Register your product and get support at
www.philips.com/welcome
EN User manual
FR Manuel d'utilisation
ES Manual del usuario
MODEL NUMBER
EN: For further assistance, call the customer support service in your country.
To obtain assistance in the U.S.A., Puerto Rico, or the U.S. Virgin Islands, contact Philips
Customer Care Center at 1-866-771-4018
To obtain assistance in Canada, contact Philips Customer Care Center at:
1-800-661-6162 (French speaking)
1-866-771-4018 (English speaking)
To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 504 6200
Enter below the model and serial numbers located on the back and right side of the TV cabinet.
FR: Pour obtenir de l'aide supplémentaire, communiquez avec le centre de service à la clientèle de
votre pays.
Pour obtenir de l'aide aux États-Unis, à Puerto Rico ou aux Îles Vierges américaines,
communiquez avec le centre de service à la clientèle Philips au : 1-866-771-4018
Pour obtenir de l'aide au Canada, communiquez avec le centre de service à la clientèle Philips
au :
1-800-661-6162 (pour un service en français)
1-866-771 4018 (pour un service en anglais)
Pour obtenir l'aide au Mexique, entrez en contact avec le centre de soin de client de Philips à
01 800 504 6200
Entrer ci dessous le modèle et le numéro de série situés dérrière à droite sur le dos du téléviseur.
ES: Para obtener más información, llame al servicio de soporte al cliente de su país.
Para obtener asistencia en los Estados Unidos, Puerto Rico o en las Islas Vírgenes de los
Estados Unidos, comuníquese con Centro de atención al cliente de Philips al 1-866-771-4018
Para obtener asistencia en Canadá, comuníquese con Philips Customer Care Center al:
1-800-661-6162 (en francés)
1-866-771-4018 (en inglés)
Solo para Mexico CENTRO DE ATENCIÓN A CLIENTES LADA.
Para México.
Escriba a continuación el modelo y número de serie que estan localizados en lado derecho y parte
posterior de el gabinete de el televisor.
SERIAL NUMBER
32PFL3514D
32PFL3504D
42PFL3704D
01 800 504 6200 Solo

Advertisement

Table of Contents
loading

Summary of Contents for Philips 32PFL3504D

  • Page 1 1-866-771 4018 (pour un service en anglais) • Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips à 01 800 504 6200 Entrer ci dessous le modèle et le numéro de série situés dérrière à droite sur le dos du téléviseur.
  • Page 2: Table Of Contents

    Contents 1 Notice 2 Important Product Information Screen Care Environmental Care Regulatory Notices 3 Your TV Side Controls and Indicators Remote Control 4 Get Started Position the TV Insert the Remote Control Batteries Connect the Antenna or Cable Connect the AC Power Cord (Available for 42PFL3704D only) Manage Cables Switch on and Set Up the TV...
  • Page 3 Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
  • Page 5: Notice

    Warranty No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only be done by Philips Service Centers and offi cial repair shops. Failure to do so shall void any warranty, stated or implied.
  • Page 6: Important

    2 Important Registering your model with Philips makes you eligible for all of the valuable benefi ts listed below, so don’t miss out. Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to ensure: •...
  • Page 7: Your Tv

    3 Your TV Congratulations on your purchase, and welcome to Philips! To fully benefi t from the support that Philips offers, register your product at www.philips.com/welcome. Side Controls and Indicators 32PFL3504D / 32PFL3514D 42PFL3704D a Standby indicator / remote control sensor b .
  • Page 8 c FORMAT Selects a picture format (see ‘Change picture format’ on page 16). d SAP Digital Mode (DTV) • Press to select the audio language. Analog Mode (TV) • Press to select the audio mode. e FREEZE Press to pause screen image. f OK Activates a selection or accesses the menu.
  • Page 9: Get Started

    There is a Kensington security slot on the back of the TV. Prevent theft by looping a Kensington lock between the slot and a permanent object, such as a heavy table. 32PFL3504D / 32PFL3514D 42PFL3704D Insert the Remote Control Batteries Slide the battery cover off the back of the remote control.
  • Page 10 Connect a set-top box through RF IN/OUT If the TV is connected to a cable box or satellite set-top box via a coaxial connection, set the TV to channel 3 or 4, or to the channel specifi ed by the service provider. 32PFL3504D / 32PFL3514D 42PFL3704D...
  • Page 11: Connect The Ac Power Cord (Available For 42Pfl3704D Only)

    Connect a set-top box through component video input or HDMI 32PFL3504D / 32PFL3514D Connect the AC Power Cord (Available for 42PFL3704D only) Warning • Verify that your power voltage corresponds with the voltage printed at the back of the TV. Do not insert the AC power cord if the voltage is different.
  • Page 12: Manage Cables

