- Page 1 User Manual Wireless 1080p Computer to HD Display Kit GUWAVKIT4 PART NO. M1227-a www.iogear.com...
-
Page 3: Table Of Contents
Table of Contents Introduction Package Contents Requirements Specifications Overview Prepare to Software Installation - Windows Software Installation - Windows Hardware Installation Using the IOGEAR Wireless Software - Windows Troubleshooting and Support Federal Communications Commission (FCC) Statement Limited Warranty Contact... -
Page 4: Introduction
& projectors. Stereo audio is supported via the HD port (along with the video) or via a separate 3.5mm audio jack. The GUWAVKIT4 provides full room coverage, is easy to set up and use, and is an ideal solution for both home and office use. It delivers the best combination of performance and cost in a variety of living room, conference room and classroom environments. -
Page 5: Specifications
Specifications Base Receiver • Video Out: HD Connector, VGA Connector • Audio Output: 3.5mm Stereo Jack • USB 2.0 port to support keyboard and external hard drives. • Streaming video up to 1080p resolution • Supports both Mirror Mode and Extended Mode (TV/monitor as a second screen) •... -
Page 6: Overview
5. USB 2.0 Port 6. Antenna Prepare to Software Installation - Windows If your PC contains a previous IOGEAR Wireless Software or other Wireless USB driver installation, please perform a proper uninstall procedure using the Windows Control Panel. Prior to Software Installation: It is important to make sure there is no prior installation of Wireless USB or Display Link software from IOGEAR or other com¬panies. -
Page 7: Software Installation - Windows
Software Installation - Windows The installation checks the PC capabilities and compares them to the minimum system requirements of the system. For Vista/Win7 it is recommended to run WEI (Windows experience index) calculation prior to installation. Ensure that the PC Adapter is unplugged from the PC. Software Installation Insert the installation CD in the PC CD-ROM drive The installation CD License Agreement menu is displayed below. - Page 8 In the event you need to uninstall the software, insert the CD. Once the Modify Setup screen appears, click on “Uninstall”. Note: The Modify Setup screen will only appear if the IOGEAR wireless software is already installed on your PC. An Operation Progress screen will appear during the Uninstall process.
- Page 9 In the event you need to repair the software, insert the CD. Once the Modify Setup screen appears, click on and click on “Repair”. Note: The Modify Setup screen will only appear if the IOGEAR wireless software is already installed on your PC. An Operation Progress screen will appear during the Repair process.
-
Page 10: Hardware Installation
Hardware Installation 1. Connect the Wireless USB PC Adapter 1. Connect the Wireless USB PC Adapter to a high speed PC USB port. 2. The system will automatically detect and install the drivers. 2. Connect the Power Adapter 1. Plug the AC Adapter cord into the DC-IN on the back of the Receiver Base. - Page 11 6. Connecting USB Devices* (Optional) 1. The Receiver Base provides one USB 2.0 port 2. Connection can be made to an External HDD’s, IOGEAR wireless keyboard etc. *Webcam’s are not supported. Notes: IOGEAR Wireless AV Multimedia Keyboards with trackball make a perfect...
-
Page 12: Using The Iogear Wireless Software - Windows
You can also refer to this section to learn how to uninstall the software. 1. Introducing the UWB Connection Manager Software The UWB Connection Manager is the driver software for your GUWAVKIT4. This driver is automatically installed when you run the IOGEAR Wireless Software Installation CD. The GUWAVKIT4’s USB Wireless PC Adapter contains a radio transmitter that enables your... - Page 13 Page.15 to set the display mode to Mirror Mode. D: Disconnecting the GUWAVKIT4 from your computer - On the Devices tab of the UWB Connection Manager, right click on the connected GUWAVKIT4 and unselect “Set as Default”.
- Page 14 Note: It is recommended to leave this setting on Automatic. If you manually select a channel that is being used by another GUWAVKIT4 in the vicinity, the channel bandwidth will be shared by both devices. To maximize performance, there are eight channels to choose from and a separate channel should be used for each GUWAVKIT4.
- Page 15 2. Adjusting video settings A. Selecting Extended mode or Mirror mode You can choose to set the USB to VGA Adapter’s video output signal to Extend mode or Mirror mode. The default setting is Extend mode. Extend mode extends your desktop space across multiple monitors, so that you can display different information on each monitor connected to your computer.
- Page 16 B. Configuring the Display 1. Setting options for the display The following are the suggested work configurations when connecting a display screen to the Base Adapter: • Mirror Mode • Extend Mode • Laptop with Lid Closed • External Display Only 2.
- Page 17 2) Using Windows Display Preperties on Windows XP/Vista Setting the Display to Extend or Mirror Mode • Mirror Mode : uncheck the option “Extend my Windows desktop on to this monitor” • Extend Mode : check the option “Extend my Windows desktop on to this monitor” Adjusting Screen Resolution Use the Resolution slider to adjust the desired resolution of the display Adjusting Color Level (Color quality)
- Page 18 2) Using Windows Display Properties on Windows 7 Click the Viewspan icon in the System tray/Notification Area Click Change Display Settings To configure screen resolution or any other display option, choose Advanced. The following windows will appear. To change any of the external display settings. Select the appropriate display name in the Display scroll down options.
- Page 19 By default, the audio ports on the GUWAVKIT4 are automatically enabled each time you connect. When you disconnect the GUWAVKIT4 from the PC, the audio ports on the PC are automatically re-enabled. To change the default settings, you may need to manually adjust the audio settings in Windows®, as described in this section.
- Page 20 In Windows Vista/Win7: • Right click the Volume icon in the System Tray and select Adjust Volume Properties. • In the Sounds and Audio Devices Properties screen, select the Audio tab. • In the Sound Playback > Default Device drop-down box, select the USB PnP Sound Device.
-
Page 21: Troubleshooting And Support
• Check to make sure that the wireless connection is established between the PC and the GUWAVKIT4 (the UWB Connection Manager icon in the System Tray is green, and when you double click on it, your TV or Monitor shows connected). - Page 22 Video or game playback is slow or choppy on the external monitor connected to the IOGEAR Wireless Software. • Confirm that the PC meets the minimum system requirements to run the GUWAVKIT4. You can find the requirements on the packaging, or online in the product pages at www.IOGEAR.
- Page 23 • On some systems, the GUWAVKIT4 video adapter cannot control the internal display. Mirror mode is not available (grayed out). • Mirror mode is not available if the external monitor connected to the GUWAVKIT4 is set as the primary display.
- Page 24 There is no sound coming from the external audio device connected to GUWAVKIT4. • Check and adjust the volume settings. • Make sure the cable connecting the audio device to the GUWAVKIT4’s audio output is secure. • Check that the Mute all/Mute checkboxes in Microsoft® Windows® are not selected or that the volume is not set too low.
- Page 25 USB device does not work. • Make sure the GUWAVKIT4 is connected to your computer and the computer is docked (indicator light on the Receiver Base is green). • Check that the cable connection between the USB port on the Receiver Base and the USB device is secure.
-
Page 26: Federal Communications Commission (Fcc) Statement
Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential setting. This product generates, uses, and can radiate radio frequency energy and, if not installed and used as directed, it may cause harmful interference to radio communications. -
Page 27: Limited Warranty
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their respective holders. IOGEAR makes no warranty of any kind with regards to the information presented in this document. - Page 28 © 2013 IOGEAR ®...
