INSTALLATION ANd OPERATION INSTRUCTIONS
CUSTOm PASS-ThRU bACk bAR CAbINET - SELf CONTAINEd ANd REmOTE
PS Series
ImPORTANT INfORmATION
Fill out the enclosed warranty card and mail to the
Perlick Corporation to register the warranty. if the
card is not returned, the warranty period will begin
from the date the equipment is shipped from the
factory.
this manual has been prepared to assist you in the
installation of your Cabinet and to acquaint you with
its operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. if service is required, your dealer can
provide you with a list of qualified service agents. For
your own protection, never return merchandise for
credit without our approval.
We thank you for selecting a Perlick product and
assure you of our continuing interest in your
satisfaction.
WARNING: When lifting, the full weight of the
cabinet must be supported. Lift from the cabinet
base and not from the top. Improper lifting can
result in severe damage to the cabinet.
8300 West good hope road • Milwaukee, Wi 53223 • Phone 414-353-7060 • Fax 414-353-7069
toll Free 800-558-5592 • e-Mail: Perlick@Perlick.com • www.Perlick.com
mOdEL NOS.
PS Series
Pr Series
PR Series
Table of Contents
Specifications .....................................................2,3
List of included Parts .............................................4
tools required ......................................................4
Plumbing ................................................................4
electrical ................................................................4
Uncrating and inspection .......................................4
Placing the Cabinet ...............................................4
Leveling the Cabinet ..............................................4
installing Legs ......................................................4
installing the base Plate ........................................4
electrical Condensate evapaway Kit ....................4
refrigeration and temperature Control .................5
Cleaning the Cabinet .............................................5
Cleaning Stainless Steel .......................................5
replacement Parts ................................................6
reversing Door hinge ...........................................7
Wiring Diagram ......................................................8
Form no. Z2279
rev 08.01.07
