HD Multi SeaCam
Operator's Manual
4033 Ruffin Road
San Diego, CA
T:
(858) 576-1261
92123- 1817 USA
F:
(858) 576-0219
®
HD Multi-SeaCam
Record product serial number below as it appears on the nameplate.
Serial #
Connector Type
Pin-outs:
● HD-SDI = Coax
● Ground = Pin ____
● Power = Pin ____
● Analog Video = Pin ____
● Tristate A = PIn ____
● Tristate B = Pin ____
www.deepsea.com
sales@deepsea.com
®
Original Instruction - 1
REV 11/21/16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DeepSea Power & Light HD Multi SeaCam
Summary of Contents for DeepSea Power & Light HD Multi SeaCam
- Page 1 HD Multi SeaCam ® Operator’s Manual ® HD Multi-SeaCam Record product serial number below as it appears on the nameplate. Serial # Connector Type Pin-outs: ● HD-SDI = Coax ● Ground = Pin ____ ● Power = Pin ____ ● Analog Video = Pin ____ ●...
-
Page 2: Specification Overview
Operator’s Manual HD Multi SeaCam ® Specification Overview Standard Connectors Mechanical Specifications Flat Port Dome Port Configuration Housing Aluminum, Titanium SEACON MCBH8 Port Sapphire Optically polished glass hemisphere Pin 1 – DC + Outer Diameter 56 mm [2.20 in] 69 mm [2.72 in] Pin 2 –... - Page 3 Operator’s Manual HD Multi SeaCam ® Specification Overview Dimensions Bracket 5.46 6.29 138.6 159.8 4.88 4.05 124.0 102.8 2.72 2.22 69.1 56.4 1.26 2.04 1.26 1.20 32.0 51.7 32.0 30.5 Fiber [inch] 6.93 6.10 1.69 176.1 154.9 42.9 4x 1/4"-20 5.91...
-
Page 4: Table Of Contents
Operator’s Manual HD Multi SeaCam ® Table of Contents Specification Overview Table of Contents Safety Symbols General Notes and Warnings Pre and Post Dive Inspection Operation Procedure Operation Instruction Camera Output Flooding Repair Procedure Troubleshooting RMA Procedure for Repair Warranty Information... -
Page 5: Safety Symbols
Operator’s Manual HD Multi SeaCam ® Safety Symbol In this operator’s manual and on the product, safety symbols are used to communicate important safety information. This section is provided to improve understanding of these symbols. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. -
Page 6: Flooding Repair Procedure
Operator’s Manual HD Multi SeaCam ® gases. If a camera appears flooded upon personal protective equipment to include, at a mini- removal from the water, it should be treated mum, eye and hand protection. as potentially dangerous. Point the camera away from persons and valuable equipment 1. -
Page 7: Warranty Information
Operator’s Manual HD Multi SeaCam ® Inc. within such 90 day or one year warranty period, the sole obligation of DeepSea Power & Light, Inc. shall be to DeepSea Power & Light furnish new or repaired parts free of charge in exchange... -
Page 8: Appendix A: Tristate Input Camera Control
Operator’s Manual HD Multi SeaCam ® Appendix A Tristate Input Camera Control... - Page 9 1.1 Tristate Controls The HD Multi SeaCam can be configured with dual tristate input control pins which are mapped to control the on screen display menu of the internal HD camera module. The two control pins are referred to as Tristate A and Tristate B.
- Page 10 Operator’s Manual HD Multi SeaCam ® 1.5 OSD Menu Structure FACTORY MAIN MENU SUB MENU1 SUB MENU2 SUB MENU3 VALUE DEFAULT FOCUS ADJ RETURN NORMAL / MODE DEBLUR LENS ELC - NORMAL INDOOR / MODE OUTDOOR / DEBLUR BRIGHTNESS 0 - 20...
- Page 11 Operator’s Manual HD Multi SeaCam ® FACTORY MAIN MENU SUB MENU1 SUB MENU2 SUB MENU3 VALUE DEFAULT SHARPNESS 0 - 10 GAMMA 0.45 - 0.65 0.55 COLOR GAIN 0 - 20 MIRROR OFF / ON FLIP OFF / ON D-ZOOM X1.0 –...
- Page 12 Operator’s Manual HD Multi SeaCam ® USER OFFSET 0 - 20 IMAGE RANGE FULL USER – 8 COMP OUTPUT MODE 1080P / 720P 1080P HD-CbCr / YUV / COLOR SPACE HD-CbCr SD-CbCr [30FPS / 25FPS] / FRAME RATE 30FPS SYSTEM...
- Page 13 The HD Multi SeaCam is equipped with a fixed aperture lens lending the ALC function inert, however laboratory testing has shown that the ALC mode is still preferred as the default setting due to the small sensing area used in the ELC algorithms.
- Page 14 The Motion Detection engine can be used to highlight parts of the image that change from one video frame to the next. It will draw red outline boxes around those areas that meet the change threshold set by the user. The hardware alarm feature is not supported by the HD Multi SeaCam.
- Page 15 SYSTEM – Video Format Settings and Camera System Options 1.5.10 1.5.10.1 The COM menu is used by some of the internal functions of the HD Multi SeaCam. Access to these settings through the OSD menu is restricted. IMAGE RANGE 1.5.10.2 The IMAGE RANGE options change the apparent brightness of the video image.
-
Page 16: Factory Reset
Operator’s Manual HD Multi SeaCam ® Factory Reset Returning the HD Multi SeaCam camera to the factory supplied settings can be done through the Tristate input control pins. 1.5.1 Tristate Input Factory Reset Method To reset the camera using the two Tristate inputs, hold Tristate A and Tristate B high for 5 seconds. After 5 seconds the camera will undergo a brief reset sequence during which the camera video outputs will be disabled and there will be no image available.
