- Page 1 English VIDEO DOOR PHONE DOOR STATION MR7D USER MANUAL ▪ ALUMINIUM PANEL ▪ DIRECT SELECT CALL ▪ LED NIGHT VIEW ▪ NAMEPLATE FOR EACH HOUSE ▪ RAINCOVER AVAILABLE VT-ENG-MR7D-V1.0 081S115...
-
Page 2: Parts And Functions
1. PARTS AND FUNCTIONS Microphone Camera Night view LED Video Intercom System Nameplate Call button Backcover screw DIMENSIONS: 336(H)×125(W)×50(D)mm Note: models with different number of buttons install the same - 1 -... - Page 3 2. PORTS INSTRUCTIONS 3117-VT-WB Port Instructions: P+,P-: power input, connect to the P+,P- of the power supply(the output of ▪ the power supply must be 18V DC) L+(NO),L-,L+(NC): e-lock connection port.(refer to wiring next page) ▪ 1R,2W,3Y,4B: connect to the 1R,2W,3Y,4B of the Indoor monitors ▪...
- Page 4 3. STANDARD SYSTEM WIRING - 3 -...
- Page 5 4. NAMEPLATE INSTRUCTIONS Down press the left side of the nameplate and push to left, then the right side ▪ of the nameplate will jump up Take the nameplate out and put the paper with the names in between the ▪...
-
Page 6: Warranty Card
4. Attempting to force the device to perform functions for which it is not intended 5. Attaching the device to power supplies other than thoserecommended by the manufacturer Distributor for Warranty purposes: Intelligent Home Online Ltd 62 Hartley Old Road Purley, Surrey CR8 4HJ +44 (0)20 86170015 www.intelligenthomeonline.com...
