  • Page 1 PRESENTATION SOLUTIONS 2007 / 08...
  • Page 2 KINDERMANN The specialist for presentation solutions Kindermann is one of the leading German manufacturers of presentation and conference equipment and distributes its products worldwide. Since its foundation in 1861 the company has been committed with light technology, and over the years has developed genuine professionality in projection systems.
  • Page 3 With the new digital technologies procedures have changed considerably, but not demands as to picture quality. The KINDERMANN KWD 220X, the various models by EPSON, e.g. the TW D3, TW 700 and TW 1000, as well as the other projectors in the KINDERMANN programme meet the demands of the home cinema user.
  • Page 4 KINDERMANN KXD 140 / KSD 140 The projectors for education and business 2200 ANSI lumens (KXD 140) 2000 ANSI lumens (KSD 140) High contrast 2000:1 Serial interface RS 232 Features Easy installation and operation HDTV compatible Excellent value KINDERMANN KXD 165 / KSD 160 The ideal business projectors 2600 ANSI lumens (KXD 165) 2200 ANSI lumens (KSD 160)
  • Page 5 KINDERMANN KX 170 The proper projector for conference and lecture rooms High connectivity DVI-D input Monitor output and serial interface RS 232 Features Easy installation and operation HDTV compatible Component video input Excellent value KINDERMANN KXD 2650 The powerful business projector Multi-compatibility for computer and video High contrast 2000:1 Low fan noise...
  • Page 6 KINDERMANN KX 2900 active The multi-talent for interactive presentation 2600 ANSI lumens Interactive functions integrated – NEW Works with any projection surface For a more attentive audience Features Built-in camera for interactive presentation After the installation of the software driver on your laptop you can control your presentation with the help of an electronic telescope pointer.
  • Page 7 KINDERMANN KX 4000 The high-performance projector for permanent installation Multi-compatibility for computer and video Automatic positioning for ceiling mounting High light output Features Horizontal and vertical Keystone correction Serial interface RS 232 Picture-in-picture function Video component and DVI input IR remote control with mouse and laser pointer Lamp change on top, ideal for ceiling mounting KINDERMANN KWD 220 X The home cinema projector for a photo realistic AV show...
  • Page 8 Technical data KINDERMANN range Model KXD 50 KXD 140/ KSD 140 Ref. No. 8952 8793 / 8797 Resolution 1024 x 768 1024 x 768 / 800 x 600 ANSI lumens 1800 (1500 eco) 2200 (1700 eco) / 2000 (1600 eco) Display 1 x 0.7“...
  • Page 9 The TOSHIBA range Do you seek the ideal business projector, do you work in education, or look for a projector for your home cinema? TOSHIBA projectors match your needs per- fectly – compatible with Windows and Mac, with lamp or LED light source, classic or modern design, with or without camera, wireless or with cable.
  • Page 10 The SANYO range SANYO is one of the largest producers of projectors with LCD technology. SANYO projectors are the proper choice for large audiences and permanent in- stallations in conference halls. Powerful low-budget models for mobile and office use and for home cinemas supplement the programme.

  • Page 11: Interchangeable Lenses

    PLC XP57L Easy lens change lens shift function high connectivity SANYO PLC XP57L Ref. No. 8974 Resolution ANSI lumens 5500 Contrast ratio 1000 : 1 depending on lens Image size diagonal Projection distance depending on lens Ratio depending on lens 319 x 168 x 470 mm Dimensions Weight...
  • Page 12 The EPSON range The Epson projectors offer very bright, compatible and versatile presentation solutions as well as excellent portability. Whether you require a high- performance projector for home use or for presentations in various office or conference room environments or wish to create a specialised installation system, Epson has the projector to suit your needs.

  • Page 13: Interchangeable Lenses

    Subject to technical alterations, as well as to changes of the design and the colour EMP TW D3 all-in-one home cinema projector integrated JVC DVD player and JVC stereo loudspeaker connection to PC, receiver, digital camera, play stations EMP TW D3 8880 (854 x 480) 1200 1000 : 1 0.76 –...
  • Page 14 The elegant solution for presentations in entrance halls, conference rooms and point-of-sale Advantages of the LCD technology High resolution Needle-sharp pictures Long life No hot spots Low energy consumption Nearly glare-free Technical data: Model CONRAC Optic 32 HD 8850-0 Technology Resolution (pixel) 1366 x 768 Size of display...
