model aircraft is a non-human-carrying aircraft capable of sustained fl ight 1. All pilots shall avoid fl ying directly over unprotected people, vessels, vehicles in the atmosphere.
What this Warranty Covers Inspection or Services Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product If this Product needs to be inspected or serviced and is compliant in the country purchased (the “Product”) will be free from defects in materials and workmanship you live and use the Product in, please use the Horizon Online Service Request at the date of purchase.
Compliance Information for the European Union X-VERT RTF (EFL1800) X-VERT BNF (EFL1850) EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product EU Compliance Statement: Horizon Hobby, LLC hereby declares that is in compliance with the essential requirements and other relevant provisions of this product is in compliance with the essential requirements and the RED Directive.
Decal Placement Options / Aufkleber Optionen / Options de décalcomanie / Opzioni decalcomanie Air Force / Luftwaffe / Aviation / Air Force Top / Oben / Haut / Superiore Bottom / Unterseite / Bas / Inferiore Red Wave / Rote Welle / Vague rouge / Onda rossa Top / Oben / Haut / Superiore Bottom / Unterseite / Bas / Inferiore...
Page 21
Orange Delta / Orange Delta/ Orange Delta/ Delta arancione Top / Oben / Haut / Superiore Bottom / Unterseite / Bas / Inferiore Green Mech / Grüne Maschine / Machine verte / Macchina verde Top / Oben / Haut / Superiore Bottom / Unterseite / Bas / Inferiore...
