Description - Pelltech PV1000agri User Manual

PV1000agri pellet burner

Description

3/ 50
p
Main components
2 Description
PV1000Agri is a pellet burner that is intended to be used with 6 or 8mm wooden pellets. Due to the
unique design of the burning chamber you can use industrial pellets to fuel the burner. You cannot use
any other form of fuel to run this burner.
The construction of the burner allows it to be used with different boilers: liquid fuel, solid fuel and
universal boilers. The burner is connected to the boiler using a connection plate.
The burner is equipped with a safety thermostat, a melting hose, temperature sensor, sprinkler system
(optional) and auxiliary battery for protection against back-burning.
DK9401A1
www.pelltech.eu