  • Page 15 Technical data: LG M 3201 C Model 8817-5 Technology 1366 x 768 Resolution (pixel) Size of display 708.4 x 398.5 mm Brightness cd/m 1600 : 1 Contrast Response 8 ms GTG Dim. in mm 803 x 493 x 99.9 Weight in kg Technical data: Model PIONEER PDP-42MXE 20...
  • Page 16 Universal projector mounting kits for ceiling and wall mounting Universal + patented Due to the variable holder the projector mounts are compatible with nearly any projector weighing max. 25 kg. 3D ball-point joint For tilting, swivelling and rotating the projector in all 3 dimensions.
  • Page 17 Vario Comfort line Modern and elegant design Metallic silver colour RAL 9006 or white RAL 9003 Fully pre-mounted for quick installation Variable patented holder suitable for nearly all data/video projectors Joint for tilting the unit in all directions, up to ±20°, can be rotated up to ±180° Can hold up to 20 kg weight Integrated cable channel ø...
  • Page 18 Vario Professional line Suitable for any demand Variable patented projector holder Fully pre-mounted (except 5886-100) for easy mounting Can hold up to 25 kg weight Stepless telescopic height adjustment (No. 5883-xxx) Supplied with external cable channel Quick exchange of projector, e.g. for servicing Ball-and-socket joint for tilting the unit in all directions up to ±20°, can be rotated...
  • Page 19 Vario Home Cinema CT Small and inexpensive – for direct ceiling mounting Flight Frame Holder for professional data/video projectors for big events Accessories for Vario ceiling and wall mounts Projector arm No. 5886-200 For mounting an additional projector on the Vario Pro C 60. No.
  • Page 20 Anti-theft devices Anti-theft device No. 5775 For notebooks, projectors etc. with security lock slot Plastic coated steel rope Length 1.5 m Diameter 4 mm Accoustic anti-theft device No. 7425 The accoustic anti-theft device with built-in shock sensor triggers off the alarm in two stages (after 8 resp.
  • Page 21 Ceiling mirror for data/video projectors Mirror projection system for false ceilings max. 430 mm min. 240 mm Mirror flap 395 mm Distance to screen: + 50 cm = projection distance Technical data Necessary space for mounting (depending on the adjustment of the upper mirror) Max.
  • Page 22 Ceiling lifts allow you to install your data/video projector in a false ceiling, e.g. of a conference or lecture room. If not in use the projector is hidden behind the panelling of the ceiling and thus protected against theft. KINDERMANN ceiling lift Pro 120 / Pro 250 Professional ceiling lift with low noise movements Lifting range up to 340 cm For projectors of up to 30 kg weight...
  • Page 23 KINDERMANN ceiling lift Compact 80 / 120 Lifting range up to 120 cm Max. projector weight 20 kg Installation height > 120 mm Sturdy construction Easy mounting The KINDERMANN ceiling lift Compact is extremely flat. For projectors of not more than 6.5 cm height a false ceiling of 120 mm is sufficient. The lift Compact is easy to mount and its mounting frame fits into nearly any false ceiling with standardized ceiling elements of 60 x 60 cm.
  • Page 24 Mounts for plasma and TFT/LCD displays Sturdy high-quality mounts for safe mounting of displays Universal mounts for displays up to 50“: Professional mounting of large displays Easy configuration and installation For mounting displays in portrait or landscape format Compatible with many displays Also suitable for integration in AV furniture Optional tilting plate KINDERMANN ceiling mounts for displays...
  • Page 25 KINDERMANN wall mounts for displays Wall mount VESA 75 / 100 / 100 x 200 2 7 0 m Wall mount VESA 75 / 100 / 100 x 200 / 200 Wall mount identical with No. 7511-1, but tiltable up to 6 3 0 9 Wall mount VESA with rotating arm distance to the wall max.
  • Page 26 KINDERMANN PIXIE Pro Conference controls for: Projectors, displays, etc. Electronic devices, e.g. DVD player Volume control, e.g. amplifier Room technology, e.g. screens, ceiling lifts, shades PIXIE Pro conference controls The PIXIE Pro control systems are intelligent gadgets for conference, lecture rooms and classrooms where data/video projectors, displays, volume controls or room technology are permanently installed and often used by...
  • Page 27 KINDERMANN PIXIE Pro NRC Network Room Control Operation via web browser or operating panel Complete media control with RS 232, IR transmitter, relais outputs, sensor inputs Can be extended via system bus (IR, RS 232, relais) PIXIE pro System Control can be used as operating panel Examples of application The PIXIE Pro Network Room Control controls a projector, a screen, a DVD player via web...
