- Page 1 "CALVERT" CARVED FIREPLACE FA927800TX-ESPRESSO FA927900TX-IVORY For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 ASSEMBLY INSTRUCTION service@seidal.com www.seidal.com...
- Page 2 "CALVERT" CARVED FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
-
Page 3: Parts List
"CALVERT" CARVED FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. - Page 4 "CALVERT" CARVED FIREPLACE Assembly Instructions INSERT（A）CAM BOLT &（B）WOOD DOWEL TO THE RELATED HOLES,THEN USE （C）CAM LOCK TO CONNECT (2)LEFT SIDE PANEL & (4) LEFT FRONT PANEL TOGETHER,USE （C） CAM LOCK TO CONNECT (3)RIGHT SIDE PANEL & (5) RIGHT FRONT PANEL TOGETHER Figure 1 AFTER ASSEMBLED FIGURE 1,INSERT...
- Page 5 "CALVERT" CARVED FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE （C） CAM LOCK TO CONNECT (8)MIDDLE FRONT PANEL & (9) MIDDLE LEFT FRONT PANEL & (10)MIDDLE RIGHT FRONT PANEL TOGETHER. Figure 4 AFTER ASSEMBLED FIGURE 4,INSERT （B）...
- Page 6 "CALVERT" CARVED FIREPLACE Assembly Instructions AFTER FINISHED FIGURE 6,THEN INSERT (I) WOOD SCREW INTO THE RELATED HOLES TO CONNECT WITH TOP PANEL, USE SCREWDRIWER TO LOCK IT TIGHTLY. Figure 7 PUSH (12) INSERT TO THE RELATED PLACE OF MAIN BODY ,THEN INSERT (I)WOOD SCREW THROUGH (11)INSERT FIXED BAR TO LOCK TIGHTLY .
- Page 7 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI Please contact Southern Enterprises at 800-633-5096 or in Dallas (972) 869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues with your purchase. Please ask for a customer service representative for issues involving damages or replacement parts.
