ABOUT THE PA11-VW6 INTERFACE

The PA11-VW6 interface connects the iPod directly to VW audio system and its on-board software
translates commands from either your VW CD Changer controls into commands that the iPod
understands. This interface enables the iPod to take place of a VW remotely mounted CD Changer and
provides the following benefits:
Direct connection of the iPod to VW vehicle audio system for optimum sound quality
Control iPod playback with CD Changer buttons on car radio
Direct access and control of up to 5 favorite playlist and/or direct control of the iPod using the
iPod buttons.
Charge the iPod internal battery --- and charging stops automatically at one hour after iPod is
paused.
Auxiliary audio input [connect additional audio device (SAT radio, DVD Player, Game system
etc) and listed to it on the factory system)
Plug-n-play: includes installation cable, mounting screws and owner's manual.
Retains factory SAT Radio.

COMPATIBILITY

The PA11-VW interface is compatible with iPod (G3, G4, G5) iPod Mini, Nano, Photo, Video, iPhone,
Classic, Touch models featuring a dock connector. Please visit www.apple.com/iPod and update the
firmware on your iPod.
rd
Note: The iPod Nano 3 Generation, Touch, classic, touch, and iPhone are not fully compatible in Hybrid mode.
(See below). The screen on these iPods will be locked and OK TO DISCONNECT will be displayed. Playlist on iPod
can be accessed through the DISC button on the radio, but user can not operate the keys on the iPod when DIP
switch #2 is set to "ON". These iPod's are fully compatible in Direct Mo
Important: Display of artist, song title information, track search and artist, song title, album or genre is
not displayed on the Audi/VW radio. Radio will show Track and disc number. (CD Changer display
mode)

1. HYBRID MODE, DIRECT MODE AND AUX. OPTION

The PA11-FVW provides two ways to control your iPod through the car radio, namely Hybrid Mode
and Direct Mode.
1. DIRECT MODE: Search and select music on the iPod directly just as you would in portable use.
Music will playback through your car stereo. You may also use the track up/down, fast forward and
reverse buttons on your radio or steering wheel to control music playback. All control functions on
the iPod will still be available for direct control using the iPod buttons. Please see section 4 of this
manual for additional information.
2. HYBRID MODE: Operate and control the iPod as if it was a CD Changer. This mode allows you to
access up to five playlist on the iPod. The instructions for playlist creation and playback controls are
available later on in this manual. Additionally, while in Hybrid Mode, the keypads and the display on
the iPod function as if it was in Direct Mode or in portable use.
If the playback of a Playlist is manually interrupted by using the iPod's key pad, and a song or
music in a new category is played, the interface module memorizes the last played track number of
the new category. "New category" means file, or folder, or playlist, or artist etc. which is different
from the Playlist being played. When you return to the same DISC on the radio the interface module
will use the "memorized" track number (note: just the track number, not the last played song in the
new category) to playback the Playlist related to this DISC.