  • Page 28 Exchangeable modules for an individual configuration KINDERMANN PIXIE Display Control The control system for lecturers, teachers and managers Easy operation of media technology due to focus on the main functions Hassle-free presentation – no embarrassing situations because of lost remote controls or empty batteries High reliability due to cable-based transmission of IR commands Easy to install due to self-learning of the...
  • Page 29 KINDERMANN MultiMedia socket systems The modular MultiMedia socket system allows you to integrate computer, Video, Audio, control or network connections into standard electrical fittings (50/54/55 m sockets and plugs), into desktop casings, underfloor units and patch panels for 19" racks. Module covers sized: Suitable for: 54 x 54 mm (7441-xxx)
  • Page 30 Computer / Video Model Connection Blind cover Mains switch (duplex inset) VGA (HD 15) Soldering Plug Soldering Plug DVI-I (24 + 5 pin) Soldering Plug Soldering Plug Video (Cinch) Soldering Plug Soldering Plug Plug to 1xBNC S-Video (4-pin Mini DIN) Soldering Plug Soldering...
  • Page 31 Data Model Connection Soldering Serial RS 232 Plug Soldering Plug PS/2 Soldering Plug Plug Plug (A-f/A-f) USB (2.0 comp.) Plug (A-f/A-f) Plug (B-f/A-f) Plug (B-f/A-f) CAT 5 (RJ45) Gender changer (1:1) Gender changer (1:1) CAT 6 (RJ45) Crimp Crimp socket by “Reichle + DeMassari“...

  • Page 32: Connecting Cables

    Desktop connections With the KINDERMANN desktop modules messing around with the wiring on the conference table is a thing of the past. The lid is opened only when required. After fixing the wiring the lid can be closed again and the connections are no longer visible, the cable outlet is covered by an integrated brush.
  • Page 33 Modules for underfloor installation For Ackermann underfloor housings The module holders replace the casings GB2 and GB 3 Individual combination of insets Model Module holder GB2 with space for 4 half insets No. 7444-xxx Module holder GB3 with space for 6 half insets No. 7444-xxx Modules for 19“...
  • Page 34 VGA signal amplifers / splitters VGA Booster 1 : 1 Signal amplifier up to a distance of 50 m between booster and projector (depending on resolution) 1 input / 1 output (HD15 m / f) Frequency 250 MHz Supports 1920x1440 pixels @ 60 Hz Plastic housing 97x56x26 mm Incl.
  • Page 35 VGA switchers All selectors offered below transfer the VGA signal from 2 up to 8 connected computers to a monitor or projector. VGA share Basic 2 : 1 2 inputs / 1 output (all HD15 f) 2 select buttons Auto skip, for skipping non-active inputs 4 status LEDs Frequency 250 MHz Supports 1920x1440 pixels and DDC1, DDC2, DDC2B, DDC2B+, DDC2AB...
  • Page 36 Can be used as TV Tuner with video text, Progressive Scan Converter, Video Scaler, VGA/Video switcher Adaptive 2D filter for Y/C partition Philips SAA7118 Chip A2/NICAM Stereo Sound Decoder Inputs: aerial / cable), Composite Video (Cinch), S-Video (4 pin-Mini-Din), VGA...
  • Page 37 VGA cables VGA cable HD15 (m / m) 10 m 15 m 20 m* 25 m* 30 m* 40 m* High-quality VGA cable, black with gilded contacts, double-protected, for best picture quality. Multi-coaxial cable with low resistance, double-protected Gilded contacts Blue plug with 2 integrated ferrit cores, according to PC-99 standard, UL- approved...
  • Page 38 USB cables USB cable (A-m / A-m) USB 1.1 compatibility Grey USB 2.0 cable (A-m / B-m) USB adapter (A-m / B-f) USB 1.1 compatibility Grey USB 2.0 Active Hub (A-m / A-f) For cable connection > 5 m Active USB 2.0 Hub with 5 m cable Can be further extended (max.

  • Page 39: Audio Cables

    S-Video cables S-Video cable (4 pin MiniDIN m/ m) 10 m 15 m 20 m 25 m 30 m Double-protected 2 coax connections (75 Ohm) Gilded plugs S-Video cable > 30 m length on demand Video-/S-Video adapter Video/S-Video adapter Converts signals in both directions, e.g. for connecting a VHS recorder to an S-Video input Cinch (f) to S-Video (f)
  • Page 40 For an effective autio-visual presentation in front of a bigger audience your projectors must be supported by an external sound system. KINDERMANN offers various audio equipments for mobile use or permanent installation. Mobile Audio boxes Mobile Sound Champ MP3/DVD (portable microphone set) Mobile Sound Champ MP3/DVD (Lavalier microphone set) Mobile Sound Champ MP3/DVD (Microphone with head set) Powerful mobile all-in-one box with...
