- Page 1 757VR 757VR Digital Video Disc Player & Video Cassette Recorder...
-
Page 2: Introduction
PlayBack Control. You can play interactive software using a menu screens. Refer to instructions of VIDEO CD. wThank you for purchasing this Philips DVD/ VCR.This Owner’s Manual explains the basic operation of this DVD/VCR. Environmental Information All unnecessary packaging has been omitted. -
Page 3: Table Of Contents
Introduction Environmental Information..... 2 Supplied Accessories ......2 Safety Information. -
Page 4: Functional Overview
Functional Overview Front Panel OPEN/CLOSE STANDBY-ON SOURCE DIRECT DUBBING STOP PLAY RECORD TIMER TITLE REPEAT A – B 18 19 20 21 22 1. Disc Tray (DVD) insert a disc here 2. A OPEN/CLOSE button (DVD) to open/close the disc tray 3. -
Page 5: Remote Control
Remote Control STANDBY-ON OPEN/CLOSE DISPLAY CLEAR STATUS/EXIT SYSTEM SYSTEM DISC/VCR MENU MENU STOP PLAY PAUSE SV / V+ SLOW RECORD TITLE ANGLE RETURN AUDIO MODE REPEAT REPEAT ZOOM TIMER INDEX SUBTITLE SEARCH MODE 1. ySTANDBY-ON switch DVD/VCR ON or OFF 2. -
Page 6: Setting Up Your Dvd/Vcr
Setting Up your DVD/VCR Basic Connections • Please refer to the instruction books of your TV,VCR, Stereo System or other devices as necessary to make the best con- nections. • Make one of the following connections, depending on the capabilities of your existing equipment. The following guidelines are options for the best picture and sound quality available on your DVD/VCR. -
Page 7: External Input Mode (For Vcr Features)
• Do not spill water or put anything wet on the remote con- trol. Playable Video Cassette Tapes Philips Consume Electronics recommends that only video cas- sette tapes that have the VHS mark and High Quality (HQ) sys- tem is compatible with this DVD/VCR.This DVD/VCR has an Automatic Head Cleaner. -
Page 8: Automatic Channel Setup
Setting Up your DVD/VCR Automatic Channel Setup You can programme the tuner to scan only the channels that you can receive in your area. 1 Turn on the TV and select the video out channel on your TV. 2 Press VCR, then DISC/VCR MENU. 3 Press K/L to select TUNER SET UP, then press B. -
Page 9: Setting The Clock
Setting the clock If the display shows an incorrect time or ' --:-- ', the time and date must be reset manually. If a TV channel that transmits TXT/PDC (teletext/PDC) is stored under programme number 'P01', time/date will automat- ically be taken from the TXT/PDC information. (SMART CLOCK) 1 Press VCR, then DISC/VCR MENU. -
Page 10: Vcr Playback
DVD/ VCR when the DVD/ VCR stops the playback. DIGITAL STUDIO PICTURE CONTROL Philips has developed a system which produces the best possible playback quality. For old and often-used video cassettes, this sys- tem reduces interference. For new or high quality cassettes, it emphasises the details. -
Page 11: Lining Up Recordings (Assemble Cut)
Linking up recordings (assemble cut) When you add a further recording to a cassette, which already has a recording on it, a short blank (flicker) can appear between the old and the new recording or the picture itself can flicker. To help reduce these from occurring, proceed as follows: 1 Find the tape position of the old recording where you want to insert the new recording. -
Page 12: Programming A Recording (Timer)
Programming a Recording (TIMER) General information Use a TIMER programming to automatically start and stop a recording at a later time or date.The DVD/VCR will switch to the right programme number and begin recording at the cor- rect time.With this DVD/VCR, you can pre-programme up to eight recordings within a period of one year.To make a pro- grammed recording, your DVD/VCR needs to know: * the date you want to make the recording... -
Page 13: How To Check, Or Delete A Programmed Recording (Timer)
How to check, or delete a programmed recording (TIMER) Press VCR, then DISC/VCR MENU. SELECT K L CHOOSE B 2 Press K/L to select 'TIMER'.Then press B. 3 Press K/L to select 'TIMER LIST' , then press B. 4 Select timer block with B. END=EXIT 5 To cancel the recording, press CLEAR. -
Page 14: Playing A Disc
Playing a Disc Basic Playback DVD-V Getting Started Turn on the power of the TV, amplifier and any other compo- nents which are connected to the DVD/VCR. Make sure the TV and audio receiver (commercially available) are set to the correct channel. 1 Press STANDBY-ON. -
Page 15: Zoom
Zoom DVD-V The Zoom function allows you to enlarge the video image and to pan through the enlarged image. 1 Press ZOOM during playback. • Playback will continue. 2 Press ZOOM repeatedly to select the required zoom factor: x2, x4 or OFF. 3 Use Arrow ( L / K / B / s )to move the zoomed picture across the screen. -
Page 16: Program
Playing a Disc Program You may determine the order in which tracks will play. 1 In stop mode press MODE. • The PROGRAM screen will appear. 2 Press to select a track, then press OK. • Press CLEAR to erase the The most recently entered pro- gram. -
Page 17: Subtitle Language
Subtitle Language DVD-V The DVD/VCR allows you to select a language for subtitle dur- ing DVD disc (if available) playback. 1 Press DVD, then SUBTITLE during playback. 2 Press SUBTITLE repeatedly to select your desired subtitle lan- guage. • The selected language will be displayed on the display bar at the top of the screen. -
Page 18: Dvd Setup
Cleaning the disc lens • After prolonged use, dirt or dust may accumulate at the disc lens.To ensure good playback quality, clean the disc lens with Philips CD Lens Cleaner or any commercially available cleaner. Follow the instructions supplied with the cleaner. -
Page 19: Specifications
Specifications PLAYBACK SYSTEM DVD Video, Audio CD, DVD+RW, DVD-R/RW, DVD+R, CD-R/RW,VIDEO CD TV STANDARD (PAL/50Hz) (NTSC/60Hz) Number of lines Playback Multistandard VIDEO PERFORMANCE Video output 1 Vpp into 75 ohm RGB (SCART) output 0.7 Vpp into 75 ohm Video Shift Left/Right VIDEO CASSETTE RECORDER Video heads... - Page 20 Language Code Language French [FRE] Abkhazian 4748 Frisian Afar 4747 Galician Afrikaans 4752 Georgian Albanian 6563 German [GER] Amharic 4759 Greek [GRE] Arabic 4764 Greenlandic Armenian 5471 Guarani Assamese 4765 Gujarati Aymara 4771 Hausa Azerbaijani 4772 Hebrew Bashkir 4847 Hindi Basque 5167 Hungarian [HUN]...
- Page 21 20052 Monza - Milano ITALY Phone: 800 820026 PHILIPS MÁRKASZERVIZ Kinizsi U 30 - 36 Budapest 1092 HUNGARY Phone: (01)-2164428 Meet Philips at the Internet http://www.philips.com PHILIPS PORTUGUESA, S.A. Consumer Information Center Rua Dr. António Loureiro Borge, nr.5 Arquiparque, Miraflores P-2795 L-A-VEHLA PORTUGAL...
