Install Instructions For:
FP Series
FP Series
Motion Sensor
ATTENTION
The FP pod comes with the motion sensor lens preset to a wide angle and will trigger audio
activation from movement beyond the diameter of the dome. For applications with a narrow motion
sensor angle, follow these instructions. The narrow motion sensor lens will trigger audio activation
only when someone is standing directly underneath the dome.
FP Speaker Pod
Warning
S o u n d Tu b e s p e a k e r s m u s t b e i n s t a l l e d b y a p r o f e s s i o n a l a u d i o
installer/contractor. For safety and for optimum audio performance,
installer must follow all directions issued by SoundTube Entertainment.
Dome Clamp
Motion Sensor
Motion Sensor
lens (narrow)
Motion Sensor
lens (wide)
Motion Sensor
Pod Cover
1.435.647.9555
Motion Sensor Accessory Contents
(Optional, included)
(Standard)
© 2005 SoundTube Entertainment, Inc. All rights reserved. PN INS-FP6-MS REV 01.12.06
Warning
Do not spec or install speaker near support beam, ventilation
duct or other structure that may interfere with speaker function
or dispersion.
|
|
800.647.TUBE
www.soundtube.com
1 FP Pod with wide lens
1 Narrow lens