  • Page 41 Passive loudspeakers by Tannoy Apart MASK4T set, white ____________ Apart MASK4T set, black Compact well-designed loudspeaker which is suitable for many applications. The impedance of 16 Ohm allows a parallel operation of 4 loudspeakers at one 4 Ohm amplifier output. Also, an operation with 100 V is possible, e.g.
  • Page 42 Interactive presentation systems Interactive systems are the ideal tool for new ways of presentation. For working with an interactive whiteboard you need a computer and a data/video projector, which projects the computer image on the touch sensitive surface of the board. This turns the board into a large touchscreen.
  • Page 43 Polyvision Walk-and-Talk Boards The Walk-and-Talk Boards do not require any additional software, unlike most of the other systems. This makes time-consuming training superfluous. In no time is the user able to operate such a board. This feature is of special advantage when several users work with the system.
  • Page 44 Visualizer CL 500 For ceiling mounting Visualizer PS 600 / PS 400 The high-end desktop presenter Features XGA resolution (1024x768 pixels) 12x optical zoom Progressive Scan CCD with 22 pictures per second (PS 600) 20 pictures per second (PS 400) Camera can be rotated by 90, 180 or 270°...
  • Page 45 Visualizer DC 153 / Visualizer DC 160 Technical data: Mobile Model DC 153 7461-7 Image sensor 1/3” CCD Progressive Scan Resolution in pixels XGA 1024 x 768 Picture sequence in seconds Integrated memory – Slot for memory extension Rotating head „swan-neck“...
  • Page 46 Copyboards M11 Make your meetings more effective Ideal for conferences, meetings, team work For storing data directly on a USB stick (without PC) Direct connection to PC via USB cable For printing data with a printer (printer is not supplied) Easy use –...
  • Page 47 KINDERMANN overhead projectors Overhead projectors have always High light output been and still are the most widely Good value spread means of presentation in Low maintenance costs schools and conference rooms. Easy to operate Plug and play KINDERMANN offers any user a versatile programme of overhead projectors Famulus reflex The light-weight travellers Famulus beta...
  • Page 48 Users who travel a lot know the problems: It is often difficult to visualize a lecture because of poor projection facilities at one´s destination. Who wants to be on the safe side, relies on his own overhead projector. The Famulus reflex projectors are the best choice for mobile use.
  • Page 49 Famulus alpha 250 • alpha 400 The projectors for the small budget – „Made in Germany“ You are looking for a reliabe and maintenance-free overhead projector with a good projection quality but you have only a small budget? Then the Famulus alpha projectors are the proper choice for you. Patented safety lens head •...
  • Page 50 Famulus beta 250 • beta 400 The professional projectors for schools, seminars and training Innovative technology as well as safe and con- venient operation characterize the Famulus beta projectors. Famulus beta 250 For the projection in small or medium-sized rooms. With 2 halogen lamps 24 V/250 W, quick lamp changer with LED for lamp failure, economy switch, glare-free fesnel lens, vario-...
  • Page 51 Patented safety lens head • no overheating of the lens No disturbing fan noise • < 30 dB(A) Lockable projector body • protects against unauthorized handling High light output • up to 11000 lumens Picture size chart beta Distance (m) Dimensions beta 250/400/575 M In transport position:...
  • Page 52 Famulus beta 400 K The large-screen projector with Keystone correction To allow any member of the audience to see the full size of the picture, you have to project it at an extremely steep angle which leads to a trapezium-like distortion of the overall dimensions.
  • Page 53 Working material for overhead projectors Transparency rolls and sheets For the professional preparation of a lecture as well as for making notes during the lecture. Made from environmentally friendly materials. Suitable for felt pens. Transparency roll 10 m long/29.7 cm wide Transparency roll 30 m long/29.7 cm wide Transparency sheets 0.08 mm/DIN A 4 Transparency sheets 0.10 mm/DIN A 4...
  • Page 54 Magic Screen IR Two projectors in one unit – for presentation on the built-in monitor or on a large screen! Quality m a d e Ger many by KINDERMANN Two projectors in one unit The Magic Screen IR is a 35 mm slide projector for presentation just as you please: on the built-in monitor or on a large screen.
