E 14 - Gas error, push gas reset button
Gas resetting
See on the preprevious page.
error analysis
E – 14
1. Is there a
short-lived
flame at
the ignition
attempt?
2. Is an ignition
spark present?
3. Is the gas
supply/nozzle
pressure okay?
4. Is the current
between the
connector and
the ionisation at
least 0.9µA DC.
troubleshooting
Is the flame sensor
placed in the flame / is
YES
the sensor's electrical
connection okay?
NO
Go to step 2.
YES
Go to step 3.
Is the ignition electrode
NO
placed correctly / is the
connection okay?
YES
Replace the ignition
control or gas valve.
NO
Ventilate the gas system /
contact gas supplier.
Is there continuity in the
NO
harness?
YES
Replace the
ignition control.
Adjust / clean
NO
the electrode /
connections.
YES
Go to step 3.
Adjust / clean
NO
/ replace the
electrode.
YES
Adjust the sensor.
NO
Replace the sensor.
