INTRODUCTION
DVD-VIDEO
PRODVD-VIDEO: THE MEDIUM OF CHOICE FOR
PROFESSIONAL CUSTOMERS
The professional DVD player provides all the advantages of
DVD-video and more. Additional control devices like for
example touch screens or wired controls can easily be
connected. Next to that the Professional player is featured
with NVRAM memory to store and retrieve results or settings.
This player is the ideal medium for kiosk, training or business
presentation applications.
Video was never like this before! Perfect digital, studio-quali-
ty pictures with truly 3-dimensional digital multichannel
audio. Story sequences viewed on screen from your own
choice of camera angle.
Language barriers are broken down by sound tracks in as
many as eight languages, plus subtitling - if available on disc
- in as many as 32. And whether you watch DVD-Video on
wide-screen or regular TV, you always see it the way it was
meant to be seen.
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of
Dolby Laboratories. Confidential Unpublished Works.
©1992-1997 Dolby Laboratories, Inc. All rights
reserved.
CONTENTS
INTRODUCTION ..................................................................P 7
INSTALLATION ....................................................................P 9
STANDARD CONNECTIONS ................................................P 11
GETTING STARTED ..............................................................P 14
PLAYING A DVD-VIDEO DISC ..............................................P 15
PLAYING A VIDEO CD..........................................................P 18
PLAYING AN AUDIO CD ......................................................P 20
SETTINGS ............................................................................P 22
PARENTAL CONTROL ..........................................................P 24
BEFORE REQUESTING SERVICE ........................................P 25
DIGITAL VIDEO
DVD-Video uses state-of-the-art MPEG2 data compression
technology to register an entire movie on a single 5-inch disc.
DVD's variable bit-rate compression, running at up to 9.8
Mbits/second, captures even the most complex pictures in
their original quality.
The crystal-clear digital pictures have a horizontal resolution
of over 500 lines, with 720 pixels (picture elements) to each
line. This resolution is more than double that of VHS, superior
to Laser Disc, and entirely comparable to the digital masters
made in recording studios.
DVD-Video discs conform to either the PAL or NTSC video
standard. This dual-standard player can play both types and
present them in the best possible way on your multistandard
TV screen.
As the universal video system of the future, DVD-Video offers
optimum viewing on any TV screen.
CONTENTS
7

Advertisement

Table of Contents

   Also See for Philips DVD170AT

   Related Manuals for Philips DVD170AT

   Summary of Contents for Philips DVD170AT

  • Page 1: Table Of Contents

    INTRODUCTION DVD-VIDEO PRODVD-VIDEO: THE MEDIUM OF CHOICE FOR PROFESSIONAL CUSTOMERS The professional DVD player provides all the advantages of DVD-video and more. Additional control devices like for example touch screens or wired controls can easily be connected. Next to that the Professional player is featured with NVRAM memory to store and retrieve results or settings.
  • Page 2: Introduction

    DVD-Video, including selecting sound track and subtitling lan- guages, and different camera angles (again depending on the disc), are all included. What is more: Philips Parental Control lets you decide which discs your children will be able to view. You will find your player remarkably easy to use, based on the On-Screen Display and player display in combination with the remote control.
  • Page 3: Installation

    ON/OFF FRONT OF PLAYER 1 ON/OFF 2 Disc tray (behind door) 3 Tray OPEN/CLOSE key 4 Display STOP Previous title/chapter/track 7 PHONES; Headphone jack PAUSE/Still/Step 9 LEVEL; Headphone volume control Next title/chapter/track PLAY REAR OF PLAYER 1 Power supply 2 Digital audio output 3 Audio R;...
  • Page 4 INSTALLATION DISPLAY 1 Remote control active (flashing) 2 FTS active 3 SHUFFLE active 4 PAUSE active 5 SCAN active 6 REPEAT A-B/CHAPTER/TITLE/TRACK mode active 7 Chapter or track calendar 8 TOTAL/REMaining/TRACK TIME in hours, minutes and seconds 9 (V)CD disc inserted 0 DVD disc inserted ! DVD CHAPTER or VCD/CD TRACK number @ DVD TITLE number...
  • Page 5: Standard Connections

