- Page 1 Register your product and get support at www.philips.com/welcome MCD170/98 User manual ZH-TW 使用手冊...
-
Page 2: Table Of Contents
Contents 1 Important Safety Notice 2 Your DVD Micro Theater Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Connect Preparations Connect speakers Connect audio cables Connect video cables Connect the MW antenna Connect power 4 Get started Prepare the remote control... -
Page 3: Important
1 Important Safety a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 4: Hearing Safety
r This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org. Know these safety symbols This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. -
Page 5: Notice
Notice Any changes or modifi cations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. Environmental information All unnecessary packaging has been omitted. -
Page 6: Your Dvd Micro Theater
2 Your DVD Micro Theater Congratulations on your purchase, and welcome to Philips! To fully benefi t from the support that Philips offers, register your product at www.Philips.com/welcome. Introduction With this DVD Micro Theater, you can enjoy: • Video from DVDs, VCDs, and DivX fi les that are stored on USB devices. -
Page 7: Overview Of The Main Unit
Overview of the main unit a PULL TO OPEN • Open or close the disc tray. b STANDBY-ON • Turn on the unit. • Switch to standby mode. c DSC • Select a preset sound setting. d DBB • Turn on or off dynamic bass enhancement. -
Page 8: Overview Of The Remote Control
• Navigate left/right in the disc menu or system setup menu. • Adjust time. • Skip to the previous/next track. • Select a preset radio station. • USB socket i Tape controls • Start to record. • Start tape play. •... - Page 9 b Source selection keys ( DISC, USB, TUNER, TAPE/MP3 Link ) • Select a source. c MODE • Select a repeat/shuffl e play mode. d SYSTEM MENU • Access or exit the system setup menu. e REPEAT A-B • Mark the section for repeat play, or turn off repeat mode.
-
Page 10: Connect
3 Connect Preparations Place a soft cloth on a hard, fl at, stable surface. Place the unit onto the cloth. Remove the socket cover. Connect speakers Note • Insert the stripped portion of each speaker wire into the socket completely. •... -
Page 11: Connect Video Cables
Option 1: connect coaxial cable You can enjoy multi-channel surround sound from this unit when it is connected to a digital audio device. Connect a coaxial cable (not supplied) to the digital input socket on the audio device. Option 2: connect analog audio cables Connect an audio cable (red/white ends) to the audio input sockets on an audio device. -
Page 12: Connect The Mw Antenna
Option 3: connect component video cables Note • The progressive scan video quality is only available when a progressive scan TV is connected. • If your TV does not support progressive scan, you cannot view the picture. • For how to activate progressive scan on your TV, refer to the TV user manual. -
Page 13: Get Started
Use the controls only as stated in this user manual. Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of your DVD Micro Theater. The model number and serial number are on the rear of your DVD Micro Theater. -
Page 14: Set Clock
Turn on the DVD Micro Theater. Press DISC to select DISC source. Turn on the TV and then select the correct video-in channel. You should see the blue Philips DVD » background screen. • See the TV user manual for details of how to select the correct video-in channel. -
Page 15: Play
5 Play Caution • Risk of damage to the unit! During play, never move the unit. Note • If ‘INVALID KEY’ is displayed, the function is unavailable on this disc/fi le at this moment. Play discs Caution • Never look at the laser beam inside the unit. •... -
Page 16: Play From Usb Devices
Play from USB devices Note • Ensure that the USB device contains playable audio contents for supported formats (see ‘USB playability information’ on page 30) . Insert the USB connector on the device into the socket. Press USB . Press to select a folder. -
Page 17: Play Control
Play control Repeat and random play You can select various repeat functions during playback. The repeat play options vary depending on the disc type. Press MODE repeatedly to choose a play mode. • For DVD • [CHAPTER] (chapter): repeat the current chapter •... - Page 18 Program Note • You cannot program picture fi les/discs. You can program favourite tracks/chapters for playback in specifi ed order. In stop mode, press PROG/ANGLE to enter program mode. Select in the menu and then enter track/ album number to add. When the program is complete, press to start play.
