Parts and Functions

Icon

/
7
Clock; Parameter setting/inquiry; Malfunction
display; Mode setting.
Timer ON/OFF: Sleeping; Parameter setting/
inquiry; Malfunction display.
ROOM/SET temp. and humidity display, each
step is 0.5°C (1°F) . For example, if the temp.
is 25°C (77°F), it will display 25.0°C (77°F).
Humidity display function is reserved.
Energy Saving, This icon will be displayed
only when energy saving function is set.
Filter Cleaning.
Child Lock. This icon will be displayed only
when child lock function is set.
Lock/ Central
Motion Sensing (Only valid for part of
models).
Left/Right Swing. This icon is displayed in
swing mode; no display without swing mode.
Up/Down Swing. This icon is displayed in
swing mode; no display without swing mode.
