- Page 1 300M Mini 3G/4G WiFi Router & Power bank VONETS——Magic 4G 300M Professional Mini 3G/4G WiFi Router & Power Bank Magic 4G Quick Setting Guide...
- Page 2 Can’t do commodity distribution for any commercial or profitable purposes by any ways(electricity, mechanical, photoprint, record or other methods). VONETS is the registered trademark of Shenzhen HouTian Network Communication Technology Co.Ltd. The other all trademarks or registered trademarks mentioned in this documents are belong to the individual owners.
-
Page 3: Product Introduction
Product Introduction Magic 4G Supports 4 kinds of functions 1. WiFi Repeater（Magic 4G）: is a functional device that assists the Internet communication gateway to expand wireless coverage area. It is mainly used for expansion of wireless network signal and area coverage to make sure the smooth running of home wireless network. - Page 4 300M Mini 3G/4G WiFi Router & Power bank VONETS——Magic 4G 2. Hotel Mode(Magic 4G): It is a truly plug and play wireless router. Stay for a business trip or traveling, you just need to plug the network cable that provided by the hotel room into the Ethernet port of Magic 4G, and then plug Magic 4G into an electrical outlet, then the whole room is already a Wi-Fi wireless coverage.
- Page 5 300M Mini 3G/4G WiFi Router & Power bank VONETS——Magic 4G Tips: 1. When you need reset the device, the device must be powered, long press the button for 5 seconds, the green light will blink a few times, the device will reset automatically 2.
-
Page 6: Chapter 1 Quick Setting Guide Of Router Mode
(2) If you connect Magic 4G by wired, please disable the wifi network of the Computer. (3) The current mode of Magic 4G is router mode, and the method of WAN port connection is not WiFi connection, the computer can only use a wireless way to connect Magic 4G (routing mode, WAN port connections default to DHCP). - Page 7 3. Hotel Mode Magic 4G is a play and plug WiFi Router, only connect the network cable provided by hotel to the Ethernet port of Magic 4G, you can surf the web, without any other settings. See the drawing below: 4.
- Page 8 VONETS——Magic 4G 5. Magic 4G uses WiFi method to Internet access (1) Enter the configuration interface of Magic 4G, click “WAN Settings”, choose the Connection Type “WiFi”, click “Scan Hotspots”, see drawing below: (2) After the jump page will appear automatically scan window, you can search the WiFi...
- Page 9 300M Mini 3G/4G WiFi Router & Power bank VONETS——Magic 4G (3) Choose a correct WiFi Hotspots, click “Next”, the following drawing will appear: (4) Input the correct password, and confirm it is correct one, then click “Apply” button. Tip: After configuration successfully, the device must be powered off and reboot.
-
Page 10: Chapter 2 Quick Setting Guide Of Bridge Mode
Chapter 2 Quick Setting Guide of Bridge Mode (1) Into the Magic 4G configuration interface, click the "WiFi Search" button on the left, the page will jump and automatically appear scanning window, you can search around wireless... -
Page 11: Chapter 3 Quick Setting Guide Of 3G/4G Router
MAC address, hot spot password is consistent with the source password, the user can also change the SSID and password in WIFI repeater option. Chapter 3 Quick Setting Guide of 3G/4G Router Mode Magic 4G plugged with USB 3G / 4G network card, turn on the device, Magic 4G will... - Page 12 2, when the green light in flash quickly status, proves that the product dialing up connection is successful. 3, the user using a wireless device to connect Magic 4G, should pay attention to: Ø WiFi SSID (wireless name) factory default values: VONETS_ last six characters of product MAC address.
-
Page 13: Chapter 4 Magic 4G Supported 3G/4G Card Model
300M Mini 3G/4G WiFi Router & Power bank VONETS——Magic 4G Chapter 4 Magic 4G supported 3G/4G card model Brand Model Device Type 1261 CDMA2000 EC167 HUAWEI EC1260 E1750 E180 WCDMA E3131 E353 E392u-92 TD-LTE E392u-12 FDD-LTE E398 AC59 AC583 AC2787...
