WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
FCC COMPLIANCE STATEMENT INFORMATION TO THE USER : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.
Page 5
IR illuminators are available. The IP cameras are fully compatible with all ViconNet® systems; its ONVIF certification provides an open-platform for integration into other video management systems.
2. Installation For the network camera to operate, it is necessary to connect a network cable for data transmission and power connection from supplied power adapter. Depending on operation methods, it is possible to also connect an alarm cable. 2.1 Overview Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory.
Page 7
Note: Failure to thoroughly coat threads will result in moisture entering the housing and eventual failure of the unit.
Page 8
Note: For outdoor installations, Vicon recomm ends that th e vent plug should only be used if fogging conditions exi st. Addition ally, if the side cable acce ss hole i s used , the b ase m ust be m ounted so the hole is pointed directly downward.
Page 11
See the diagrams below for the exact dimension of the network camera dome.
Page 12
2.2 Connections Connection Description Set to NTSC by default Item Description Ethernet, RJ-45 port compatible 1 RJ-45 with 10/100Mbps PoE Modular Jack DC Jack Main Power, DC Jack, DC12V AI: Alarm In G: GND Alarm input and output, 3pin terminal AO: Alarm Out MIC: Audio In Audio line input, 2pin terminal...
Page 13
• Connecting to the RJ-45 Connect a standard RJ-45 cable to the network port of the network camera. Generally a cross-over cable is used f or directly c onnection t o P C, while a direct cable is used f or connection to a h ub.
2.3 Network Connection and IP assignment The network camera is designed for use on an Ethernet network and requires an IP address for access. Most networks today have a DHCP server that automatically assigns IP addresses to connected devices. By the factory default, your camera is set to obtain the IP address automatically via DHCP server.
2.4 Resetting to the Factory Default Settings To reset the network camera to the original factory settings, go to the Setup > System > Maintenance web page (described in “System > Maintenance” of Users Manual) or use the Reset button on the network camera, as described below: •...
