SJA9192/17
EN
User manual
2
SP
Manual de utilizador 20

Advertisement

Chapters

Table of Contents
loading

Summary of Contents for Philips SJA9192/17

  • Page 1 SJA9192/17 User manual Manual de utilizador 20...
  • Page 2: Table Of Contents

    Contents Special Features Control Locations Installation Operation LCD Prompts Troubleshooting Care & Maintenance Technical Support Warranty...
  • Page 3: Special Features

    Special Features Special Features • 6.5" x 2.25" Large Liquid Crystal Display - displays three full lines of information including time of the call. • Caller ID Record* - stores up to 90 Caller ID records each of which up to 14 digits number and 15 characters name. •...
  • Page 4: Control Locations

    Control Locations Control Locations 1. Message Waiting Light Indicator (red LED) - lights up steadily when you have new voice mail messages. 2. New Call Light Indicator (green LED) - lights up steadily when new calls are received. 3. Visual Display Panel - shows the caller’s name and / or number, incoming call time &...
  • Page 5: Installation

    Installation a) Caller ID unit b) Stand studs AC power adapter d) Long phone line cord 1 pc e) Short phone line cord 1 pc INSTALLING BATTERIES Please install 4 x AAA batteries (alkaline batteries are recommended) to retain the Caller ID records and keep real time clock running in case there is a power failure.
  • Page 6 Installation The AC adapter must be a Class 2 Power Source, 9V DC, 200mA TEL. LINE PHONE Connecting to a telephone and/or answering machine After installing 4 x AAA batteries, connect one end of the line cord provided into your Caller ID unit's jack labeled TEL. LINE and connect the other end of the line cord into the telephone wall jack.
  • Page 7: Operation

    Operation Operation IDLE MODE When your Caller ID unit is in idle mode, the calls status and clock are shown on the LCD display : SETUP MENU There are five options in the setup menu. Set Language Allows you to select the LCD display prompts in English, Spanish or French.
  • Page 8 Operation Set Time / Date Allows you to set the clock (hour and minute) and date (month and day).The clock will also be updated by incoming Caller ID, if you have subscribed to Caller ID service. The clock is set at “12:00AM 01/01” when ex-factory.
  • Page 9 Operation Sequence number of this incoming call It is a new call Time and date when this call was received. 12:00AM 01/01 CALL #80 NEW 249-342-363 JOHN SMITH You have new voice mail Caller's number message(s) Caller's name CALLER ID MEMORY If you have subscribed to the Caller ID service from your local tele- phone company, your Caller ID unit will receive and display incoming caller’s name (if applicable) and number together with the date and time...
  • Page 10 Operation c) The New Call Light Indicator does not stop lighting up unless you have reviewed ALL new incoming calls by pressing [REVIEW or [REVIEW ] button. VOICE MAIL If you have subscribed to Voice Mail service from your local telephone company, the Message Waiting Light Indicator lights up steadily when you have voice mails in your mailbox, and the LCD icon ( on the LCD display.
  • Page 11 Operation The LCD display shows “PICK UP OR ADJ” after you press [DIAL] button. 3. Press [DIAL] button again to change number format among: a) 7 digits (phone number) b) 10 digits (area code + phone number) c) 11 digits (1 + area code + phone number) 4.
  • Page 12 Operation...
  • Page 13: Lcd Prompts

    LCD prompts...
  • Page 14: Troubleshooting

    Troubleshooting Symptoms The display is blank The display is faded Caller ID doesn’t work No caller’s name The New Call Light Indicator (green) lights up The New Call Light Indicator (green) doesn’t light up if there is new call. The Message Waiting Light Indicator (red) doesn’t light u p i f y o u h a v e v o i c e messages...
  • Page 15: Care & Maintenance

    Care & Maintenance Care & Maintenance The following suggestions will help you care for the system so you can enjoy it for years. Keep the unit dry. If it gets wet, wipe it dry immediately. Liquids might contain minerals that can corrode the electronic circuits. Use and store the Caller ID only in normal temperature environments.
  • Page 16: Technical Support

    Philips Electronics warrants to the original purchaser of this product ("Consumer" or "you") that the product and all accessories provided by Philips in original package ("Product") are free from material defects in material and workmanship, subject to the terms and conditions set forth below, when installed and used normally and in accordance with operation instructions.
  • Page 17 Warranty What will Philips do if the product is not free from material defects in materials and workmanship during the limited war- ranty period ("Materially Defective Product")? During the limited warranty period, Philips will replace without charge, a materially defective product. Philips will return repaired or replace- ment products to you in working condition.
  • Page 18 If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warran- ty, Philips will notify you and will request that you authorize the cost of replacement and return shipping costs for conditions not cov- ered by this limited warranty.
  • Page 19 In no event shall Philips be liable for any indirect, special, incidental, con- sequential, or similar damages (including, but not limited to lost profits...
  • Page 20 Contenido Características especiales Controle las Ubicaciones 22 Instalación Operación Localización de fallas Cuide y Limpiar Asistencia Técnica Garantía...
  • Page 21: Características Especiales

    Características especiales Características especiales • Pantalla grande de cristal líquido de 6.5" x 2.25": presenta tres líneas completas de información, que incluye la hora de la llamada. • Registro de identificación de llamada*: almacena un máximo de 90 registros de identificación de llamada, con números de un máximo de 14 dígitos y nombres de hasta 15 caracteres.
  • Page 22: Controle Las Ubicaciones

