What is the effective range of the Midland MXT115 radio?

The MXT115 is designed to provide maximum operating range under optimum conditions. Optimum conditions include operating over water, in open rural areas without obstructions, or on flat areas where you can see the other radio user. To ensure maximum range, mount the included antenna as high as possible on your vehicle and set your radio to use Hi power. For more information, see page 7 of the manual.

Do I need a license to operate the Midland MXT115?

Yes, you must be licensed by the Federal Communications Commission (FCC) prior to operating the MXT115 on channels 1-7, 15-22, and repeater channels 15-22, which comprise the GMRS channels. Unlicensed use of GMRS channels can result in serious penalties. You will be issued a call sign by the FCC for station identification. For more information, see page 3 of the manual.

Is the Midland MXT115 a GMRS radio?

Yes, the Midland MXT115 is a GMRS 2-way radio. It operates on GMRS (General Mobile Radio Service) frequencies and requires a Federal Communications Commission (FCC) license for operation.

Why is my Midland MXT115 not receiving transmissions?

If your Midland MXT115 is not receiving transmissions, you should:Verify both radios have the same channel selection and Privacy Code settings.Make sure you are within range of the other radio.Confirm communication is not affected by buildings and other structures. For more information, see page 13 of the manual.

Can the Midland MXT115 communicate with other walkie-talkies?

To communicate between two radios, both radios must be set to the same channel and Privacy Code selections.

What frequencies does the Midland MXT115 operate on?

The Midland MXT115 operates on UHF frequencies. The operating frequency range is 462.5500 ~ 462.725 MHz, and the repeater frequency range is 467.5500 ~ 467.725 MHz. For more information, see page 14 of the manual.

How do I scan channels on the Midland MXT115?

To scan channels on the Midland MXT115, you can use the "auto-scan" mode:Ensure the radio is turned on.Press and release the Monitor/Scan button to enter "auto-scan" mode. The Scanning icon will appear on the LCD display. The radio will rapidly scan through the 15 available channels and pause on any active channel. "Auto-scan" will resume after four seconds of no activity.To transmit during auto-scan, press and hold the PTT button on the microphone while the radio is paused on the desired channel. The radio will remain on the active channel for three seconds after the PTT button is released.To exit "auto-scan" mode, press and release the Monitor/Scan button. The Scanning icon will turn off. For more information, see page 9 of the manual.

What kind of antenna is recommended for the Midland MXT115?

The MXT115 includes a "magnetic mount" antenna intended for attachment to the vehicle's roof, trunk, or similar location. To aid radio performance, it is recommended to mount the antenna as high on the vehicle as possible, preferably in the center of whatever surface you choose. For more information, see page 4 of the manual.

Does the Midland MXT115 have weather alert capabilities?

Yes, the Midland MXT115 has a NOAA Weather Radio function to receive weather reports and a NOAA Weather Scan function to scan all 10 channels for the NOAA National Weather Service. It also has a Weather Alert feature that will sound a siren when a weather alert goes off. For more information, see page 9 of the manual.

Can I use privacy codes on the Midland MXT115?

Yes, the Midland MXT115 has 142 Privacy Codes (38 CTCSS codes and 104 DCS codes) that can be applied to any channel. When a Privacy Code is enabled for a selected channel, the channel is muted to all incoming signals unless they carry the correct CTCSS or DCS tone. To communicate, both radios must be set to the same channel and Privacy Code selections. For more information, see page 10 of the manual.

How do I install the mounting bracket for the Midland MXT115?

To install the mounting bracket for the Midland MXT115, follow these steps:Use the mounting bracket as a template to mark the location of each screw hole under the dash using a nail or other sharp pointed object.Attach the bracket to the dash with the provided Phillips head sheet metal screws, tightening them securely but without over-tightening.Slide the radio into the mounting bracket, ensuring the retainers engage the slots in the sides of the radio to prevent movement while driving. For more information, see page 4 of the manual.

What is the best way to power the Midland MXT115 in a vehicle?

The Midland MXT115 can be powered in a vehicle using the supplied cigarette lighter adapter by simply plugging it into the vehicle's cigarette lighter. For a "hard-wired" installation, you can cut the power cord after the adapter and connect the positive lead (RED wire with in-line fuse holder) to the fuse block or directly to the positive post of the vehicle's battery. The ground lead (BLACK wire) should be connected directly to the vehicle's metal frame. For more information, see page 5 of the manual.

