PGS S27 Owner's Manual

Legacy series, pacifica series, newport series;
Hide thumbs Also See for S27:
Table of Contents

Advertisement

Quick Links

OWNERS MANUAL

LEGACY
SERIES GRILLS
PACIFICA SERIES (S36&S36R)
NEWPORT SERIES (S27&S27R)
LP OR NATURAL GAS
PORTABLE OR MASONRY
WARNING:
Read this Owner's Manual carefully and be sure your grill has been properly
assembled, installed and maintained.
bodily injury and/or property damage.
be installed in or on recreational vehicles or boats.
NOTE TO INSTALLER:
installation.
NOTE TO CONSUMER:
Nuts, bolts and fittings may become loose during transit, so for your own safety, thoroughly
inspect every nut, bolt and connection and secure as necessary before using your new grill.
IMPORTANT SAFETY NOTE: This grill is manufactured to exact specifications for the type of
fuel marked on the outside carton, as well as noted on the rating plate found on the grease tray.
Conversion from one fuel type to the other fuel type can only be done with an entire valve train
change, and only by a trained expert.
Failure to follow these instructions could result in serious
This grill is intended for outdoor use only and is not to
Leave this Owner's Manual with the consumer after delivery and/or
Leave this Owner's Manual in a convenient place for future reference.
Pacific Gas Specialties Corporation
P.O. Box 16097
Irvine, CA
92623-6097
(949) 757-7723 fax (949) 474-5559
E-mail:
info@pgscorp.com
Assembly, Operating
& Maintenance Instructions
Revised January 1, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S27 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PGS S27

Summary of Contents for PGS S27

  • Page 1: Owners Manual

    OWNERS MANUAL LEGACY SERIES GRILLS PACIFICA SERIES (S36&S36R) NEWPORT SERIES (S27&S27R) LP OR NATURAL GAS PORTABLE OR MASONRY WARNING: Read this Owner’s Manual carefully and be sure your grill has been properly assembled, installed and maintained. bodily injury and/or property damage.
  • Page 2 Authorized PGS Dealer or Distributor if you have any specific questions concerning our products.

  • Page 3: Table Of Contents

    Grease Tray Clean Out ...Page 11 Periodic Cleaning ... Page 11 & 12 Flash Back (Spider Fires) ...Page 12 Flare Ups ...Page 12 Gas Grill Conversion...Page 12 Troubleshooting... Page 12 & 13 Care of Stainless Steel...Page 13 Masonry Cut Out Dimensions...Page 13 Infra Broil Rear Burner Use...Page 14...
  • Page 4 PGS gas grill may result in serious bodily injury and/or property damage. GIVE THIS SYMBOL SPECIAL ATTENTION THROUGHOUT THIS MANUAL.

  • Page 5: Recap Of Safety Tips, Warnings And Recommendations

    • Never use charcoal, volcanic rock, wood chip materials, or non-PGS briquettes in your grill. • Keep the optional rotisserie motor and electrical supply cord away from heated casting, cooking grids, other hot parts or water.

  • Page 6: Model Identification

    SAFETY INFORMATION OF PROPANE MODELS Your PGS grill is designed to operate on propane gas regulated at a gas pressure of 11" water column (W.C.) (2.7kPa). hooking your grill into “System LP” which fuels your home, please be certain that you are at this pressure.

  • Page 7: Natural Gas Models

    A regulator adjusted to this pressure must be installed in the gas supply line before the grill is connected to the propane source. PGS propane gas grills include a 11” W.C. regulator and a “TYPE I “ Cylinder Connection Device.

  • Page 8: Part Numbers And Descriptions

    Locking Casters for Cart Swivel Caster for Cart Inner Shelf for Cart Use of your gas grill at the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5kPa). The grill must be isolated from the gas by closing its valves during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5kPa).

  • Page 10: Safety Precautions

    SAFETY PRECAUTIONS IF YOU SMELL GAS: 1. Shut off gas to the appliance. 2. Extinguish any open flames. 3. Open lid. 4. If odor continues, immediately call your gas supplier. CALIFORNIA PROPOSITION 65 –WARNING The burning of gas cooking fuel generates toxic byproducts, which are on the list of substances that are known by the State of California to cause cancer or reproductive harm.

