Philco PVD1000 Owner's Manual

Philco dvd/cd player owner's manual
Hide thumbs Also See for PVD1000:
Table of Contents

Advertisement

Quick Links

Enlarged version
Owner's Manual
Please read before using this unit.
DVD/CD Player
PVD1000
Supplied Accessories
Remote control
Audio/Video cables
(NB079UD) with
(WPZ0102TM015/
two AA batteries
WPZ0102LTE01)
Connecting to RF Modulator
If your TV has AUDIO/VIDEO input jacks, see the section
"Connections" on page 6. If not, it is still possible to
connect this unit to your TV by using a STEREO AUDIO/
VIDEO RF modulator (commercially available). In this
case, follow the instructions below.
1) Connect the AUDIO/VIDEO output jacks of this unit to the
AUDIO/VIDEO input jacks of your RF modulator by
Audio / Video cables.
2) The antenna input jack of your TV may have been already
occupied. If so, disconnect the RF cable from your TV,
and then connect the RF cable to your RF modulator
(usually marked "ANT IN").
3) Connect your RF modulator to your TV by another RF
cable.
4) Set your RF modulator's channel 3/4 switch to either 3
or 4, whichever TV channel is least used in your area. If
your RF modulator has a modulator/antenna switch, set it
according to your RF modulator's manual.
5) Turn on your TV and choose the same channel as you set
the RF modulator's channel 3/4 switch to. For more details,
follow the instructions supplied with the RF modulator.
If your TV does not have AUDIO / VIDEO input jacks.
Antenna
Cable
Signal
STEREO AUDIO / VIDEO RF Modulator
(commercially available)
AC 120V
ANT IN
CHANNEL
TO TV
VIDEO
AUDIO
3
4
R
2
3
Hint
• The quality of picture may become poor if the unit is connected to
an RF modulator.
If you need additional operating assistance
after reading this owner's manual, please call
TOLL FREE : 1-800-317-6062
or visit our web site at
http://www.funai-corp.com
Owner's Manual
(1VMN23217)
Owner's Manual
(Back of this unit)
L
AUDIO OUT
DIGITAL
AUDIO OUT
(Back of TV)
COAXIAL
R
VIDEO
S-VIDEO
OUT
OUT
1
L
Audio/Video
Cables
(Supplied)
Antenna in jack
RF Cable (Not supplied)
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Table of Contents

Precautions
Laser Safety ...................................................................2
■ Important Safeguards ..................................................3
Location and Handling ....................................................4
Warning of Dew Formation .............................................4
About Copyright ..............................................................4
Symbols Used in This Manual ........................................4
Maintenance ...................................................................4
■ About the Media............................................................5
Playable Media ...............................................................5
Unplayable Media ...........................................................5
■ Connections ..................................................................6
Connection to a TV .........................................................6
Connection to an Audio System .....................................7
Rear Terminals ...............................................................7
■ About the Remote Control ...........................................8
Remote Control ..............................................................8
■ Playback ........................................................................9
■ On-Screen Display ......................................................10
■ Search Function .........................................................10
Using Title / Chapter Search ........................................10
Using Track Search ......................................................10
Using Time Search .......................................................11
Marker Setup ................................................................11
Repeat Playback ..........................................................12
Repeat A-B Playback ...................................................12
Random Playback ........................................................12
Programmed Playback .................................................12
■ Special Settings ..........................................................13
Subtitle Language .........................................................13
Audio Language ...........................................................13
Camera Angles .............................................................13
Black Level Setting .......................................................13
Stereo Sound Mode......................................................13
Virtual Surround ............................................................13
■ DVD Setup ...................................................................14
LANGUAGE Setting .....................................................14
DISPLAY Setting ..........................................................15
AUDIO Setting ..............................................................15
PARENTAL Setting ......................................................16
OTHERS Setting ..........................................................16
(except for PARENTAL Setting) ...................................17
■ Troubleshooting Guide ..............................................17
■ Specifications .............................................................18
■ Language Code List ...................................................18
■ Limited Warranty ........................................................ 18
■ Español ........................................................................19
■ Quick Use Guide ......................................... Back Cover

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PVD1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PVD1000

Summary of Contents for Philco PVD1000

  • Page 1: Table Of Contents

    Owner’s Manual Please read before using this unit. DVD/CD Player PVD1000 Supplied Accessories Remote control Audio/Video cables (NB079UD) with (WPZ0102TM015/ two AA batteries WPZ0102LTE01) Connecting to RF Modulator If your TV has AUDIO/VIDEO input jacks, see the section “Connections” on page 6. If not, it is still possible to connect this unit to your TV by using a STEREO AUDIO/ VIDEO RF modulator (commercially available).

  • Page 2: Laser Safety

    WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS 1) Read Instructions - All the safety and operating instruc- tions should be read before the product is operated. 2) Retain Instructions - The safety and operating instruc- tions should be retained for future reference. 3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.

  • Page 4: Location And Handling

    Location and Handling • Do not stand this unit up vertically. Install this unit in a horizontal and stable position. Do not place anything directly on top of this unit. Do not place this unit directly on top of the TV. •...

  • Page 5: About The Media

    About the Media Playable Media Playable Mark (logo) discs DVD-Video *1, 2, 4, 6 DVD-R DVD-RW *1, 3, 4, 5, 6, 7, 9, 10 DVD+R DVD+RW *1, 3, 4, 5, 6, 8, 9, 10 Video CD *4, 6, 11 Audio CD *4, 6 CD-R CD-RW...