    Controle las Ubicaciones Controle las Ubicaciones 1. Indicador luminoso de mensaje en espera (LED rojo): se ilumina ininterrumpidamente si hay nuevos mensajes de voz en el buzón. 2. Indicador luminoso de llamada nueva (LED verde): se ilumina inin- terrumpidamente si hay llamadas nuevas. 3.
  • Page 23: Instalación

    Instalación Instalación SE NECESITA EL ADAPTADOR DE CA QUE ACOMPAÑA A LA UNIDAD DE IDENTIFICACIÓN DE LLAMADAS PARA QUE ÉSTA PUEDA FUNCIONAR. SE RECOMIENDA, SIN EMBARGO, INSTA- LAR 4 PILAS AAA PARA PREVENIR LA PÉRDIDA DE LA MEMORIA EN CASO DE PRODUCIRSE UN CORTE DE ENERGÍA. Verifique el contenido de todos los accesorios incluidos con la unidad de identificación de llamadas.
  • Page 24 Instalación El adaptador de CA debe ser una fuente de potencia clase 2, para 9 V de CC y 200 mA Elimine las pilas viejas de manera correcta y con prontitud. No las queme ni las entierre. Cambie las pilas si aparece el icono indicador de pilas agotadas ( Desconecte la línea telefónica.
  • Page 25: Operación

    Instalación TEL. LINE PHONE Operación COLOCACIÓN DE LA UNIDAD SOBRE EL ESCRITORIO Inserte las ranuras de los dos soportes verticales en las pestañas cor- respondientes situadas en el fondo de la caja. Luego deslice los soportes verticales siguiendo las pestañas hasta que queden trabados en el fondo de la caja.
  • Page 26 Operación Presione el botón [REVIEW cionar inglés, francés o español. Presione el botón [DIAL] para guardar el valor de ajuste y pulse el botón [REVIEW ] para pasar a la siguiente opción de ajuste, SET AREA CODE. Set Area Code (Fijar código de área) Los códigos de área de todas las llamadas entrantes serán compara- das con el código de área que el usuario ingresó...
  • Page 27 Operación Set Contrast (Ajustar contraste) Permite ajustar el contraste de la pantalla de cristal líquido en 8 nive- les diferentes. El valor predeterminado de fábrica es 4. Presione el botón [DIAL] cuando “SET CONTRAST” aparezca en la pantalla. Presione el botón [REVIEW minuir o aumentar el contraste de la pantalla de cristal líquido.
  • Page 28 Operación secuencie el número de la llamada de fuera es una llamada El tiempo y la fecha nueva cuando la llamada se recibe 12:00AM 01/01 CALL #80 NEW 249-342-363 JOHN SMITH usted tiene los número de persona mensajes nuevos que llama de buzón de voz El tiempo y la fecha cuando la llamada se recibenombre de...
  • Page 29 Operación Nota: Usted o el contestador automático deben contestar la nueva llamada entrante solamente después del primer timbre. De otro modo, no quedará grabada la información sobre la nueva llamada entrante. Si el adaptador de CA no está conectado, el indicador lumi- noso de llamada nueva destellará...
  • Page 30 Operación MARCACIÓN DE NÚMEROS CON LA UNIDAD DE IDENTIFICACIÓN DE LLAMADAS Cuando revisa el registro de una identificación de llamada, presione el botón [DIAL] para marcar el número que aparece en la pantalla de cristal líquido. Si el formato del número de la llamada identificada no es ajustable, aparece en pantalla “PICK UP HANDSET”.
  • Page 31 Operación ciones de llamada. Si desea suprimir uno de los registros de identificación de llamada Mientras revisa el registro de una llamada identificada, pre- sione el botón [DELETE] y aparecerá en la pantalla “DELETE CALL?”. Presione nuevamente el botón [DELETE] para efectuar la supresión.
  • Page 33: Localización De Fallas

    Localización de fallas Sintomas La pantalla est á Aseg ú rese que el adaptador de corriente alterna est é en blanco conectado al enchufe etiquetado DC 9V al reverso de su unidad de Identificador de Llamadas y enchufado al socket de la pared que no est á...
  • Page 34: Cuide Y Limpiar

    Cuide y Limpiar B E L Cuide y Limpiar Observe las siguientes sugerencias de cuidado de la unidad para que la pueda usar por muchos años. • Mantenga seco el Caller ID. Séquelo de inmediato si se moja. Los líquidos podrían contener minerales que pueden corroer los circuitos electrónicos.
  • Page 35: Asistencia Técnica

    PHILIPS Electronics garantiza al comprador original de este pro- ducto (en adelante, el "consumidor" o "usted") que el producto y todos los accesorios incluidos por Philips en el envase original (en adelante, el "producto") están libres de todo defecto importante de material y mano de obra, sujeto a las condiciones indicadas a continuación, si se lo instala y utiliza normalmente y de conformi-...
  • Page 36 Problemas causados por el uso de la unidad con accesorios eléctricos no ofrecidos por Philips. Se han quitado o alterado las etiquetas de garantía/calidad, las placas de número de serie o los números de serie electróni- cos del producto, o se los dejó...
  • Page 37 Esta garantía representa el convenio definitivo y exclusivo que usted y Philips han celebrado, y sustituye las demás comunica- ciones escritas o verbales que se refieren al producto. Philips no ofrece ninguna otra garantía para el producto. La garantía describe exclusivamente todas las responsabilidades que Philips tiene respecto al producto.
  • Page 38 Philips no será tenido por responsable de los daños indirectos, cuantificables, incidentales o similares (entre otros, la pérdida de...
  • Page 40 Specifications are subject to change without notice Trademarks are property of Philips Accessories and Computer Peripherals 2006© Philips Accessories and Computer Peripherals, Ledgewood, NJ USA Printed in China www.philips.com...