    TV. The holder helps keep your cables tidy and easily manageable. Attach the cable holder as illustrated below. 32PFL3504D / 32PFL3514D 42PFL3704D Keep the cable through this holder to avoid tangle them. 32PFL3504D / 32PFL3514D...
  • Page 13: Switch On And Set Up The Tv

    Switch on and Set Up the TV Before you switch on the TV, check that the AC power cord is properly connected. Press . POWER at the right side of the TV, or press . on the remote control. The TV normally takes 25-30 seconds to start up and the following screen appears the fi...
  • Page 14: Use Your Tv

    5 Use Your TV This section helps you perform basic TV operations. Switch Your TV on/off or to Standby 32PFL3504D / 32PFL3514D 42PFL3704D To switch on Press . POWER at the side of the TV. • Press . (Standby-On) on the remote control.
  • Page 15: Adjust Volume

    Adjust Volume 32PFL3504D / 32PFL3514D 42PFL3704D To increase or decrease volume • Press VOL +/- on the remote control or press VOLUME +/- on the side of the TV. To mute or unmute sound Press MUTE on the remote control to mute the sound.
  • Page 16: Watch A Dvd

    Watch a DVD To watch a DVD Insert a DVD disc into your player. Press on the remote control of the DVD player to select channels. » The DVD might automatically play on the TV. If the picture does not appear Press SOURCE repeatedly to select the DVD player and wait a few seconds for the picture to appear.
  • Page 17: Use More Of Your Tv

    Contrast FEATURES Color LANGUAGE Tint Sharpness Color Temperature *[USB] does NOT appear on 32PFL3504D / 32PFL3514D. to select one of the picture settings, and press OK to Press enter the setting. Adjust the picture quality. [Auto Picture] Press to select the desired setting, then press OK.
  • Page 18 Caution • Before you connect your PC, set the PC monitor refresh rate to 60Hz. Supported screen resolutions The following screen resolutions are supported in PC mode: 32PFL3504D / 32PFL3514D Resolution Refresh rate 640 x 480 60Hz 800 x 600...
  • Page 19: Use Auto Pic Mode

    Change sound settings Press MENU on the remote control and select [SOUND]. PICTURE Auto Sound SOUND Equalizer SETUP Vir tual Surround Sound FEATURES Auto Volume Leveling LANGUAGE TV Speakers Press Î or ï to highlight a sound setting and press OK to select the setting.
  • Page 20: Use Child Control And Rating Locks

    HDMI 2 HDMI 3 Select View / Block *[Video 1], [Video 2] dose NOT support for 32PFL3504D / 32PFL3514D. [Video] will appear instead. Press and then press OK repeatedly to switch between blocked and not blocked. • A box with indicates that the channel is blocked.
  • Page 21 Summary of TV ratings Age rating TV-Y: Appropriate for children of all ages with themes and elements suitable for children aged 2-6. TV-Y7: Programs designed for children age 7 and older. TV-G: Programs suitable for all ages. These programs contain little or no violence, no strong language and little or no sexual dialog or situations.
  • Page 22: View Closed Captions (Subtitles)

    View Closed Captions (subtitles) The caption service displays transmitted CC- and T- text. The caption text can be displayed permanently or only when the TV is muted. Note • Closed caption will not be displayed when you are using an HDMI connection. •...
  • Page 23: View Photos And Play Music On A Usb Device (Available For 42Pfl3704D Only)

    : 24 Mpixel Note • Philips can not be held responsible if your USB device is not supported, nor will Philips accept any liability for damage or loss of stored data. • The USB device is not supplied with the TV.
  • Page 24 Press a number 2 (Number buttons) to toggle between [List] and [Thumbnails]. USB0 Image1.JPG Image1.JPG Image2.JPG Image2.JPG Thumbnails Press the OK button to play/pause USB0 Image1.JPG List Press the OK button to play/pause Press OK to view the picture or to start a slideshow of the pictures in the album.
  • Page 25: Install Channels

    7 Install Channels The fi rst time you setup your TV, you are prompted to select a menu language and to install TV and digital radio channels (if available). This chapter provides instructions on how to reinstall and fi ne-tune channels. Select Your Menu Language Press MENU on the remote control and select [LANGUAGE].
  • Page 26: Add Channels

    Press to select the channel you want to remove, then press OK. PICTURE SOUND SETUP Highlight channels for Ch Up/Down key FEATURES selection. LANGUAGE Ch Select Watch/Skip • The channel display for the removed channel darkens. You will not be able to select the channel again using CH +/-. •...
  • Page 27: Update Your Tv Software

