E 08 - Machine overheated
error description
There is an overheating thermostat with a manual reset on both air inlet and outlet.
These thermostats are connected with each other in series.
The error code indicates that one or the overheating thermostats, or their associated wi-
res, has opened.
A defective PCB can also cause this error.
The dryer stops operating.
error analysis
E – 08
1. Have either of the
heating thermostats
tripped?
2. Has fuse FH300
blown?
3. Disconnect P1 and
P2 from the PCB.
Check for continuity
over the heat
thermostate F5/F6.
Is the circuit closed?
4.Missing air flow.
5. Check the inlet/
outlet temperature.
troubleshooting
Reset the overheating
thermostat.
Restart the tumble dryer.
YES
Check steps 4 and 5.
NO
Go to step 2.
Replace the fuse and
YES
restart the dryer.
NO
Go to step 3.
YES
Replace PCB.
NO
Go to step 4.
See Check list - error
codes related to
overheating
Are there any errors
according to the list?
Is the inlet and outlet
temperature parameter set
correctly?
Inlet:
Factory setting for Inlet
temperature: Menu 5-2-1.
outlet:
Factory setting for outlet
temperature: Menu 2-1-1, 2-2-
1, 2-3-1, etc. up to 2-11-1.
YES
Correct the error
from the check list.
NO
Go to step 5.
YES
Replace PCB.
Enter the
NO
programming mode
and adjust the
parameter.
