MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015)
Suspensions
Check the continuity of the yellow-red cable be-
tween the pressure switch connector and the fuse
box (7.5A fuse No. 11) and between the remote
control base and the fuse box (7.5A fuse No. 11).
With a multimeter, also check the pressure switch
operation as well as the continuity at rest as this is
normally closed switch.
Rear

Removing the rear wheel

Before removing the rear wheel, support the vehi-
cle properly and operate the parking brake so as
to facilitate removing the wheel fixing screws.
- Remove the exhaust silencer.
- Undo the screw fixing the right shock absorber to
the clamp.
- Remove the cotter pin and collect the cap.
- Unscrew the wheel fixing nut and collect the
spacer.
SUSP - 343