    New software can be obtained from your dealer or can be downloaded from the www.philips.com/welcome website. • Use only software upgrades that can be found on the Philips web site. Warning • When the software upgrade is running, don’t press any buttons.
  • Page 28: Connect Devices

    9 Connect Devices This section describes how to connect various devices with different connectors and supplements examples provided in the Quick Start. Connection Overview 32PFL3504D / 32PFL3514D VIDEO S-VIDEO VIDEO AUDIO HDMI 2 SERVICE TERMINAL a S-VIDEO (side) S-Video (side) input connector to be used with Audio L/R connectors for camcorder, game console, etc.
  • Page 29 42PFL3704D DIGITAL VIDEO 1 COMPONENT AUDIO OUT (COAXIAL) AUDIO OUT S-VIDEO AUDIO VIDEO HDMI 1-IN AUDIO AUDIO AUDIO HDMI IN HDMI 1 HDMI IN HDMI 3 a VIDEO 1 S-VIDEO (back) S-Video (back) input connector to be used with Audio L/R connectors for camcorder, game console, etc.
  • Page 30: Select Your Connection Quality

    Supports high-defi nition signals and gives highest picture and sound quality. Video and audio signals are combined in one cable. You must use HDMI for full high-defi nition video and to enable Philips EasyLink. • To connect to a PC without an HDMI connector, use a DVI-HDMI adaptor and a separate audio cable.
  • Page 31: Connect Your Devices

    When you connect composite or component cables, match the cable colors to the connectors on the TV. Connect a DVD player/recorder via composite connectors 32PFL3504D / 32PFL3514D AUDIO L/R + VIDEO RF OUT RF OUT RF OUT...
  • Page 32 Connect a set-top box, DVD player/recorder and game console via HDMI 32PFL3504D / 32PFL3514D Connect a DVD player/recorder via HDMI-DVI and DIGITAL AUDIO OUT connectors 32PFL3504D / 32PFL3514D 42PFL3704D HDMI 1 IN only HDMI 1 IN only HDMI 1 IN only...
  • Page 33 Connect a set-top box via a composite connector 32PFL3504D / 32PFL3514D AUDIO L/R + VIDEO CABLE RF OUT RF OUT RF OUT RF IN Set-top box IN IN AUDIO L/R + VIDEO RF IN RF IN RF IN RF OUT...
  • Page 34 Connect a digital home theater amplifi er 32PFL3504D / 32PFL3514D DIGITAL AUDIO DIGITAL AUDIO For legal reasons, the digital audio signal can be muted for copy-protected PCM audio qualities on accessory devices connected through HDMI. Connect a PC Connect a PC with an S-Video connector at the back...
  • Page 35 Connect a PC with a DVI connector 32PFL3504D / 32PFL3514D AUDIO DVI OUT AUDIO AUDIO AUDIO HDMI 1 HDMI 1 HDMI 1 IN only IN only IN only Connect a PC with an HDMI connector 32PFL3504D / 32PFL3514D AUDIO AUDIO...
  • Page 36: Troubleshooting

    TV via an your TV and HDMI cable. Not all brands of devices such as DVD connected players use the same system as Philips EasyLink. devices with one Other brands might not work with Philips EasyLink. remote control.
  • Page 37: Notes For The Use Of Usb Devices (Available For 42Pfl3704D Only)

    • If you have a digital camera with only internal memory (no removable memory) you can try to copy the content manually to a USB memory device (e.g. Philips KEY product) using a personal computer. • Some digital cameras allow you to switch between PTP (Picture Transfer Protocol) or “PC Link”...
  • Page 38: Product Information

    Picture enhancement Type: 32PFL3504D / 32PFL3514D: WXGA (1366 x 768 pixels @60Hz) 42PFL3704D: Full HD (1920 x 1080 pixels @60Hz) Brightness: 32PFL3504D / 32PFL3514D: 430 cd/m2 42PFL3704D:500 cd/m2 Aspect Ratio: 16:9 Viewing Angles: 32PFL3504D / 32PFL3514D: 170° (V) by 170° (H) 42PFL3704D:180°...
  • Page 39: Warranty

    13 Warranty WARRANTY COVERAGE: This warranty obligation is limited to the terms as set forth below. WHO IS COVERED: This product warranty is issued to the original purchaser or the person receiving the product as a gift against defects in materials and workmanship as based on the date of original purchase (“Warranty Period”) from an Authorized Dealer.
  • Page 40: Index

    14 Index Antenna Cables component composite HDMI S-Video Channels install list lock Child lock lock channels PIN code ratings lock connection quality Closed captions EasyLink Environmental care Home mode Location mode (Retail or Home) Picture format Picture settings Power Product information Ratings Remote control insert batteries...
  • Page 41 40 40...
