- Page 1 Public Signage Solutions User Manual TYPE NR. BDL4635E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS... 1 Contents ... 7 Elements Name and Functions ... 8 Terminal Panel ... 9 Remote Control...10 Operating Range for the Remote Control...11 Handling the remote control ...11 How to Mount or Attach Table stand to the LCD Monitor...12 Setup Procedure...15 Install the LCD Monitor in Portrait Mode ...17 Connectivity ...18... -
Page 4: Safety Instructions
TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The Socket-outlet shall be installed near the apparatus and shall be easily accessible. KNOW THESE SAFETY SYMBOLS User Manual BDL4635E ... - Page 5 User Manual BDL4635E REGULATORY INFORMATION CE DECLARATION OF CONFORMITY MMD declares under our responsibility that the product is in conformity with the following standards • EN60950-1:2001+A11:2004 (Safety requirement of Information Technology Equipment) • EN55022:2006 + A1:2007 (Radio Disturbance requirement of Information Technology Equipment) •...
- Page 6 4. MMD confirms that if its products are handled properly for their intended use, they are safe to use according to scientific evidence available today. 5. MMD plays an active role in the development of international EMF and safety standards, enabling MMD to anticipate further developments in standardization for early integration in its products. User Manual BDL4635E ...
- Page 7 User Manual BDL4635E INFORMATION FOR UK ONLY WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: 1. Remove fuse cover and fuse.
- Page 8 ○ ○ ○ × × ○ ○ × ○ ○ ○ × ○ ○ ○ × ○ ○ ○ ◦ ◦ User Manual BDL4635E 多溴联苯 多溴二苯醚 （PBB） （PBDE） ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ...
- Page 9 Your new TV/Monitor contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old monitor from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.
-
Page 10: Contents
Contents The BDL4635E monitor pack* should include: • LCD monitor • Power cord (1.8 m) • VGA Signal Cable (1.8 m) • DVI-HDMI Cable (1.8 m) • User Manual • Remote Control and AAA Batteries • Clamper x 2 (To prevent from falling) •... -
Page 11: Elements Name And Functions
User Manual BDL4635E Elements Name and Functions Control Panel POWER button ( ) : To switch the power on/off. MUTE button : To switch the audio mute ON/OFF. INPUT button : Acknowledge a choice while the OSD menu is on or to toggle switch between [HDMI1], [HDMI2], [PC-A], [CVI], [VIDEO<S>] and [VIDEO] while OSD menu is off. -
Page 12: Terminal Panel
EXTERNAL CONTROL (mini D-Sub 9 pin) This for the serial connection when multiple BDL4635E monitors are connected. To achieve remote control through RS232 commands (refer to the RS232 remote control user manual), connect the IN connector with the RS-232C OUT connector of a computer or a multi-connected BDL4635E monitor and connect the OUT connector with the RS-232C IN connector of a next BDL4635E monitor. -
Page 13: Remote Control
User Manual BDL4635E Remote Control POWER button To turn the power on/off. If the LED power indicator is not blinking, then the remote control will not work. SMART PICTURE button To select smart picture mode from [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA]. -
Page 14: Operating Range For The Remote Control
* Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately. Avoid exposure to heat and steam. Other than to install the batteries, do not open the remote control. 30° 30° User Manual BDL4635E ... -
Page 15: How To Mount Or Attach Table Stand To The Lcd Monitor
User Manual BDL4635E How to Mount or Attach Table stand to the LCD Monitor You can install the LCD monitor in one of the following two ways: Method 1: Attach and remove the optional table stand How to install the table stand 1. - Page 16 As shown in the figure below, secure the monitor to a solid wall or pillar using rope (commercially available) strong enough to bear the weight of the monitor(BDL4635E: approx. 34.6 kg). Screw hooks (commercially available), of ring type rather than C-shaped screw hooks (with opening), are recommended.
-
Page 17: Ventilation Requirements For Enclosure Locating
User Manual BDL4635E Ventilation Requirements for enclosure locating To allow heat to disperse, leave space between surrounding objects as shown in the diagram below. ... -
Page 18: Setup Procedure
7. Adjust the sound Make adjustments to lower or to rise the volume as required. 8. Adjust the screen Make adjustments to the display position or settings if required. User Manual BDL4635E Cable Holder ... - Page 19 User Manual BDL4635E 9. Adjust the image Make adjustments to brightness or contrast if required. 10. Recommended Adjustment To reduce the risk of “image persistence”, please adjust the following items based on the application being used. “POWER SAVE”, “PANEL SAVING”, “SIDE BORDER COLOR”, “DATE AND TIME”, “SCHEDULE”.
