Four front panel keys are used as directional keys to navigate through the menus in setup mode (see Figure 3-3).
The ( ) and
UNITS PRINT
( ) move up and down (vertically) to different menu levels. The
GROSS/NET
for selecting parameter values within the menus.
Level 1
Parameter
Level 2
Parameter
Default value
When moving through values below the first menu level, press
above. Press to move to the next parameter on the level above.
To select a parameter, press
press to move down to the submenu or parameter you want. When moving through the menu parameters, the
default or previously selected value appears first on the display.
To change a parameter value, scroll left or right to view the values for that parameter. When the desired value
appears on the display, press
navigation keys to select the digit and to increment or decrement the value.
24 880 Installation Manual
UNITS
MENU GROSS
Figure 3-3. Five-Key Keypad Functions in Setup Mode
( ) keys scroll left and right (horizontally) on the same menu level;
Value Value
Figure 3-4. Setup Mode Menu Navigation
or to scroll left or right until the desired menu group appears on the display, then
to select the value and move back up one level. To edit numerical values, use the
0 0 0 0 0 0
When editing numeric values, press
Press or to increment or decrement the value of the selected digit.
After the number desired is displayed, press ENTER. The decimal point
will begin flashing if a decimal value is allowed. To move the decimal,
use or to move the decimal position. Press ENTER when done.
Figure 3-5. Editing Procedure for Numeric Values
