50CC SKY LINK
50CC SKY LINK
50cc gasoline engine
Requires : 6-channel radio w/ 9 high torque servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
A306PO31741705
Specifications
108 in / 2745 mm
1575 sq in / 101.6 sq dm
21 Ib / 9.5 kg
84.5 in / 2145 mm
*Specifications are subject to change without notice.*
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF)SERIES
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for The World Models Manufacturing 50CC SKY LINK
Summary of Contents for The World Models Manufacturing 50CC SKY LINK
- Page 1 INSTRUCTION MANUAL 50CC SKY LINK 50CC SKY LINK 50cc gasoline engine Requires : 6-channel radio w/ 9 high torque servos Specifications Wing Span 108 in / 2745 mm Wing Area 1575 sq in / 101.6 sq dm Flying Weight 21 Ib / 9.5 kg Fuselage Length 84.5 in / 2145 mm...
-
Page 2: Before You Begin
50CC SKY LINK 50CC SKY LINK INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.12 SAFETY PRECAUTIONS P.13 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 9. SOCKET HEAD SCREW M5x50mm -- 4 pcs PUSHROD Ø1.8x480mm (For Throttle) -- 1 pc. 2. SOCKET HEAD SCREW M4x60mm -- 4 pcs PLASTIC TUBE d2xD3x160mm (For Throttle) -- 1 pc. SCREW PWA2x8mm -- 24 pcs WASHER d5xD12mm -- 4 pcs M4 NYLOON INSERT LOCK NUT -- 4 pcs M5 BLIND NUT -- 4 pcs... - Page 4 Main Wing Aileron Servo Lead Pre-glued Bottom View Aileron & Flap Servos Socket Head Screw M4x60mm Lamp Cover M2x8mm Socket Head Screw PL4120300 PWA2x8mm Screw Signal Lamp PWA2x8mm Nylon Insert Lock Nut 1.5mm M2 Nut M2 Nylon Insert Lock Nut Heavy Duty Clevis Signal Lamp Wire Lead...
-
Page 5: Elevator Pushrod
Stabilizer & Elevator d3xD7mm Washer PA3x12mm Screw PA3x12mm Stabilizer Tube Ø 9.6 x 521mm Washer 3xD7mm 2.5mm Pre-glued PA3x12mm d3xD7mm Washer 2.5mm Completed Elevator Pushrod Socket Head Screw M4x55mm Heavy Duty Servo Horns ( w / Bearing) Nylon Insert Lock Nut PL4120300 M2 x 10mm M2 Nylon... -
Page 6: Rudder Pushrod
Vertical Fin & Rudder Signal Lamp Signal Lamp Wire Lead Vertical Fin`s Wing 6x65x85mm Pre-glued Rudder Pushrod M2x8mm Socket Head Screw PL4120300 Screw PWA2x8 mm C’ Socket Head Screw M4x60mm Nylon Insert Lock Nut 1.5mm C=C’ M2 Nut M2 Nylon Insert Lock Nut PWA2 x 8mm Rudder Pushrod... - Page 7 Front Landing Gear Collar M3 x 3mm M3 x 3mm 5.6 mm Set Screw Set Screw Set Screw M4x4mm 5.6 mm Collar Screw PA3x25mm 5.6 mm Collar Screw Wheel Ø100mm PA3x30mm Wheel Pant M4 x 4mm Set Screw M4 x 4mm M4 x 4mm Set Screw Set Screw...
-
Page 8: Main Landing Gear
Main Landing Gear M5x25mm Socket Head Screw Wheel Ø118mm M3x3mm M5x65mm Set Screw Socket Head Screw d5xD12mm Washer M3x10mm Socket Head Screw M5x65mm PWA3x8mm Screw Plate 1mm d5xD12mm Washer M5 Nut 5.1mm Collar 5.1mm Collar Front M3x 10 mm M5 x 25 mm d5 x D12 mm Washer Main Landing... -
Page 9: Fuel Tank
Fuel Tank Cable Tie Double-sided Tape 1.5x8x500mm Instrument Panel 40x160mm Fuel Tank 800cc Completed Servo Set 3x3mm Set Screw 3x3mm Set Screw Throttle Pushwire Linkage Connector Washer M2 Nut Washer 1.5mm 2mm Washer Throttle Servo. M2 Nut Please refer to the attached sheet for linkage connector installation. Radio Equipment Install and arrange the servos as shown in the diagram. - Page 10 Canopy Pilot Mounting Plate PM2x12mm M2 Nylon Screw PM2x12mm Insert Lock Nylon Insert Lock Nut Pilot Statues Completed Cowling First insert the grommet to the cowling then apply screw. Please refer to the attached sheet for usage of the transparent 3D template. Screw Quick Release Nylon Rivet PA3x12mm...
- Page 11 Main Wing Set Screw x 8mm Wing Tube Ø Lead to Aileron Servo 25.4 x 917mm Wire Ø0.8mm Set Screw M3x8mm Wing Tube Ø 14.5 x 907mm Self Tightening Set Screw M3X8mm Wing Latch Completed Wing Tube PWA2x8mm Wing Struts Socket Head Screw M3x16mm Screw...
- Page 12 Antenna & Ornament Screw PA2x12mm PA2x12mm Ornament Ornament Aileron Ornament Completed Elevator P.11 A306PO31741705...
- Page 13 Decals Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can Rudder adjust according to your personal preference. 35mm 35mm Elevator 30mm 30mm Flaps (near fuselage) 60mm Ailerons (away from fuselage) 20mm 20mm The ideal C.G.
- Page 14 # First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. 50CC SKY LINK 50CC SKY LINK 50 c.c. gasoline is specially designed to be powered by engine, using a more powerful engine does not mean better performance.
- Page 15 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 16 Product Registration Form (US Customers) We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to AirBorne Models, 4749-K,Bennett Drive, Livermore, CA 94551 USA. 1.
- Page 17 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
-
Page 18: Optional Parts
Optional Parts ACCESSORIES) Clevis Wrench 180mm Extension Code No. Size Package Code No. Size Package PL8210010 1 set KW0011800 180mm 1 set Small Clevis Large Clevis Special tool for clevis installation. Suitable for standard and small (EP) clevis. 180mm Y-Cord Code No. - Page 19 A306PO31741705...
- Page 20 A306PO31741705...
