USER'S MANUAL
PS110 USA
Electronic Postage Computing Scale
BASIC SERVICES AVAILABLE
First Class Mail
o
Priority Class (Local and Zones 1 to 8)
o
Packages (Local and Zones 1 to 8)
o
Media Mail
o
Domestic Express Mail (Post Office to Addressee)
o
Global Express Mail(Canada, Mexico, UK, Japan, and China)
o
International Airmail Letter (Canada, Mexico, and rate groups 3 to 5)
o
SPECIAL SERVICES AVAILABLE
Registered Mail
o
Certified Mail
o
Return Receipt/Return Receipt for Merchandise
o
SPECIAL FEATURES
1. Instant selection for Canada or Mexico destinations.
2. Tare Function
3. Domed Keyboard for Tactile Response.
4. Strain Gauge Loadcell Technology.
5. Easily Replaceable Plug-in Rate Change Chip.
BASIC TECHNICAL DETAILS
Maximum Capacity
Accuracy
Power Supply
Power Consumption
Minimum add Weight
Minimum Weight
Dimensions/Weight
Platform
Unit Weight
Packaged Weight : 2 lbs. 4 oz.
Tare
: 5 lbs (Including Tare)
: 0.1 oz.
: 9 volt AC adapter - UL rated.
: Approx. 400mW
: 0.1 oz.
: 0.2 oz.
: Overall: 7¾" × 5½" × 2¼"
: 5" × 5½" (opens for flats)
: 1 lb. 2.8 oz.
: Unlimited (up to scale's maximum capacity)
Advertisement
Related Manuals for Elane PS110 USA
Summary of Contents for Elane PS110 USA
- Page 1 USER'S MANUAL PS110 USA Electronic Postage Computing Scale BASIC SERVICES AVAILABLE First Class Mail Priority Class (Local and Zones 1 to 8) Packages (Local and Zones 1 to 8) Media Mail Domestic Express Mail (Post Office to Addressee) Global Express Mail(Canada, Mexico, UK, Japan, and China)
- Page 2 A. START-UP INSTRUCTIONS Place the scale on a flat surface. Plug AC adapter (included) into the PS110 USA scale (port at back of unit) and then into standard electrical outlets. The PS110 USA scale will automatically turn on and perform a self test with automatic Tare.
- Page 3 . POSTAL SELECTIONS 1. First Class/Priority The Scale automatically sets up to weigh 1st Class after going through its self-test. The Scale will automatically switch from 1ST Class to Priority for any piece over 13 oz. NOTE: RATES FOR PRIORITY MAIL MAY VARY DEPENDING UPON THE ZONE OF DESTINATION. Before transition to Priority Mail, the user is a sked to input the zone.
- Page 4 Plug the main adapter to the power supply. The scale will turn on and display ©Elane then Selftest. Press the CAN/4 key while it displays Selftest. The scale will then ask you to put a 1-oz weight followed by 5-lb weight on the platform.