-
Page 19: Listen To Radio
6 Listen to radio Tune to a radio station Press TUNER repeatedly to select FM or Press and hold for more than 2 seconds. [SEARCH] is displayed. » The radio tunes to a station with » strong reception automatically. Repeat step 2 to tune to more stations. •... -
Page 20: Record
7 Record Note • To record, use only “Normal” (IEC type I) tapes on which the write-protect notches (tabs) are not broken. • When you play or record a tape, the sound source cannot be changed. • The best recording level is set automatically. Change of volume and sound effect does not affect recording. -
Page 21: Adjust Sound
8 Adjust sound Adjust volume level During play, press VOL +/- to increase/ decrease the volume level. Select a preset sound effect During play, press DSC repeatedly to select: • [POP] (pop) • [JAZZ] (jazz) • [CLASSIC] (classic) • [ROCK] (rock) Enhance bass During play, press DBB to turn on or off dynamic bass enhancement. -
Page 22: Adjust Settings
9 Adjust settings System settings Change system menu language Press SYSTEM MENU . Select [LANGUAGE SETUP] (language setup)> [MENU LANG] (menu language), and then press Select an option and then press OK . Press SYSTEM MENU to exit. Set screen saver The screen saver protects the TV screen damage due to prolonged exposure to a static image. - Page 23 Select an option, and then press OK . [4:3PS] • For 4:3 screen TV: full-height display with the trimmed sides. • [4:3LB] For 4:3 screen TV: wide-screen display with black bars on the top and bottom of the screen. [16:9] •...
-
Page 24: Video Settings
Change parental control password You can set a password to restrict play of certain discs. Press SYSTEM MENU . Select [SYSTEM SETUP] (system setup)> [PASSWORD] (password), and then press Enter a four-digit password with Numeric keypad 0-9 and then press OK . Press SYSTEM MENU to exit. -
Page 25: Audio Settings
Adjust picture quality During DVD play , you can adjust brightness, contrast, hue, and saturation to improve picture quality. Press SYSTEM MENU . Select [TV MODE] (tv mode). Select one of the following options, and then press [BRIGHTNESS] (brightness) • Adjust the brightness level. - Page 26 Select sampling rate You can select the Linear Pulse Code Modulation (LPCM) output sampling rate. The higher the sampling rate, the better the sound quality. Press SYSTEM MENU . Select [AUDIO SETUP] (audio setup)>[ LPCM] , and then press Select an option and then press OK . •...
-
Page 27: Other Features
10 Other features Set the alarm timer This unit can be used as an alarm clock. The DISC, TUNER or USB is activated to play at a preset time. Ensure that you have set the clock correctly. In standby mode, press and hold TIMER . Press DISC , TUNER or USB to select a source. -
Page 28: Product Information
4 Hz - 20 kHz (44.1kHz) Response 4 Hz - 22 kHz (48 kHz) 4 Hz - 44 kHz (96 kHz) Digital Output SPDIF (Sony Philips digital interface) coaxial Total harmonic < 0.1% (1 kHz) distortion Channel separation 40 dB minimum (1 kHz) S/N Ratio >65dBA... -
Page 29: Usb Playability Information
General information AC power 110-127 V, 220 - 240V, 50Hz Operation Power 20 W Consumption Standby Power <4W Consumption Eco Standby Power <2W Consumption USB Direct Version 2.0/1.1 Dimensions - Main Unit (W x H x D) 147 x231 x 209 mm - Speaker Box 134 x 233 x 153 mm (W x H x D) -
Page 30: Troubleshooting
If you encounter problems when using this DVD Micro Theater, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www.Philips.com/support). When you contact Philips, ensure that your DVD Micro Theater is nearby and the model number and serial number are available . - Page 31 Cannot display some fi les in USB device • The number of folders or fi les in the USB device has exceeded a certain limit. This phenomenon is not a malfunction. • The formats of these fi les are not supported.
-
Page 32: Glossary
13 Glossary Analog audio Sound that has not been turned into numbers. Analog sound is available when you use the AUDIO LEFT/RIGHT. These red and white jacks send audio through two channels, the left and right. Aspect ratio Aspect ratio refers to the length to height ratio of TV screens. - Page 33 Multichannel Usually DVD is specifi ed to have each sound track constitute one sound fi eld. Multichannel refers to a structure of sound tracks having three or more channels. Parental control A function of the DVD to limit playback of the disc by the age of the users according to the limitation level in each country.