  • Page 6: Setup

    Connections If your TV has AUDIO/VIDEO input jacks, see the following instructions. If not, see the section “Connecting to RF Modulator” on the front page. Connection to a TV Basic Audio AUDIO IN Audio cable (supplied) This unit AUDIO OUT AUDIO OUT DIGITAL AUDIO OUT...

  • Page 7: Connection To An Audio System

    Connection to an Audio System Playing 2 channel audio Stereo system Analog audio input jacks AUDIO Audio cable (supplied) This unit AUDIO OUT Hint • Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers. Rear Terminals AUDIO OUT DIGITAL...

  • Page 8: About The Remote Control

    About the Remote Control Remote Control STANDBY-ON OPEN/CLOSE SEARCH DISPLAY MODE AUDIO SUBTITLE ANGLE REPEAT CLEAR PAUSE SKIP SLOW PLAY STOP SETUP TOP MENU MENU MODE ENTER ZOOM RETURN Installing the Batteries for the Remote Control Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.

  • Page 9: Functions

    Operations described in this section are mainly based on the remote control use. Some operations can be carried out on main unit. Playback Before: Turn on the TV, amplifier and any other equipment which are connected to this unit. Make sure the TV and audio receiver (commercially available) are set to the correct channel.

  • Page 10: On-Screen Display

    On-Screen Display You can check the information about the current disc by pressing [DISPLAY] on the remote control. Angle icon appears in a case multi- angle is available on the DVD. DISPLAY Current playback status 11/16 0:00:00 - 0:03:30 Remaining time of the current chapter Elapsed time of the current chapter CH (Chapter):...

  • Page 11: Using Time Search

    Search Function Using Time Search Press [SEARCH MODE] Press the desired time repeatedly until the Time location on the disc, using Search display appears the Number buttons within during playback. 30 seconds. SEARCH MODE PLAY TOTAL 1:29:00 Hint • When there is no need to enter a number, “0” appears automatically.

  • Page 12: Repeat / Random / Programmed Playback

    Repeat / Random / Programmed Playback Repeat Playback Repeat function is available only during playback. Press [REPEAT] during playback. REPEAT PLAY <Example: DVD> Each time you press [REPEAT], repeat function changes as example below. (repeat off) CHAPTER (current chapter repeat) TITLE (current title repeat) (repeat off)

  • Page 13: Special Settings

    Special Settings Subtitle Language This unit allows you to select a subtitle language (if available) during DVD playback. OFF (no subtitles) Press [SUBTITLE] during playback. SUBTITLE ENG (English subtitles) PLAY FRE (French subtitles) 1.ENG/6 Each time you press [SUBTITLE], subtitle language changes as example above.

  • Page 14: Dvd Setup

    DVD Setup QUICK SETUP Menu You can select the “PLAYER MENU”, “TV ASPECT” or “DOLBY DIGITAL” from the QUICK SETUP menu quickly. Press [SETUP] in the stop mode. SETUP STOP <SETUP MENU> Confirm that “QUICK” is selected. SETUP QUICK CUSTOM INITIALIZE CUSTOM Menu You can change the settings of the unit.

  • Page 15: Display Setting

    DISPLAY Setting You can change the display functions. Follow steps 1 to 3 in the “CUSTOM Menu” section on page 14. Select the desired item. TV ASPECT: (Default: 4:3 LETTER BOX) ENTER See Hint on the right. TV ASPECT STILL MODE DISPLAY menu SETUP DISPLAY...

  • Page 16: Parental Setting

    PARENTAL Setting Parental Control limits the disc viewing that exceed your settings. (An incorrect password will not be acceptable.) This feature prevents your children from viewing inappropriate materials. Parental Levels Parental Level allows you to set the rating levels of your DVD discs. Playback will stop if the ratings exceed the levels you set.

  • Page 17: Reset To The Default Setting (Except For Parental Setting)

    Reset to the Default Setting (except for PARENTAL Setting) Press [SETUP]. Select “INITIALIZE”. SETUP STOP SETUP menu SETUP SETUP QUICK CUSTOM INITIALIZE Troubleshooting Guide If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit consulting the following checklist.

  • Page 18: Specifications

    Specifications Output signal format: NTSC color Power source: 120 V AC +/- 10%, 60 Hz +/- 0.5% Power consumption: 10 W (standby: 0.8 W) Language Code List Language Code Language French [FRE] Abkhazian 4748 Frisian Afar 4747 Galician Afrikaans 4752 Georgian Albanian 6563...

  • Page 19: Español

    Español Conexiones Si su televisor tiene entradas de AUDIO/VIDEO vea la sección “Connection to a TV” en la página 6 en el Manual de Manejo. En caso contrario, vea la sección “Connecting to RF Modulator” en la página del frente en el Manual de Manejo.

  • Page 20: Quick Use Guide

    Quick Use Guide Connections If your TV has AUDIO/VIDEO input jacks, see the section “Connection to a TV” on page 6 of the Owner’s Manual. If not, see the section “Connecting to RF Modulator” on the front page of the Owner’s Manual. Installing the Batteries for the Remote Control To Change the On-Screen Language Confirm that “QUICK”...
