- Page 1 Hi(!)bility™ Bill Validator GPT ARGUS (B; D) Rev. 1.2 www.atronic.com January 2004...
-
Page 2: Release Info
ELEASE Bill Validator GPT ARGUS (B; D) Rev. 1.2 Rel. January 2004 © 2003 - 2005 Atronic. All rights reserved. January 2004... -
Page 3: Bill Validator
NTRODUCTION GPT Synergy Series ARGUS-B (G3) and ARGUS-D (G3) Bill Validator Features • Light weight, self contained assembly • Multi-Level High Security process • Side-Looking Sensors • LED illuminating runway lights • User selectable currency denomination accep- tance via host machine •... -
Page 4: Details Of Operation
ALIDATOR ANDLING Details of Operation 1. Validator power up a. The Service LED near the DIP-switch lights up. b. The validator stepper motor is initiated and runs for approx. 2 seconds. c. The stacker motor makes 2 or 3 cycles. d. -
Page 5: Technical Information
Protocol V2.2 The Argus Bill Acceptor and the Atronic machine comunicate via the V2.2 protocol. The Argus Bill Ac- ceptor uses the software information supplied by the Atronic machine to determine how the validator is to be set. January 2004... -
Page 6: Maintenance
Any changes to the DIP- switches during operation will have no effect until the next power up. In Atronic machines only 3 DIP-switches are in use. Changes to the bill acceptance table are made via host machines Menu Setup. - Page 7 ALIDATOR ANDLING Cleaning the ARGUS Validator Depending on its environment and amout of use, the Argus Bill Validator may require periodic cleaning to restore the unit to optimum performance. Under nor- mal use, it should be cleaned every 6 month. For unusual operating conditions more frequent cleaning will be required.
- Page 8 GPT G2 unit (with short instuction printed on the card) or other cards. Note: Do not use damaged or soiled VLA cards for this test. Please ask Atronic Technical Service to get a new matching VLA card. VLA procedure Note: If a software update needs a hard boot, per- form this procedure directly after software upload.
- Page 9 ALIDATOR ANDLING Bezel LED displays at normal operation Idle State: Validator is operational and ready to accept a bill. • Each pair of green LEDs sequentially flash at 4 Hz (Runway lights) • Red LED is not lit Accepting State: A bill is inserted into the bill validator.
- Page 10 ALIDATOR ANDLING Troubleshooting Chart y l l y l l ´ r . l l l l i l l i . l l l l i January 2004...