  • Page 11: Connection To Gas Supply

    be tightened with an Allen-wrench, vice grips on channel locks. Attach the two non-locking wheels to the other side of the cart. Flip cart back upright and attach two right-hand side shelf brackets to the right-hand side of the cart, and the two left-hand to the left-hand side with the angled edge at the bottom and the straight edge on the top.

  • Page 12: Lighting Your Grill

    NOTE GAP ON ELECTRODE AND GROUND WIRE Before using grill, we suggest you LINE YOUR GREASE TRAY WITH HEAVY-DUTY ALUMINUM FOIL. inspection and clean out of the grease tray provided with your PGS gas grill. You will find this very easy.

  • Page 13: Flash Back (Spider Fires)

    Spider webs inside venturi THIS SHOULD BE DONE ROUTINELY AFTER THE GRILL HAS SET IDLE FOR EXTENDED PERIODS. Your PGS grill has fine mesh brass screening placed inside the burner venturis to minimize this problem. Please DO NOT damage or remove these screens when you clean your burners.

  • Page 14: Care Of Stainless Steel

    Grill. Likewise do not use wire brushes, scrapers or contaminated scouring pads. 4. Your PGS Grill has a directional polished grain, any cleaning with abrasives should be carried out along this grain and not across it 5.

  • Page 15: Side Burner Kit

    MDS (door kit) 16 ¾” INFRA-BROIL REAR BURNER The PGS Infra-Broil Kit comes as a standard feature on our models Newport Gourmet and Pacifica Gourmet. The Infra-Broil is a rear burner especially designed for those back yard chefs who love to rotisserie.
  • Page 16 Install battery with “+” side facing out. GAS LEAK TEST AFTER SIDE BURNER KIT IS ATTACHED TO CART, TIGHTEN ALL CONNECTIONS, FITTINGS AND SCREWS. THAT DURING TRANSPORT, CONNECTIONS AND SCREWS MAY BECOME LOOSE CHECK ALL. BEFORE ATTEMPTING TO LIGHT GRILL, BE CERTAIN THE GAS VALVE KNOBS ARE IN THE OFF POSITION.

  • Page 17: Cooking Tips And Times

    Some flare-up should not only be expected but is desirable in most outdoor cooking. Your PGS Grill has been designed to allow you to control the level of the flare-ups. ceramic rocks themselves have been designed to give you unequaled even cooking and flare-up control.
  • Page 18 A meat thermometer with a probe will give you an exact indication of proper cooking times and temperatures. INDIRECT COOKING You can bake or roast foods in your PGS grill just like you would in a conventional oven. can be cooked using this indirect method.
  • Page 19 After deciding on the main dish you can get quite creative planning your meal around it. PGS grill allows you a great deal of flexibility in the choice and preparation of the main dish. The following section will provide you...
  • Page 20 (see recipe) placed on top of the steaks as soon as cooked will add a gourmet touch to your meal. Your PGS cooking grids are specifically designed to retain the heat and cook your steaks quickly, thoroughly, and evenly throughout.

  • Page 21: Fish & Seafood

    BARBECUE or cooking sauce. FISH & SEAFOOD Your PGS grill has been designed with particular attention to the special requirements needed to cook fish and seafood easily. Our performance grilling system has been designed to provide you with even cooking temperatures as well as the added flexibility of our variably spaced grids for small more delicate seafood items.

  • Page 22: Beef Cooking Guide

    Your PGS outdoor gas grill is a fun and exciting product that welcomes your involvement and creativity. grill can cook!

  • Page 23: Poultry Cooking Guide

    Your PGS outdoor gas grill is a fun and exciting product that welcomes your involvement and creativity. grill can cook! POULTRY COOKING GUIDE The guide below is only a guide;...

  • Page 24: Warranty Information

    WE STRONGLY RECOMMEND THAT YOU PURCHASE A PGS GRILL COVER TO PROTECT THE FINISH OF YOUR GRILL WHEN NOT IN USE.
  • Page 25 PACIFIC GAS SPECIALTIES, CORPORATION 2641 DU BRIDGE AVE. IRVINE, CA. 92606-5001 (949) 757-7723 949 474-5559...
