Dear user!
Thank you for buying Neoline Wide S45 video recorder. Study this manual
thoroughly in order to use the device correctly and to make its service life longer.
Do not throw the user manual away because you may need to consult it in future.
[ Table of Contents ]
Operating conditions .....................................................................................................................2
Technical characteristics ...............................................................................................................3
Completing parts ............................................................................................................................3
Description of connectors and buttons ..................................................................................4
Meaning of buttons ........................................................................................................................5
Special functions .............................................................................................................................6
Operation guide ..............................................................................................................................9
System menu ................................................................................................................................. 10
Video mode ................................................................................................................................................ 10
Photo mode ............................................................................................................................................... 11
Playback mode .......................................................................................................................................... 12
Settings ........................................................................................................................................................ 12
Possible problems and their causes ...................................................................................... 13
1
Advertisement
Table of Contents
Related Manuals for Neoline Wide S45
Summary of Contents for Neoline Wide S45
-
Page 1: Table Of Contents
Dear user! Thank you for buying Neoline Wide S45 video recorder. Study this manual thoroughly in order to use the device correctly and to make its service life longer. Do not throw the user manual away because you may need to consult it in future. -
Page 2: Operating Conditions
• Disassembling or modifying of the device is forbidden • Neoline Company is not liable for the loss of data and/or any damage – direct or indirect – sustained by the user or a third party due to improper usage of the device or software, inadequate installation, or application of accessories that are not included in the accessory kit. -
Page 3: Technical Characteristics
• Car charger input: DC 12-24V • Dimensions (mm): 88x52x16 (35 with lens) • Weight: 91g [ Completing parts ] • Neoline Wide S45 video recorder • Rear view camera • Mounting with a suction cup • Car charger • Cable for rear view camera connection •... -
Page 4: Description Of Connectors And Buttons
[ Description of connectors and buttons ] 10 11 12 13 14 15 1) Microphone 2) TF card slot 3) AV input 4) USB connector 5) Display 6) HDMI connector 7) Speaker 8) Lens 9) On/off feeding button (POWER) 10) Up button (UP) 11) Up button (UP) 12) OK button 13) Mode button (MODE) -
Page 5: Meaning Of Buttons
[ Meaning of buttons ] POWER on/off button: Prolonged press switches the device on/off. Short press the button in Operating mode to switch the screen lighting on/off. UP button: Short press the button to switch between the basic and the additional camera. In Menu, this button is used for moving along Menu items (upwards);... -
Page 6: Special Functions
Before installing the memory card switch the device off ATTENTION: Make sure that the memory card‘s position is right. Your attempt to insert the memory card facing the wrong direction may bring about damage to the device and also to the memory card Warning: НDo not apply too much force when installing the memory card to avoid damage to the device. - Page 7 ATTENTION: If after the engine switch off the feeding to 12/24 V car socket does not stop, the auto switch off function will not be activated. Consult your car operation documents or car manufacturer for more detailed information about your 12/24 V socket. Urgent recording function It is meant for protecting current video file from re-recording or removing .
- Page 8 [Rear view camera mounting and using] 1. Mount your rear view camera as shown in Fig.1. video recorder camera black rear light car body 2. Fix the camera on the rear bumper by means of self-tapping screws or inside the car using 3M scotch tape (from the kit) as shown in Fig.2. 3.
-
Page 9: Operation Guide
[ Operation guide ] Connection to 12/24V car socket. Plug in the charger to 12/24 car socket. Upon starting the engine (supplying power to 12/24V car socket) the device will begin to record automatically. Upon shutting off the engine (disconnection of power supply to 12/24V car socket) the device will stop recording automatically and save recorded files. -
Page 10: System Menu
[System menu] Menu has 4 modes: Video (settings in Video mode), Photo (settings in Photo mode), Playback (settings in Playback mode), and Settings (general settings in any mode). They allow setting different modes of video recorder’s operation. Video Stop the recording, press Menu button, and select any menu item for setting. Video Description Submenu... -
Page 11: Photo Mode
Photo In Photo mode, press Menu button, and select any menu item for setting. Photo Description Submenu Shooting Selecting the momentum Single/2sec.timer/5sec.timer/10 sec.timer mode photo function or timer setting Resolution Selecting the resolution 12M/10M/8M/5M/3M/2MHD/1.3/VGA Burst shot Function 3x frames in On/Off succession Quality... -
Page 12: Playback Mode
Playback In Playback mode, press Menu button, and select any menu item for setting. Playback Description Submenu Remove Removing the video or image Remove current /Remove all Protection Protecting the video or image Block current/ against removal Unblock current/ Block ALL/ Unblock ALL Slide show Selecting the interval for automated... -
Page 13: Possible Problems And Their Causes
[ Possible problems and their causes ] If any problems with the device emerge although the equipment maintenance and operation terms have been observed, read this section to solve them. - It is impossible to shoot photos and record videos. Check if there is enough free space on Micro SD card, and if it is not blocked. - Page 14 - Hang (no image on the display, no reaction to pressing on buttons). For starting a forced reset of the device press RESET button.