How do I reset the Midland MXT115 to factory settings?

To reset the Midland MXT115 to factory settings:Ensure the radio is turned off.Press and hold the PTT and the Weather buttons simultaneously.While holding the buttons, turn on the radio. All user settings will be cleared, returning the radio to default settings. For more information, see page 13 of the manual.

What is the Midland MXT115 MicroMobile radio?

The Midland MXT115 is a MicroMobile GMRS 2-way radio. It is designed for General Mobile Radio Service (GMRS) operation and is described as a compact package that is big on performance, featuring state-of-the-art high-tech engineering.

How do I adjust the squelch level on the Midland MXT115?

To adjust the squelch sensitivity on the Midland MXT115:Press the Menu button to enter "Menu" mode.Use the Channel Up or Channel Down button to scroll until the LCD display shows "Sq".Press the Monitor/Scan button to confirm your selection.Use the Channel Up or Channel Down button to select the desired squelch level, from "oF" to "09". The default setting is "04".Press the Monitor/Scan button to confirm your selection. If you do not confirm, the squelch sensitivity will not be changed. For more information, see page 11 of the manual.

What type of power cord does the Midland MXT115 use?

The Midland MXT115 uses a power cord supplied with a cigarette lighter adapter for easy installation. For a hard-wired installation, the power cord can be connected to the vehicle's electrical system by cutting the cord just after the cigarette lighter adapter and connecting the positive lead (RED wire with in-line fuse holder) to the fuse block or directly to the positive post of the vehicle's battery. The ground lead (BLACK wire) should be securely connected directly to the vehicle's metal frame. For more information, see page 5 of the manual.

Using An External Speaker; Controls And Indicators; Connecting The Microphone - Midland Mxt115 Owner's Manual

Hide thumbs Also See for MXT115:

Manual (30 pages)

User manual

Table Of Contents

Table of Contents

Enlarged version

Electrical and Rear Panel Connections

Refer to Rear Panel Connections for rear panel connector locations.

NOTE: Radio antenna is installed separately.

1. The power cord supplied with the MXT115 is equipped with a cigarette

lighter adapter for easy installation. Simply plug the connector into the

vehicle's cigarette lighter. If a "hard-wired" installation is desired, connect

the power cord to the vehicle's electrical system as follows:

▪

Cut the power cord just after the cigarette lighter adapter.

▪

Connect the positive lead (RED wire with in-line fuse holder) to

either (a) the fuse block or (b) directly to the positive post of the

vehicle's battery.

NOTE: The fuse block is usually the most convenient connection

point. The power cord positive lead can also be connected to the

accessory terminal on the fuse block or ignition switch, so the radio

automatically turns off when the ignition is turned off.

▪

Securely connect the ground lead (BLACK wire) directly to the

vehicle's metal frame. A good direct metal-to-metal ground is

essential for optimum performance.

2. Attach the antenna cable to the ANT jack on the rear panel.

3. If desired, an optional external speaker (purchased separately) can be

connected to the EXT SPKR jack (see Using an External Speaker).

Connecting the Microphone

Insert the RJ11 connector into the front of the MXT115. The microphone

mounting bracket can be attached to the vehicle dash or other convienent

location in a manner similar to the radio's mounting bracket..

Page 8

Model MXT115

Using an External Speaker

The MXT115 provides a rear-panel jack for connection of an optional

external speaker (purchased separately).

When selecting an external speaker, ensure the speaker has 8-ohm

impedance and is rated for 4.0 watts.

NOTE: When an external speaker is connected, the radio's internal

speaker is automatically disabled.

CONTROLS AND INDICATORS

Operating Controls

1. LCD Display

2. On/Off Volume

3. Microphone Jack

4. USB Charging Jack

keypad

monitor mode

midlandusa.com

Menu - Press to access menu

Weather - Press to access weather mode

Call /

Lock - Press to send a call signal, or long press to lock the

Monitor /

Scan - Press to enter scan mode, or long press to enter

Model MXT115

Page 9