  • Page 55 The Magic range High-quality 35 mm slide projectors The Magic projectors with the powerful 250 or 150 W halogen lamps are designed for the ambitious amateur as well as for schools and seminars. Convenient wireless operation for easy use The 4-channel IR remote control has clearly identifiable command buttons: two buttons for forward or backward transport, two other buttons for overriding the selective autofocus,...
  • Page 56 diafocus 66 T The high-performance projector for 6 x 6 slides The superiority of 6 x 6 slides as to brilliance and contrast is only at its best when using the proper projector. To make a slide show with 6 x 6 slides as convenient as a conventional one with 35 mm slides, KINDERMANN offers the diafocus 66 T, a high performance projector for single and dissolve projection at a reasonable price.
  • Page 57 The low-budget model – No. 6293-2 two horizontally stepless and vertically height adjustable trays adjustment 45 x 30 cm each 60 -100 cm Simple projection table for ohps, with base 38 x 39 cm. With 4 castors, 2 of them lockable. Weight: 7 kg.
  • Page 58 Lectern with column Practical and decorative lectern. Hydraulic stepless height-adjustment from 90–135 cm. Ready for use, easy to store away because it needsonly little space. High-quality steel construction in grey or black, with two lockable castors. Lectern with column, beech Lectern with column, grey Lectern / Projection table / MultiMedia table –...
  • Page 59 Presentation boards Light-weight, sturdy aluminium construction Can be used on both sides 4 castors, 2 lockable Overall height approx. 198 cm Presentation cases Sturdy lockable aluminium case with carrying strap Presentation case Subject to technical alterations, as well as to changes of the design and the colour 150 x 120 cm, light-blue felt cloth No.
  • Page 60 The KINDERMANN rail system More flexibility for your conference room High flexibility is guaranteed through an unlimited variety of combinations. The very sturdy and reliable construction allows easy and troublefree mounting in no time. The elegant flat design, only 7.2 cm high, fits to any room style.
  • Page 61 Flip charts Flip chart Budget Magnetic board 100 x 70 cm Integrated pen tray Holder with two fixing screws Height-adjustable up to 190 cm With tripod Optional wheel base Flip chart Budget No. 4534-1 Flip chart pad, 20 sheets No. 6917 Flip chart Deluxe Magnetic board 96 x 69 cm Surface for dry wiping...
  • Page 62 Whiteboards The classic writing boards for conferences, presentations and meetings Solid construction Long life For whiteboard markers Can be dry-wiped Magnetic surface For horizontal or vertical position For wall mounting 25 years warranty for enamelled surface Whiteboards PRO The PRO series features an enamelled long life surface that can be easily dry-wiped.
  • Page 63 The proper guideline for large-screen projection How to choose the proper type of screen Which screen is to be preferred first of all depends on the application. For frequent shows in the same location a wall or ceiling screen - manually or electrically operated, with or without frame - should be considered.
  • Page 64 Elpro electrol – Easy Install The professional electrical model Compact electrol – Easy Install The efficient economy screen Cineroll Electric Advanced The professional model for permanent installation 4 : 3 format with black rim SlimScreen electrol The low-budget electrical model Subject to technical alterations, as well as to changes of the design and the colour Perfectly flat projection image Standard format 1:1...
  • Page 65 Pro Screen – Easy Install The high-quality model with spring mechanism Slim Screen (XL) The basic model with spring mechanism Standard wall screen For the small budget Cinelux Compact Mono The mobile economy model Subject to technical alterations, as well as to changes of the design and the colour Big rotary shaft for flat projection Standard format 1:1 screen and powerful spring...
  • Page 66 Pro Star The top of the range model Pro View The attractive economy screen Standard tripod screen For the small budget Fast Fold The mobile model for large-screen projection Subject to technical alterations, as well as to changes of the design and the colour Extremely sturdy stand, square Standard format 1:1 bars, with Keystone bracket...
  • Page 67 Pro Cinema – Easy Install The manual wall screen Home Screen II The elegant model with frame We offer more home cinema screens. Please ask for more information! Accessories Mounting brackets 100 cm long (can be shortened) for Elpro large electrol, Elpro electrol, Hapro manual, Cinelpro electrol 100 cm long (can be shortened) for Cineroll Electric Advanced...
  • Page 68 KINDERMANN & Co. GmbH • Kindermannstr. 2 • D-97199 Ochsenfurt • +49 (0) 9331/93-0 • 93-400 • www.kindermann.com • export@kindermann.de 0100 905 002 GB 0107 15.0 Printed in Germany Subject to alterations...