    GENERAL NOTE - Depending on your TV and other equipment, there are various ways in which the DVD-Video player can be connec- ted. These are shown below. - Please refer to your TV, VCR, Stereo System and any other User Manual(s) as necessary to determine the optimum con- figuration.
  • Page 6 STANDARD CONNECTIONS EXCELLENT A/V CONNECTION VIDEO CABLE AUDIO CABLE Connection to a TV with a video (CVBS) jack. 1 Connect the Video jack on the rear of the player to the cor- responding jack on the TV using the cable supplied. 2 Connect the audio Left and Right channel jacks on the rear of the player to the corresponding jacks on the TV using the cable supplied.
  • Page 7 NTSC/PAL SETTING Use the NTSC/PAL switch on the rear of the player to set the player menu according to the standard used by your TV set. To activate the new setting, the player needs to be switched off and on again. NOTE - The video output standard for video CD and DVD-Video discs must correspond to the disc being played.
  • Page 8: Getting Started

    GETTING STARTED OPERATION NOTE - Unless indicated otherwise, all operations can be performed using the remote control. Always point the remote control directly at the player, making sure there are no objects obstructing the path of the infrared beam. - When there are corresponding keys on the front panel, these can also be used.
  • Page 9: Playing A Dvd-video Disc

    PLAYING A DVD-VIDEO DISC You will recognize DVD-Video discs by the logo. Depending on the material on the disc (a movie, video clips, a drama series, etc.) it may have one or more Titles, and each Title may have one or more Chapters. Play stops at the end of each Title.
  • Page 10 PLAYING A DVD-VIDEO DISC • To go directly to any chapter, enter the chapter number using the numeric keys. NOTE - If the number has more than one digit, press the keys in rapid succession. - For more information about chapters, see “Checking the contents of DVD-Video discs: Menus”...
  • Page 11 • As each chapter is played, its number disappears from the track calendar. • To return to normal play, press SHUFFLE briefly again. REPEAT CHAPTER/TITLE/DISC • To repeat the chapter that is currently playing, press REPEAT for about 1 second: appears on the player display.
  • Page 12: Playing A Video Cd

    PLAYING A VIDEO CD If the disc has a title menu, this will now appear on the OSD. • To remove the title menu, press T-C again. PLAYING A VIDEO CD You will recognize Video CDs by their logo. Depending on the material recorded on the disc (a movie, video clips, a drama series, etc.) it may have one or more tracks, and tracks may have one or more...
  • Page 13: Playing A Video Cd

    NOTE - If the number has more than one digit, press the keys in rapid succession. PLAYBACK CONTROL (PBC) • Insert a Video CD with PBC and press 2. The PBC menu appears on the TV screen. • Move through the menu using the keys indicated on the TV screen until the desired passage starts to play.
  • Page 14: Playing An Audio Cd

    PLAYING A VIDEO CD • To exit from the Repeat mode, press REPEAT a third time for about 1 second. A-B REPEAT To repeat or loop a sequence: • Press A-B REPEAT briefly at the desired starting point; appears on the player display. •...
  • Page 15 • If the TV is on, the search speed and direction are indicated on the screen each time K or J is pressed. • To end the search, press 2, ;, or 9 as desired. MOVING TO ANOTHER TRACK • Press K briefly during play to move forward to the next track.
  • Page 16: Settings

    PLAYING AN AUDIO CD To select Tracks: 1 Insert a disc and go to Stop mode. 2 Press 3 Use to move to the first track number you want to select. 4 Press 5 Repeat steps 3 and 4 to select other track numbers in the same way.
  • Page 17 TV Shape Factory setting 16:9 (wide screen). If you have a regular (4:3) TV, you can choose Letterbox for a ‘wide-screen’ picture with black bars top and bottom, or Pan Scan, for a full-height pictu- re with the sides trimmed. If a disc has Pan Scan, the picture then moves (scans) horizontally to keep the main action on the screen.
  • Page 18: Parental Control

    PARENTAL CONTROL PARENTAL CONTROL ACTIVATING PARENTAL CONTROL This can only be done in Stop mode 1 Press SETUP to view the Settings menu. 2 Move to Parental Control using 3 Press to change Parental Control to Active. 4 You will be asked to enter a 4-digit PIN code of your own choice, and then to confirm your choice.
  • Page 19: Before Requesting Service

    BEFORE REQUESTING SERVICE If the DVD-Video player appears to malfunction, first consult this checklist. Something simple may have been overlooked. Do not attempt to repair the system yourself under any cir- cumstances; this will invalidate the warranty. Look for the specific symptom(s). Then perform only the meas- ures indicated in order to remedy the specific symptom(s).
  • Page 20: Before Requesting Service

    If you are unable to solve the problem, contact your dealer or the Philips CIC. 6 You will find the phone number of the Philips CIC in your Warranty Booklet. english ’ or ‘...