-
Page 20: Install The Lcd Monitor In Portrait Mode
Install the LCD Monitor in Portrait Mode BDL4635E can be installed in portrait position, under the following conditions: Caution: Portrait mode is effective only when wall-mounted or ceiling-mounted. The table stand can not be used for the monitor in portrait position. -
Page 21: Connectivity
User Manual BDL4635E Connectivity Before making connections: First turn off the power of all the attached devices before make connections. Refer to the user manual of each individual device. Connectivity Diagram BDL4635E (second monitor) BDL4635E DVD player Equipment with... -
Page 22: Connecting To A Personal Computer
HDMI is not a suitable source for audio loop through. PC or IBM compatible To audio output To analog RGB output Mini D-sub 15 pin BDL4635E (second monitor) BDL4635E Mini D-sub 15 pin User Manual BDL4635E ... -
Page 23: Connecting To A Digital Interface Equipment
User Manual BDL4635E Connecting to a Digital Interface Equipment Connections can be made between LCD monitor and other digital equipment that is equipped with a digital interface compliant with the DVI (Digital Visual Interface) standard. Connect the LCD Monitor to a Computer with a Digital Output •... -
Page 24: Connecting To A Dvd Player
• The AUDIO IN 2 , 3 (both of RCA connector type) can be used for audio input. Select [AUDIO 1] ( for 3.5φ phone jack), [AUDIO 2], [AUDIO 3] Or [HDMI] from the AUDIO SOURCE button on the remote control. HDMI (for audio) is selectable only when HDMI 1 or 2 (for video) is selected. BDL4653V BDL4635E User Manual BDL4635E ... -
Page 25: Connecting To A Stereo Amplifier
User Manual BDL4635E Connecting to a Stereo Amplifier You can connect your stereo amplifier to your LCD monitor. Refer to your amplifier's manual for further information. Connect the LCD Monitor to a Stereo Amplifier • Turn on the LCD monitor and the amplifier only after all connections have been finished. -
Page 26: Basic Operation
Before pressing the power button, be sure to turn on the Main Power button on the LCD monitor. 3. Using the remote control. NOTE: Before operating the remote control, be sure to turn on the Main Power Switch on the LCD monitor. User Manual BDL4635E ... -
Page 27: Power Indicator
User Manual BDL4635E Power Indicator Status Power ON Green Power Standby / Power Off AC Power Off Dark Using Power Management Please turn off the LCD monitor when it will not be used for long time. This could potentially increase the life and will for sure decrease the power consumption of the LCD monitor. -
Page 28: Smart Picture Mode
PIP or POP Main:PC-A Sub:VIDEO<S> PC-A 1024 x 768 Main picture Information 48kHz 60Hz AUDIO : 1 VIDEO<S> Sub picture Information NTSC Main picture Information SIZE : FULL STANDARD sRGB STANDARD CINEMA AUDIO1 AUDIO2 AUDIO3 AUDIO2 AUDIO3 User Manual BDL4635E ... -
Page 29: Osd (On-Screen-Display) Controls
User Manual BDL4635E OSD (On-Screen-Display) Controls Press MENU button to open Main menu. Press UP or DOWN button to select sub-menu. Remote Control Press EXIT button to open Main menu. Press UP or DOWN button to select. Control Panel UP or DOWN button... -
Page 30: Picture
NOTE: sRGB picture mode is standard and cannot be changed. NOISE REDUCTION * : INPUT VIDEO<S>, VIDEO only Adjusts the noise reduction level. Press + button to increase reduction level. Press - button to decrease reduction level. User Manual BDL4635E ... -
Page 31: Color Temperature
User Manual BDL4635E TINT * : INPUT HDMI1, 2(HDMI INPUT MODE-HD), CVI, VIDEO<S>, VIDEO only Adjusts the tint of the screen. Press + button the flesh tone color becomes greenish. Press - button the flesh tone color becomes purplish. -
Page 32: Screen
(The upper and the bottom of the image will be cut by expansion.) Dynamic image is the same as FULL size image when HDTV signal is input. Selecting “REAL” image will be displayed 1 by 1 pixel. User Manual BDL4635E ... - Page 33 User Manual BDL4635E CUSTOM ZOOM “CUSTOM ZOOM” will be selected when you select “CUSTOM” on the screen “ZOOM” mode. ZOOM: expands the horizontal and the vertical size simultaneously. HZOOM: expands the horizontal size only. VZOOM: expands the vertical size only.
