CURRENT COVER AND MOUNTING PLATE PARTS FOR ROYAL
Item
No.
Code No. Part No.
Description
1.
‡
Solenoid Activated Valve Assembly
0306249PK F-15
2.
Tail Assembly 3/4" x 6"
0345150
3.
EL-431-A Flange Assembly
3305100
4.
EL-640-A CP Cover Plate with Sensor and Mounting Hardware
Assembled (Exposed Models)
(includes EL-549 mounting plate)
3305101
5.
EL-645-A CP Cover Plate with Sensor Assembled
(Concealed Models) (includes EL-592 Moutning Plate)
0305251PK EL-549-A Exposed Urinal Mounting Plate Kit
6.
CURRENT COVER AND MOUNTING PLATE PARTS FOR ROYAL
Item
No.
Code No. Part No.
Description
1.
‡
Solenoid Activated Valve Assembly
0306249PK F-15
2.
Tail Assembly
0345150
3.
EL-431-A Flange Assembly
3305105
4.
EL-625-A CP Cover Plate with Mounting Hardware
(Closet only) (includes EL-549 mounting plate)
0305251PK EL-549
4A.
Exposed Closet Mounting Plate
3305107
5.
EL-635-A Concealed CP TMO Cover Plate with Sensor
(includes Mounting Kit)
5A.
0305292PK EL-592
Concealed Closet TMO Mounting Plate
PLATES ONLY
Item
No.
Code No. Part No.
Description
10.
3345090
EL-1030-A Plate Assembly Only w/ Set Screw*
11.
3345091
EL-1031-A Plate Assembly Only w/ Set Screw*
12.
3345092
EL-1032-A Plate Assembly Only w/ Set Screw*
The information contained in this document is subject to change without notice.
7
Concealed Urinal Models
and TMO Models
5
8
12
9
URINAL FLUSHOMETER
®
Concealed and Exposed
Water Closet Models & TMO Models
5A
6A
6
7
10
7
8
8
9
CLOSET FLUSHOMETER
®
†
Repair Parts and Maintenance Guide
Optima
Flushometers
®
Current style Royal
(after 09/26/10)
®
6
Exposed Urinal Models
8
9
Item
No.
Code No. Part No.
Description
7.
0305292PK EL-592-A
Concealed Urinal Mounting Plate Kit
8.
—
Screws (Flat Head Slotted #6/32)
9.
5305100
EL-674
Wall Plate Screw Kit ( #6-32 x 15.87mm)
†
3305620
EL-1500
Urinal Sensor Replacement
(Exposed and Concealed Models, not shown)
† NOTE: For exposed & concealed solenoids manufactured before 2003 or not shown here,
consult factory for individual part assembly.
‡ Part number varies with valve model variation; consult factory.
4A
Exposed Water Closet Models
5
7
12
8
Item
No.
Code No. Part No.
Description
6.
3305104
EL-595-A CP Cover Plate with Sensor and Override Switch
Assembled (Closet only) Exposed ES-S
6A.
0305292PK EL-592
Exposed & Concealed Closet Mounting Plate
7.
—
Screws (Flat Head Slotted #6/32
†
3305621
EL-1500-L Closet Sensor Replacement Kit (Closet only,
not shown)
3345095
EL-1034-A Button Assembly Repair Kit
8.
5305100
EL-674
Wall Plate Screw Kit ( #6-32 x 15.87mm) (6 per kit)
9.
3345095
EL-1034-A ESS Override Repair Kit for EL-595-A
† NOTE: For exposed & concealed solenoids manufactured before 2003 or not shown here, consult factory for
individual part assembly.
‡ Part number varies with valve model variation; consult factory.
* Mounting plates do not include sensor.
47
Royal flushometer parts, solenoid
parts and assemblies, see page
46 and 47
4
1
3
2
11
Royal flushometer parts,
solenoid parts and assemblies,
see page 46 and 47
1
4
3
