8-2-4 Fill/Park Position
1. Once a normal harvest mode has been completed, the water solenoid will be activated.
2. The amount of water is adjusted by inserting a "pin" into small hole located at front of ice maker. These changes
the time allowed for fill as illustrated in the table below.
NOTE: The water mount only must be changed by technicians.
Water supply amount TABLE
S T A G E I T M E T O
1 6 sec.
2 7 sec.
3 8 sec.
NOTE :Below is an example used by another vendor as an explanation of what is taking place.
S U P P L Y N I D C I A I T O N S
The water amount will vary depending
on the water control switch setting, as
well as the water pressure of the
connected water line.
- 29 -
R E M A R K S