-
Page 34: Audio
Selecting Audio reset allows you to reset all OSD settings from AUDIO setting. Select “YES” and press “SET” button to restore the factory preset. Press “EXIT” button to cancel and then return to the previous menu. User Manual BDL4635E ... -
Page 35: Pip (Picture In Picture)
User Manual BDL4635E Main-Menu PIP (PICTURE IN PICTURE) Note: The “PIP” and “POP” modes do not function when the screen size is “CUSTOM” or “REAL”. PIP SIZE Selecting the size of picture inserted at the “Picture-in-Picture” (PIP) mode. “Large”, “Middle” and “Small” are available. -
Page 36: Configuration 1
AUTO: NTSC, PAL, SECAM, PAL60 or 4.43 NTSC is automatically selected. NTSC: Specific selection of NTSC. PAL: Specific selection of PAL. SECAM: Specific selection of SECAM. PAL-60: Specific selection of PAL60. 4.43NTSC: Specific selection of 4.43 NTSC. User Manual BDL4635E ... - Page 37 User Manual BDL4635E SAVING MODE Selecting Power Saving Mode “ECO", the monitor will enter standby mode, scheduling and RS232C will be disabled in order to save power. Selecting Power Saving Mode “NORMAL", the monitor will operate normally. CONFIGURATION RESET Selecting the CONFIGURATION RESET allows you to reset all configuration settings.
-
Page 38: Configuration 2
A time between 1 to 24 hours is available. When the SLEEP TIMER is set, the SCHEDULE settings will be disabled. OSD H POSITION Adjusts the horizontal position of the OSD menu. OSD V POSITION Adjusts the vertical position of the OSD menu. User Manual BDL4635E ... -
Page 39: Monitor Information
User Manual BDL4635E MONITOR INFORMATION Indicates the model and serial number of your monitor. ... -
Page 40: Advanced Option
PROGRESSIVE: Enable the IP function, to convert interlace signal to progressive. Normally use this setting. INTERLACE*: Disable the IP function. *NOTE: This mode is better suited for motion pictures, but it increases chance of image retention. User Manual BDL4635E * : INPUT HDMI1,2(HDMI INPUT MODE-HD), VIDEO<S>, VIDEO only ... -
Page 41: Keyboard Control
OFF: Disable the Film mode function. This mode is better suited for Broadcasting or VCR source. IR CONTROL Selects the operation mode of the remote controller when multiple BDL4635E monitors are connected via RS-232C. The item in this menu will become effective by pressing “SET” button on the selected item. - Page 42 MONITOR ID ID numbers for remote control are assigned to BDL4635E monitors that are multi-connected via RS-232C. ID numbers 1 to 26 are selectable. DDC/CI Use to turn ON or OFF the DDC/CI communication function. Select ON for normal use.
-
Page 43: Note
As with all personal display devices, PHILIPS recommends displaying moving images and using a moving panel saving at regular intervals whenever the screen is idle or turning off the monitor when not in use. -
Page 44: Remote Control Numbering Function
26 are selectable. It is recommended to assign sequential ID numbers from 1 and up. 2. The remote control mode of the first BDL4635E monitor is set to PRIMARY and those of the other monitors are set to SECONDARY. -
Page 45: Pixel Defect Policy
This notice explains the different types of pixel defects and defines the acceptable defect level for the BDL4635E LCD screen. In order to qualify for repair under warranty, the number of pixel defects must exceed a certain level which is given in the reference table. - Page 46 Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips LCD- display must have pixel or sub-pixel defects exceeding the tolerances listed in the following table.
-
Page 47: Features
LCD displays is not permanent, you want to prevent this to happen, especially in locations where content is shown 24/7. Compliant with RoHS standards Philips designs and produces display products in compliance with strict Restriction of Hazardous Substances (RoHS) standards that restrict lead and other toxic substances that can harm the environment. -
Page 48: Troubleshooting
NOTE: As with all personal display devices, PHILIPS recommends displaying moving images and using a moving panel saving at regular intervals whenever the screen is idle or turning off the monitor when not in use. - Page 49 User Manual BDL4635E No Sound • Check to see if speaker cable is properly connected. • Check to see if mute is activated. • Check to see if volume is set at minimum. Remote Control doesn’t work • Check the Remote Control’s batteries status.
-
Page 50: Specifications
Remote Controller, AAA Battery x 2, Clamper x 2 (To prevent from falling), Cable belt x 3 (For securing cables), Screw for Main switch cover x 2, Screw for CLAMPER x 2, Cable Holder x 2, Main switch cover. User Manual BDL4635E Digital Input @CR>10 25.0 -165.0 MHz... -
Page 51: Pin Assignment
User Manual BDL4635E Pin Assignment 1) Analog Video Signal Input (Mini D-SUB 15P): PC-A Pin No Name Video Signal Red Video Signal Green Video Signal Blue DDC-GND Red-GND Green-GND Blue-GND +5V (DDC) SYNC-GND DDC-SDA H-SYNC V-SYNC DDC-SCL 2) S-VIDEO input (MINI DIN 4P): V I D E O <S>... - Page 52 User Manual BDL4635E Specifications are subject to change without notice. www.philips.com ...
