TS Performance Products
Re-Speed
Tire Calibration and Speed Limiter
Removal Operation & Installation Manual
Installation of the TS Performance Re-Speed
Read all instructions and fully understand them before installing your TS Performance Re-Speed
module. Disconnect the battery terminals and remove keys from ignition before installation.
Advertisement
Table of Contents
Summary of Contents for TS Performance Re-Speed F-150
- Page 1 TS Performance Products Re-Speed Tire Calibration and Speed Limiter Removal Operation & Installation Manual Installation of the TS Performance Re-Speed Read all instructions and fully understand them before installing your TS Performance Re-Speed module. Disconnect the battery terminals and remove keys from ignition before installation.
- Page 2 Contents: (1) Switch (2) T-taps Installation: 1) Use supplied pink connector, crimp to RED wire on ReSpeed; crimp supplied eyelet to BLACK wire. 2) Use the supplied T-tap and tap RED wire into KEY ON +12 V usually located under the dash. 3) Connect the black wire to good clean ground.
- Page 3 Disable speed limiter 1) Leave key off and locate the push button next to the dip switches on re-speed board (Figure 5). This button allows the re-speed to go into SET mode if pushed while powering up. 2) Hold the button down and turn the vehicle on then release the button. 3) The re-speed is now in SET mode.
- Page 4 Calibration Charts Tire Ratios Chart A Gear Ratios Chart B Dip Switch Chart...
- Page 5 %Change in Speed Dip Switch Values 1 represents dip switch on, 0 represents dip switch off, for example the dip switch settings in Figure 6 is the equivalent of 11100001. %Change in Speed 11001100 10101100 00011100 01011100 10111100 11111100 01000010 00100010 11100010 10010010...
- Page 6 TS Perforamance Re-Speed Guide Part # Make Model F-150 F-250 1190101 Ford F-350 Bronco Explorer Mountainer Explorer Mountainer Ford Sport Trac Ranger 1190102 Dodge Dakota Dakota/Durango Cherokee Grand Cherokee Jeep Wrangler Liberty F-250 Ford 1190103 Dodge Tears Sensor Wire Color, Location 1992-1996 Red/Pink, behind speedometer 1997-1998...
- Page 7 READ CAREFULLY BEFORE INSTALLING ANY TS PERFORMANCE PRODUCT REMEMBER THIS IS A HIGH PERFORMANCE PRODUCT. USE AT YOUR OWN RISK. FOR OFF ROAD USE ONLY. Do not use this product until you have carefully read the following agreement. This agreement sets forth the terms and conditions for the use of the TS Performance product.
