Important Note Advarsel: Laserrudstråling ved åbning når sikkerhesafbrydere er ude af funktion. Undgå u tsættelse for stråling. Bemærk: Netafbryderen POWER er sekundært indkoblet og afbryder ikke strømmen fra nette. Den indbyggede netdel er derfor tilsluttet til lysnettet så længe netstikket sidder i stikkontakten. Observer: Nettbryteren POWER er sekundert innkoplet.
General Information The region code for this set is 2. Since it is usual for DVD movies to be released at different times in different regions of the world, all players have region codes and discs can have an optional region code.
Introduction Philips DVD Video Introduction Your Philips DVD Video player will playback digital video discs conforming to the universal DVD Video standard. The unique features of DVD Video, such as selection of sound track, subtitle languages and different camera angles (disc dependent), are all supported.
Functional Overview Front and Rear Panels STANDBY-ON – switches the player to Standby mode or ON DISPLAY – shows the current status of the player DVD/VIDEO CD/CD PLAYER STANDBY-ON / OPEN/CLOSE – opens/closes the disc tray Disc Tray MAINS (AC Power) –...
Remote Control RETURN / RESUME – go back to previous menu / to continue playback after play was stopped DISC MENU – access menu of a DVD disc 1 2 3 4 – (left/right/up/down) select an item in the menu –...
If your TV is not equipped with a SCART you can select one of the following alterative connections: S-Video (Y/C) connection Connect the Y/C S-VIDEO OUT jack on the DVD player to the S-Video in jack on the TV using an optional S-Video cable (Y).
For this you need a multi-channel A/V receiver that supports one or more of the audio formats supported by your DVD player (MPEG 2, Dolby Digital™ and DTS). Check the receiver manual and the logos on the front of the receiver.
Unplug the DVD player from the mains. Press and hold 9 and T, on the front of the DVD player. While holding 9 and T, plug in the mains. After PAL or NTSC appears on the display of the DVD player, release 9 and T at the same time.
Initial Setup (Virgin Mode) General In ‘Initial Setup’ you may have to set your preferences for some of the player’s features. (not applicable for all models) Operation After switching on the player for the very first time, the ‘Initial Setup Screen’ will appear. The menu for the first item to be set is displayed and the first option is highlighted.
Temporary Feedback Field Icons Scan Repeat All Repeat Title Repeat Track Repeat Chapter Shuffle Shuffle Repeat Repeat A to end Repeat A-B Angle Child Lock On Child Safe Resume Action prohibited Personal Preferences You can set your own personal preferences on the player. General operation: ¶...
Sound – Digital output Factory setting: ALL. This means coaxial and optical output is on. If you are not connecting to equipment with a digital input, change the setting to OFF. If your equipment doesn't include a digital multi-channel decoder, set the digital output to PCM (Pulse Code Modulation).
Operation Loading Discs Press OPEN/CLOSE on the front of the player to open disc tray. Load your chosen disc in the tray, label side up. Press OPEN/CLOSE again, to close the tray. ➜ READ appears in the status window and on the player display, and playback starts automatically.
Repeat DVD Video Discs Repeat chapter/title/disc ¶ To repeat the current chapter, press REPEAT. ➜ appears on the player display. REPEAT CHPT ¶ To repeat the current title, press REPEAT a second time. ➜ appears on the display. REPEAT TITL ¶...
FTS-Video ¶ The FTS-Video function allows you to store your favourite titles and chapters (DVD) and favourite tracks and indexes (VCD) for a particular disc in the player memory. ¶ FTS program can contain 20 items (titles, chapters etc.). ¶ A programmed FTS will be placed on top of the list when playback is activated.
Special VCD & SVCD Features Playback Control (PBC) ¶ Load a Video CD with PBC and press B. ¶ Go through the menu with the keys indicated on the TV screen until your chosen passage starts to playback. If a PBC menu consists of a list of titles, you can select a title directly.
Storing an FTS Programme Load a disc and stop playback. Use 4 to go to the list of available tracks. Use 2 or 1 to select tracks from the list. To go directly to any track, enter the track number using the numerical keys (0-9).
Access Control Access Control; Child Lock (DVD Video and Video CD) Activating/deactivating the child lock When disc playback is stopped, select ACCESS CONTROL in the features menu using the 3/4 keys. Enter a 4-digit code of your own choice. Enter the code a second time. Move to “CHILD LOCK”...
DVD player, certain aspects of the technical standards had not been settled between set makers and the disc industries. On this basis Philips cannot guarantee the functioning of PARENTAL CONTROL system and denies any liability associated with unintended watching of disc content.
NTSC/PAL setting at the DVD player matches the video signal of your television. – If your TV video signal is NTSC, select the NTSC setting at the DVD player. – If your video signal is PAL, select the PAL setting - see NTSC/PAL SETTINGS.
(left surround) PPENDIX Delay times The DVD player is set to reproduce correctly synchronized Digital Surround Sound in a listening area where the surround speakers are about 150cm nearer to the listening position than the front speakers, and the center speaker is in line with the front speakers.
Specification PLAYBACK SYSTEM DVD Video Video CD & SVCD CD (CD-R and CD-RW) DVD+RW OPTICAL READOUT SYSTEM Lasertype Semiconductor AlGaAs Numerical Aperture 0.60 (DVD) 0.45 (VCD/CD) Wavelength 650 nm (DVD) 780 nm (VCD/CD) DVD DISC FORMAT Medium Optical Disc Diameter 12cm (8cm) Playing time One layer...
